4OM-1603 3-54 3. Error IDs and Remedial Procedures : Chap.3 1 109-006 3.4 T ray Feeder (Block1) Error ID Error Name, Description, Cause, and Remedy 430201 T ray Motor Error(Block1) Elevator abnormal stop ----- 430202 T r…
4OM-1603
3-53
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
42b504 Transfer check
Going down in PCB stopper(AR) was not completed within the predetermined
time.
-----
42b505 Transfer check
Going down in PCB stopper(BL) was not completed within the predetermined
time.
-----
42b506 Transfer check
Going down in PCB stopper(BR) was not completed within the predetermined
time.
-----
42b601 Transfer check
Going down in the backup base(L) was not completed within the predetermined
time.
-----
42b602 Transfer check
Going down in the backup base(R) was not completed within the predetermined
time.
-----
42b603 Transfer check
Going down in the backup base(AL) was not completed within the predetermined
time.
-----
42b604 Transfer check
Going down in the backup base(AR) was not completed within the predetermined
time.
-----
42b605 Transfer check
Going down in the backup base(BL) was not completed within the predetermined
time.
-----
42b606 Transfer check
Going down in the backup base(BR) was not completed within the predetermined
time.
-----
T4C5
4OM-1603
3-54
3. Error IDs and Remedial Procedures : Chap.3
1109-006
3.4 Tray Feeder (Block1)
Error ID Error Name, Description, Cause, and Remedy
430201 Tray Motor Error(Block1)
Elevator abnormal stop
-----
430202 Tray Motor Error(Block1)
Elevator abnormal stop
-----
430203 Tray Motor Error(Block1)
Traverse abnormal stop
-----
430301 Tray Rack Shutter open/close error (Block1)
The Rack Shutter did not open in prescribed time.
-----
430302 Tray Rack Shutter open/close error (Block1)
The Rack Shutter did not close in prescribed time.
Pleaseconrmwhetherthepaletteisnotcaughtintherackshutter.
430401 Tray Pallet Chuck open/close error (Block1)
The Pallet Chuck did not open in prescribed time.
-----
430402 Tray Pallet Chuck open/close error (Block1)
The Pallet Chuck did not close in prescribed time.
-----
431001 Tray Supply Operation Error (Block1)
-----
-----
431002 Tray Supply Operation Error (Block1)
Tray steps No. disagreement of draw out(return operation)
-----
431003 Tray Supply Operation Error (Block1)
Tray steps No. disagreement of draw out(return operation)
-----
431004 Tray Supply Operation Error (Block1)
The operation mode is illegal. (system)
-----
431005 Tray Supply Operation Error (Block1)
The position of TV axis is irregular
-----
431006 Tray Supply Operation Error (Block1)
Magazineclassicationdisagreement
Please carry out the check of ten steps of magazines, and 15-step type.
431101 Tray Pallet Returning Error (Block1)
Elevator pre-check error
-----
431102 Tray Pallet Returning Error (Block1)
Elevator movement position error
-----
4OM-1603
3-55
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
431103 Tray Pallet Returning Error (Block1)
Elevator wave form setting error
-----
431104 Tray Pallet Returning Error (Block1)
Elevator operating error
-----
431201 Tray Pallet Returning Error (Block1)
Traverse pre-check error
-----
431202 Tray Pallet Returning Error (Block1)
Traverse movement position error
-----
431203 Tray Pallet Returning Error (Block1)
Traverse wave form setting error
-----
431204 Tray Pallet Returning Error (Block1)
Traverse operating error
-----
431206 Tray Pallet Returning Error (Block1)
No palette when the return begins.(B15411)
-----
431301 Tray Pallet Draw out Error (Block1)
Elevator pre-check error
-----
431302 Tray Pallet Draw out Error (Block1)
Elevator movement position error
-----
431303 Tray Pallet Draw out Error (Block1)
Elevator wave form setting error
-----
431304 Tray Pallet Draw out Error (Block1)
Elevator operating error
-----
431305 Tray Pallet Draw out Error (Block1)
Elevator abnormal stop
-----
431401 Tray Pallet Draw out Error (Block1)
Traverse pre-check error
-----
431402 Tray Pallet Draw out Error (Block1)
Traverse movement position error
-----
431403 Tray Pallet Draw out Error (Block1)
Traverse wave form setting error
-----
