4OM-1603
3-33
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
422202 positioning conveyor Error
Time Over in the downward on Backup(L) axis
-----
422203 positioning conveyor Error
Conveyor did not stop
-----
422204 positioning conveyor Error
Upward timeout on Backup(L) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422301 positioning conveyor Error
Time Over in placement of product position(R)
Remove Stagnated P.C.B., Please set P.C.B. correct positioning. (manual moving)
422302 positioning conveyor Error
Time Over in the downward on Backup(R) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422303 positioning conveyor Error
Conveyor did not stop
-----
422304 positioning conveyor Error
Upward timeout on Backup(R) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422401 Output Conveyor Error
P.C.B. output was not completed within predetermined time.
P.C.B. is stagnating in P.C.B. Output for Output Machine. Please set stagnated
P.C.B.
422402 Output Conveyor Error
The output was completed, but P.C.B. is still placed on output conveyor .
P.C.B is stagnated although the movement in the position of transfer start is done.
PleaseconrmthestagnatedP.C.B.andConveyortransitsection.
422403 Output Conveyor Error
No P.C.B. on output conveyor
P.C.B. was not detected when output started. There is a possibility whether not
detected by P.C.B. Slit or it is fallen. Please set correctly after checking P.C.B..
Conrmtheadjustmentofconveyorwidth.
422404 Output Conveyor Error
Stop sensor of output conveyor was detected while P.C.B. was ready for placing
Remove Stagnated P.C.B.
423001 Communication Error of transfer section
Error in AELINK communication
Error in P.C.B. board. Please exchange it.
423101 Error in NL-L1 axis
Zeroing Error on NL-L1 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
4OM-1603
3-34
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
423102 Error in NL-L1 axis
Out-of-Control on NL-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423103 Error in NL-L1 axis
Error in motor power voltage of NL-L1 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423104 Error in NL-L1 axis
STP input on NL-L1 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423105 Error in NL-L1 axis
Over-current on NL-L1 axis
Abnormalcurrentinmotoroutputlinewasdetected.Conrmthemotorwiring,
supplying power.
423106 Error in NL-L1 axis
Limit sensor(+) on NL-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423107 Error in NL-L1 axis
Limit sensor(-) on NL-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423108 Error in NL-L1 axis
Motor disconnection of NL-L1axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423109 Error in NL-L1 axis
Error in control power voltage of NL-L1 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42310a Error in NL-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42310b Error in NL-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42310c Error in NL-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42310d Error in NL-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42310e Error in NL-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
4OM-1603
3-35
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
42310f Error in NL-L1 axis
System Error on NL-L1 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423110 Error in NL-L1 axis
Communication Error on NL-L1 axis
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
423201 Error in NL-L2 axis
Zeroing Error on NL-L2 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423202 Error in NL-L2 axis
Out-of-Control of NL-L2 was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423203 Error in NL-L2 axis
Error in motor power voltage of NL-L2 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423204 Error in NL-L2 axis
STP input on NL-L2 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423205 Error in NL-L2 axis
Over-current on NL-L2 axis
Abnormalcurrentinmotoroutputlinewasdetected.Conrmthemotorwiring,
supplying power.
423206 Error in NL-L2 axis
Limit sensor(+) on NL-L2 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423207 Error in NL-L2 axis
Limit sensor(-) on NL-L2 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423208 Error in NL-L2 axis
Motor disconnection of NL-L2 axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423209 Error in NL-L2 axis
Error in control power voltage of NL-L2 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42320a Error in NL-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
