4OM-1603 1-13 2. Maintenance Check List : Chap.1 2.3 Monthly Maintenance Grease Symbols DE1 : DAPHNE EPONEX GREASE No. 1 Object Unit Inspection, Cleaning, and Lubricating Spots Work Grease Required T ools Check 3.2.3 Com…
4OM-1603
1-12
2. Maintenance Check List : Chap.1
2.2 Weekly Maintenance
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.1 Air Source
Drain
Cleaning
----- -----
3.2.3 Component
Recognition
Camera Section
Fiducial Mark
Cleaning
----- Lens Cleaning Cloth
3.2.5 Feeder Cart
Section
Groove on Feeder Base
Cleaning
----- Vacuum Cleaner
3.2.6 Feeder Cart
Section (Cutter)
Cutter Box Inside
Cleaning
----- Vacuum Cleaner
Linear Guide
3.2.7 Head Section
Vacuum Nozzle
Cleaning
----- Lens Cleaning Cloth,
Air Gun, Rag
Nozzle Filter
Change
----- Filter Insertion Jig
(High-Speed Nozzle),
Filter Insertion Jig
(Nozzle for Middle-Size and
Odd-Shape Components),
Filter Removing Jig
3.2.9 PCB Positioning
Section
Upper Surface of Feeder
Base
Cleaning
----- Vacuum Cleaner
3.2.10 Conveyor
Section
Support Pin Detection
Sensors
Cleaning
----- Rag
PCB Detection Sensor,
PCB Detection Sensor
Fiber,
PCB Detection Sensor
Mirror
Cleaning
----- Rag
T4A10
1109-005
4OM-1603
1-13
2. Maintenance Check List : Chap.1
2.3 Monthly Maintenance
Grease Symbols
DE1
: DAPHNE EPONEX GREASE No. 1
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.3 Component
Recognition
Camera Section
Teaching Plate
Cleaning
----- Rag
QFP Glass Plate Jig
Cleaning
----- Lens Cleaning Cloth
3.2.7 Head Section
High Speed Head
Diffusion Plate
Cleaning
----- Lens Cleaning Cloth
3.2.11 Nozzle Stocker
Section
Nozzle Stocker
for High Speed
Nozzle
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
3.2.11 Nozzle Stocker
Section
Nozzle Stocker
for Multi-
Function Nozzle
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
Carn Follower
Cleaning,
Lubrication
NM1
T4A11
1109-001
4OM-1603
1-14
2. Maintenance Check List : Chap.1
2.4 Quarterly Maintenance
Grease Symbols
DE1
: DAPHNE EPONEX GREASE No. 1
NM1
: MOLYNOC GREASE AP1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.1 Air Source
Filter
Cleaning
-----
3.2.2 Vacuum System
Driving Section
Filter
Cleaning
-----
3.2.4 Feeder Base
Worm Gear
Lubrication
NM1
3.2.6 Feeder Cart
Section (Cutter)
Linear Guide
Lubrication
DE1
Needle Bearing
Lubrication
DE1
3.2.7 Head Section
High Speed Head
Nozzle U/D Ball Screw
(NL Axis)
Cleaning,
Lubrication
DE1
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
DE1
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
DE1
Center Spline
Lubrication
DE1
Carn Follower
Cleaning,
Lubrication
DE1
Nozzle Change Carn
Face (Upper Side)
Cleaning,
Lubrication
DE1
Vacuum Filter
Replacement
-----
Vacuum Nozzle
Inspection
-----
3.2.7 Head Section
Multi-Functional
Head
Ball Screw (3 locations)
Lubrication
DE1
Linear Guide
(3 locations)
Lubrication
DE1
Pan
(3 locations)
Cleaning
----- Oiled Rag
Vacuum Filter
Change
----- Filter Attachment /
Detachment Jig
Vacuum Nozzle
Inspection
-----
3.2.8 X/Y Beam
Section
* X-Axis Linear Guide
Cleaning,
Lubrication
DE1
* Y-Axis Linear Guide
Cleaning,
Lubrication
DE1
X-Axis Linear Scale
Cleaning
-----
Y-Axis Linear Scale
Cleaning
-----
3.2.9 PCB Positioning
Section
* Ball Screw
Cleaning,
Lubrication
DE1
3.2.10 Conveyor
Section
* Linear Guide
Cleaning,
Lubrication
DE1
T4A12
1012-005
