4OM-1603
4-9
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
05200603 Shape (edge) cannot be detected.
05200604 Shape (rectangle) cannot be detected.
05200605 Shape (oval) cannot be detected.
05200606 There is shape that cannot be detected as in the shade of nozzle etc.
05200607 The Shape corresponding to data was not able to be detected.
05200000 Others.
05800001 The pick-up position has deviated greatly.
05800002 The pick-up position has deviated greatly in X direction.
05800003 The pick-up position has deviated greatly in Y direction.
05800004 The pick angular skew is big.
05800101 Component outward length X is incorrect.
05800102 Component outward length X is shorter than the tolerance.
05800103 Component outward length X is longer than the tolerance.
05800104 Component outward length Y is incorrect.
05800105 Component outward length Y is shorter than the tolerance.
05800106 Component outward length Y is longer than the tolerance.
05800107 Component outward length X or Y is incorrect.
05800108 Component outward length X or Y is shorter than the tolerance.
05800109 Component outward length X or Y is longer than the tolerance.
05800201 The number of leads is small.
05800202 The number of leads is large.
05800203 The lead width is shorter than the tolerance.
05800204 The lead width is longer than the tolerance.
05800205 Gap of the width direction of a lead is larger than a permissible value.(Cmpnt
Angle inclined)
05800206 Gap of the length direction of a lead is larger than a permissible value.
05800207 The detected lead length direction positions differ greatly.
05800208 The lead length is shorter than the tolerance.
05800209 The lead length is longer than the tolerance.
05800301 Electrode(ball) length is incorrect.
05800302 Electrode(ball) position is larger than a permissible value.
05800303 Electrode(ball) which must not exist existed.
05800401 A shape positional gap is larger than a permissible value.
05800000 Others.
05900000 Others.
05900101 Error in Polarity Detection.
05900102 The polarity of components differs.
05900103 The polarity of components cannot be judged.
05900201 The component is reversed.
05900301 There is the electrode (lead) that must not exist
05900302 There is the electrode (ball) that must not exist
05900303 There is the shape that must not exist.
05900401 Thereistheballwhichuxisnotspread.
05900402 Fluxspreadisnotconrmedbecausethecomponentrecognitionwasabnormal.
05a00101 The pick-up position has deviated greatly in X direction.
05a00102 The pick-up position has deviated greatly in Y direction.
4OM-1603
4-10
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
05a00103 The pick angular skew is big.
05a00000 Others.
05b00001 The pick-up position has deviated greatly.
05b00002 The pick-up position has deviated greatly in X direction.
05b00003 The pick-up position has deviated greatly in Y direction.
05b00004 The pick angular skew is big.
05b00000 Others.
05e00000 Others.
15000000 Others.
06001001 Base mark not found in recognizable range.
06001002 The position of base mark slips off.
06001003 Base mark not found in recognizable range.
06001101 The Base mark is not found, because light turn off.
06001102 Base mark not Acquiring in recognizable range.
06001201 The Base mark is not found, because mark light too bright.
06001202 Base mark not Acquiring in recognizable range.
06000001 Speciedmarknotfoundinrecognizablerange.
06000101 The Base mark is not found, because mark light turn off.
06000102 The Base mark is not found, because too dark.
06000201 Base mark not found in recognizable range. Because mark light turn on.
06000202 The Base mark is not found, because too bright.
06000000 Others.
06101001 Base mark not found in recognizable range.
06100001 Speciedmarknotfoundinrecognizablerange.
06100000 Others.
06201001 Base mark not found in recognizable range.
06201100 Base mark edge not detected.
06201201 Base mark edge not detected.
06201401 Base mark corner not detected.
06201402 Base mark corner not detected.
06201403 Base mark corner not detected.
06201404 Base mark corner not detected.
06201405 Base mark corner not detected.
06200001 Speciedmarknotfoundinrecognizablerange.
06200100 Edge not detected.
06200201 Edge not detected.
06200401 Corner not detected.
06200402 Corner not detected.
06200403 Corner not detected.
06200404 Corner not detected.
06200405 Corner not detected.
06200000 Others.
06301101 Base Mark shape not circle.
06301102 Base Mark shape not square.
06301201 Base mark edge not detected.
06300101 Speciedmarkisnotcircle.
4OM-1603
4-11
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
06300102 Speciedmarkisnotsquare.
06300201 Edge not detected.
06300000 Others.
06801101 Base mark not found in recognizable range.
06801102 Base mark not found in recognizable range.
06801201 Extensive error in similitude of mark size.
06801202 Extensive error in similitude of mark size.
06801301 Extensive error in similitude of mark shape.
06801302 Extensive error in similitude of mark shape.
06801401 Extensive error in similitude of mark shape.
06801402 Extensive error in similitude of mark shape.
06801501 Base mark not found in recognizable range.
06801502 Base mark not found in recognizable range.
06801601 Base mark not found in recognizable range.
06801602 Base mark not found in recognizable range.
06801603 Base mark not found in recognizable range.
06801604 Base mark not found in recognizable range.
06800101 Speciedmarknotfoundinrecognizablerange.
06800102 Speciedmarknotfoundinrecognizablerange.
06800201 Extensive error in similitude of mark size
06800202 Extensive error in similitude of mark size
06800301 Extensive error in similitude of mark shape
06800302 Extensive error in similitude of mark shape
06800401 Extensive error in similitude of mark shape
06800402 Extensive error in similitude of mark shape
06800501 Speciedmarknotfoundinrecognizablerange.
06800502 Speciedmarknotfoundinrecognizablerange.
06800601 Speciedmarknotfoundinrecognizablerange.
06800602 Speciedmarknotfoundinrecognizablerange.
06800603 Speciedmarknotfoundinrecognizablerange.
06800604 Speciedmarknotfoundinrecognizablerange.
06800701 Mark size is different
06800702 Mark size is different
06800703 Mark shape is different
06800704 Mark shape is different
06800801 It can't read the recognized mark
06800802 The type of nozzle stocker is different.
06800000 Others.
06e00001 Others.
06e00002 Others.
06e00000 Others.
16000000 Others.
07000001 Nozzle not detected.
07000000 Others.
07100001 Nozzle not detected.
07100000 Others.
