4OM-1603
3-110
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
4b0c01 NozzleConrmationErrorbeforepickupcomp(DetectAfterPlacement)
Because a component was found on a nozzle, it stopped after disposal.
The result could have some problems.
Please check placement state on placement step recovery screen.
4b0c02 NozzleConrmationErrorbeforepickupcomp
The remains component was found on a nozzle during production.
PleaseconrmwhetherthereisanerrorintheP.C.B.
4b0c03 NozzleConrmationErrorbeforepickupcomp(DetectAfterDiscard)
Because a component was found on a nozzle, it stopped after disposal.
Pleaseconrmandcleanupthenozzleifthiserrorcontinues.
4b0e01 Splicing tape set error
The joint part of splicing tape is not correctly set. Please extract a feeder and
check whether the tape has separated from the guide.
-----
4b1201 Press in error / Insertion error
There is an error with the component pressed in or Insertion
OpensafetycoverandconrmthecomponentonP.C.B.Pleaseremoveitor
revise it
4b19ff Zeroing of single axis error
Timeout in zeroing of single axis.
-----
4b2001 P.C.B Height Measurement
Abnormal measured value was detected.
Check the measurement position.
4b2002 P.C.B Height Measurement
Abnormality occurred for communication with a sensor
-----
4b2003 P.C.B Height Measurement
The abnormality number of times of measured value was beyond a set point.
Running is stopped.
-----
4b2004 P.C.B Height Measurement
The abnormality number of times of measured value was beyond a set point.
-----
4b2005 P.C.B Height Measurement
A measurement result is abnormal(measure in arbitrary position)
Check the measurement position.
4b2006 P.C.B Height Measurement
Surpass a measurement range. (+ direction)
-----
4b2007 P.C.B Height Measurement
Surpass a measurement range. (- direction)
-----
4b2008 P.C.B Height Measurement
Detected a curve more than permission values. (+ direction)
-----
4OM-1603
3-111
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
4b2009 P.C.B Height Measurement
Detected a curve more than permission values. (- direction)
-----
4b200a P.C.B Height Measurement
Error of the result measured by a master jig (height)
Check if the master jig (height) has some dirt and foreign particles.
4b200b P.C.B Height Measurement
Failed in wearing height revision.
-----
4b200c P.C.B Height Measurement
An abnormal measurement was detected by the multipoint measurement.
Check the measurement position.
4b200d P.C.B Height Measurement
Recovery by the multipoint measurement failed because the measurement result
wasinsufcient.
Check the measurement position.
4b2011 P.C.B Height Measurement
Measurement time-out
-----
4b2081 P.C.B Height Measurement
Abnormality occurred for communication with a sensor
-----
4b2082 P.C.B Height Measurement
Failed in wearing height revision.
-----
4b2083 P.C.B Height Measurement
Measurement time-out
-----
4b2084 P.C.B Height Measurement
The coordinate where the height measurement was impossible was appointed.
Please appoint a coordinate in a measurable range.
4b2101 SSC network abnormal
There is abnormal in SSC network.
PleaseconrmthecableofSSCnetwork.
4b2102 SSC network abnormal
ThereisaprobleminconnectiontoServoAmplier(XY).
(1) Shut down the machine and check the connection between the position board
andamplier.
(2)Checkwhetherornottheservoampliersaredamaged.
4b2103 SSC network abnormal
ThereisaprobleminconnectiontoServoAmplier(Head).
(1) Shut down the machine and check the connection between the position board
andamplier.
(2)Checkwhetherornottheservoampliersaredamaged.
4OM-1603
3-112
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
4b2301 Feeder (Servo Error)
Alarm Code:A0 - Internal Parameter Error (Breakdown of Control P.C.B.)
Please replace the feeder. (Do not disconnect the feeder in powering on,
otherwise it may cause the inside data broken.)
4b2302 Feeder (Servo Error)
Alarm Code:A1 - Over Current Error (Foreign substances in the tape feeding drive
section)
Conrmwhetherornotthetapeisbeingjammedonthepath./Conrmthereelto
operatesmoothly./Conrmwhetherornotsomecomponentsanddustarebeing
caughtinthesprocket./Conrmwhetherornotsomecomponentsanddustare
being caught in the tape feeding gear.
4b2303 Feeder (Servo Error)
Alarm Code:A2 - Others
-----
4b2304 Feeder (Servo Error)
Alarm Code:A3 - Others
-----
4b2305 Feeder (Servo Error)
Alarm Code:A4 - Main Circuit Power Supply Error (Please check the power supply
voltage.) (G04)
Please check the power supply voltage.
4b2306 Feeder (Servo Error)
Alarm Code:A5 - Fault Speed Error (Tape catching)
Conrmwhetherornotthetapeisbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthetape
feeding gear.
4b2307 Feeder (Servo Error)
Alarm Code:A6 - Others
-----
4b2308 Feeder (Servo Error)
Alarm Code:A7 - Fault Load Error (Tape twisting, Catching foreign substances)
Conrmwhetherornotthetapeisbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthetape
feeding gear.
4b2309 Feeder (Servo Error)
Alarm Code:A8 - Encoder Error (Breaking wire, Breakdown of control P.C.B. and
Defective servo motor)
Please replace the feeder.
4b230a Feeder (Servo Error)
Alarm Code:Ab - System Error
Please replace the feeder. (It may be caused by trouble of the control P.C.B..)
