4OM-1603
3-127
3. Error IDs and Remedial Procedures : Chap.3
1109-006
3.12 Automatic Operation Error
Error ID Error Name, Description, Cause, and Remedy
510a01 Feeder Pocket recog Error
Abnormality occurred in process of recognizing Feeder Pocket.
-----
510b01 Auto Run Error
Master bad mark detection is abnormal.
-----
510b02 Auto Run Error
Bad mark detection is abnormal.
-----
510e01 Nozzle air blow Error(Head1)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510e02 Nozzle air blow Error(Head1)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510e03 Nozzle air blow Error(Head1)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f01 Nozzle air blow Error(Head2)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f02 Nozzle air blow Error(Head2)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f03 Nozzle air blow Error(Head2)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
511001 Head1 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511002 Head1 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511003 Head1 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
4OM-1603
3-128
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
511004 Head1 Preparation Error
There is a possibility that Nozzle is falling while processing the preparation.
PleaseconrmtheplacedNozzleonHead.
-----
511101 Head2 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511102 Head2 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511103 Head2 Preparation Error
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511104 Head2 Preparation Error
There is a possibility that Nozzle is falling while processing the preparation.
PleaseconrmtheplacedNozzleonHead.
-----
511201 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(L) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511202 Transfer Section's Preparation Error
Upward movement on PCB Stopper(L) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511203 Transfer Section's Preparation Error
Downward movement on PCB Stopper(L) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511204 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(R) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511205 Transfer Section's Preparation Error
Upward movement on PCB Stopper(R) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511206 Transfer Section's Preparation Error
Downward movement on PCB Stopper(R) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511207 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AL) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511208 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
1109-006
4OM-1603
3-129
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
511209 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511210 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AR) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511211 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511212 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511213 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BL) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511214 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511215 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511216 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BR) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511217 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511218 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511219 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(REV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511220 Transfer Section's Preparation Error
Upward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511221 Transfer Section's Preparation Error
Downward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511222 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AREV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
