4OM-1603
3-56
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
431404 Tray Pallet Draw out Error (Block1)
Traverse operating error
-----
431405 Tray Pallet Draw out Error (Block1)
Traverse operating error
-----
431406 Tray Pallet Draw out Error (Block1)
No palette when drawing out begins. (B0511)
-----
431407 Tray Pallet Draw out Error (Block1)
Cannot detect the pallet to draw out (B15505, B15506)
Pleaseconrmwhetherthepalletinthemagazineissetproperly.Ifso,adjustthe
sensor, please.
431501 Move to Tray Elevator supply/exchange position error (Block1)
Elevator pre-check error
-----
431502 Move to Tray Elevator supply/exchange position error (Block1)
Elevator movement position error
-----
431504 Move to Tray Elevator supply/exchange position error (Block1)
Elevator operating error
-----
431602 Tray Feeder Zeroing Error (Block1)
Tray feeder zeroing Servo ON error
-----
431603 Tray Feeder Zeroing Error (Block1)
Traverse pallet search error
-----
431604 Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
431605 Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
431606 Tray Feeder Zeroing Error (Block1)
The palette was detected though there was no draw out history.
-----
431607 Tray Feeder Zeroing Error (Block1)
Elevator return steps movement error
-----
431608 Tray Feeder Zeroing Error (Block1)
Traverse pallet store error
-----
431609 Tray Feeder Zeroing Error (Block1)
Elevator zeroing pre-check error
-----
4OM-1603
3-57
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
43160a Tray Feeder Zeroing Error (Block1)
Pallet chuck close error
-----
43160b Tray Feeder Zeroing Error (Block1)
Rack shutter CLOSE error
-----
43160c Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
43160d Tray Feeder Zeroing Error (Block1)
EV1 step logs and step movement error
-----
43160e Tray Feeder Zeroing Error (Block1)
Ev2 step logs and step movement error
-----
43160f Tray Feeder Zeroing Error (Block1)
Traverse zeroing error
-----
431610 Tray Feeder Zeroing Error (Block1)
Traverse zeroing pre-check error
-----
431611 Tray Feeder Zeroing Error (Block1)
Pallet chuck CLOSE error
----------
431613 Tray Feeder Zeroing Error (Block1)
Pallet chuck OPEN error
-----
431614 Tray Feeder Zeroing Error (Block1)
Traverse recede operation error
-----
431615 Tray Feeder Zeroing Error (Block1)
The palette was not detected though there was a draw out history.
-----
431616 Tray Feeder Zeroing Error (Block1)
Rack shutter OPEN error(Upper Magazine)
-----
431617 Tray Feeder Zeroing Error (Block1)
Rack shutter OPEN error(Lower Magazine)
-----
431618 Tray Feeder Zeroing Error (Block1)
The other pallet was detected from pallet store position during pulling.
-----
431619 Tray Feeder Zeroing Error (Block1)
Traverse zeroing error
-----
4OM-1603
3-58
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
43161a Tray Feeder Zeroing Error (Block1)
Pallet chuck CLOSE error
-----
43161b Tray Feeder Zeroing Error (Block1)
Rack shutter CLOSE error
-----
43161c Tray Feeder Zeroing Error (Block1)
Magazine(Down) Error in shifting Pallet existence detection position.
-----
43161d Tray Feeder Zeroing Error (Block1)
Magazine(Up) Error in shifting Pallet existence detection position.
-----
43161e Tray Feeder Zeroing Error (Block1)
Missing detect sensor is detected although a pallet is stroed.
PleaseconrmwhetherPalletisstoredinUp/downmagazine.
All pallets are stored but missing pallet is detected.
Please adjust the missing detect sensor [B15406].
431801 Tray Feeder in advanced check error (Block1)
Tray power supply not turning on(power supply cut off from main machine)
-----
431802 Tray Feeder in advanced check error (Block1)
The Safety Cover of the body is open.
Please close the safety cover of the body, and then press "READY" button, lock
the cover.
431803 Tray Feeder in advanced check error (Block1)
Tray maintenance cover OPEN
-----
431804 Tray Feeder in advanced check error (Block1)
Traverse axis main circuit was cut off
-----
431805 Tray Feeder in advanced check error (Block1)
Safety circuit cut off
-----
431806 Tray Feeder in advanced check error (Block1)
Elevator axis main circuit cut off
-----
431807 Tray Feeder in advanced check error (Block1)
Tray Safety Cover(Upper) is open.
Please close Tray safety cover(Upper), and then press "READY" button, lock the
cover.
431808 Tray Feeder in advanced check error (Block1)
Tray Safety Cover(Center) is open.
Please close Tray safety cover(Center), and then press "READY" button, lock the
cover.
