4OM-1603
3-15
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
402901 Pass Line2 Detected(Head1)
Pass Line2 detected(Head1)[B04]
-----
402A01 Pass Line3 Detected(Head1)
Pass Line3 detected(Head1)[B04]
-----
402B01 Nozzleoatup1detected(Block1)
Nozzleoatup1detected(Block1)[B1611]
ConrmNozzleofNozzleStocker1(Block1).
402C01 Nozzleoatup2detected(Block1)
Nozzleoatup1detected(Block1)[B1611]
ConrmNozzleofNozzleStocker2(Block1).
402D01 Over squeeze1 detected (Head2)
Over squeeze1 detected (Head2)[B05]
-----
402E01 Over squeeze2 detected (Head2)
Over squeeze2 detected (Head2)[B05]
-----
402F01 Over squeeze3 detected (Head2)
Over squeeze3 detected (Head2)[B05]
-----
403001 Pass Line1 Detected(Head2)
Pass Line1 detected(Head2)[B04]
-----
403101 Pass Line2 Detected(Head2)
Pass Line2 detected(Head2)[B04]
-----
403201 Pass Line3 Detected(Head2)
Pass Line3 detected(Head2)[B04]
-----
403301 Nozzleoatup1detected(Block2)
Nozzleoatup1(Block2)detected[B1611]
ConrmNozzleofNozzleStocker1(Block2).
403401 Nozzleoatup2detected(Block2)
Nozzleoatup2(Block2)detected[B1611]
ConrmNozzleofNozzleStocker2(Block2).
403501 Detecting Emergency stop (Block1)
Emergency stop(Block1) is detected
Drive after the power turns on.
403601 Tray Safety Door(Lower)(Block1)
Safety door (lower) of tray feeder unit opened.(Block1)[S0501]
Close the safety door(Lower) and operate it.
403701 Tray Safety Door(Upper)(Block1)
Safety door (upper) of tray feeder unit opened.(Block1)[S0502]
Close the safety door(Center) and operate it.
4OM-1603
3-16
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
403801 Tray Safety Door(Center)(Block1)
Safety door (center) of tray feeder unit opened.(Block1)[S0503]
Close the safety door(Upper) and operate it.
403901 Pallet Chuck Claw(Block1)
Chucking lever of pallet opened while elevator is moving.(Block1)
[B15407, B15408]
Check out detecting Sensor (B15407, B15408) of closing Chucking lever of pallet.
403A01 Palletyingaway(Block1)
Thepalletyingawaywhileelevatorismoving.(Block1)[B15406]
Check out detecting sensor (B15406) of breaking out Pallet and position of Pallet.
403B01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15417]
Please open the main cover and remove pickup miss components on the pallet.
403C01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15418]
Please open the main cover and remove the pickup miss components on tray
pallet.
403D01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15419]
Please open the main cover and remove the pickup miss components on tray
pallet.
403E01 Detecting Lower Magazine rack shutter (Block1)
Open the rack shutter while lower elevator is moving.(Block1)[B15521][B15523]
[B15525]
Check out the sensor (B15521, B15523, B15525) of closing magazine rack
shutter.
403F01 Detecting Upper Magazine rack shutter (Block1)
Open the rack shutter while upper elevator is moving.(Block1)[B15527][B15529]
[B15531]
Check out the sensor (B15527, B15529, B15531) of closing magazine rack
shutter.
404001 Lower magazine positioning error(Block1)
Lower magazine positioning error(Block1) [B15526]
Check Magazine Clamp.
404101 Upper magazine positioning error(Block1)
Upper magazine positioning error.(Block1) [B15532]
Check Magazine Clamp.
404201 Shut-off Motor Breaker for Tray (Block1)
Tripped circuit breaker of motor (Block1).
Please turn on again after turning off and cancelling Trip mode.
404301 Shut-off safety relay of Elevator(Lower) (Block1)
Cut off safety relay of lower elevator (Block1).
Check the main circuit and safety door.
404401 Shut-off safety relay of Elevator(Upper) (Block1)
Cut off safety relay of upper elevator (Block1).
Check the main circuit and safety door.
4OM-1603
3-17
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
404501 Elevator Unit Clamp released (Block1)
Released clamp of elevator unit (Block1)[B15426, B15428]
Check out Elevator unit clamp sensor(B15426, B15428).
404601 Detecting pickup miss cmpnt of Tray Feeder Cart (Block1)
Detecting pickup miss cmpnt(Block1) [B15412]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
404701 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Block1)
Feeder Disengaged Latch is detected.(Block1)[B15412]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
404801 Detecting Emergency Stop(Block2)
Emergency stop(Block2) is detected
Please turn on the main body and operate it.
404901 Tray Safety Door(Lower)(Block2)
Safety door(Lower) of tray feeder unit opened.(Block2)[S0501]
Please close the safety door(lower) and operate it.
404A01 Tray Safety Door(Upper)(Block2)
Safety door(Upper) of tray feeder unit opened.(Block2)[S0502]
Please close the safety door(upper) and operate it.
404B01 Tray Safety Door(Center)(Block2)
Safety door(Center) of tray feeder unit opened.(Block2)[S0503]
Please close the safety door(center) and operate it.
404C01 Pallet Chuck Claw(Block2)
Pallet Chuck Claw opened while elevator is moving.(Block2)[B15407, B15408]
Check out detection Sensor of closing Chucking lever of pallet (B15407, B15408).
404D01 Palletyingaway(Block2)
Palletyingawayduringelevatormoving.(Block2)[B15406]
Check out detecttion sensor of breaking out Pallet (B15406) and position of Pallet.
404E01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pickup misscmpnt on the Pallet is detected.(Block2) [B15417]
Open the main cover and remove pickup miss components on the Tray Pallet.
404F01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pickup miss cmpnt on the Pallet is detected.(Block2) [B15418]
Open the main cover and remove pickup miss components on the Tray Pallet.
405001 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pickup miss components on the Pallet is detected.(Block2) [B15419]
Open the main cover and remove pickup miss components on the Tray Pallet.
405101 Detecting lower Magazine rack shutter (Block2)
the rack shutter opening is detected during lower elevator moving.(Block2)
[B15521, B15523,B15525]
Check out the sensor of closing magazine rack shutter (B15521, B15523,
B15525).
