4OM-1603
3-139
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
600903 Teaching Leaning Nozzle offset
Error of coordinates calculation.
-----
600904 Teaching Leaning Nozzle offset
Error of Data set for XY Beam.
-----
600905 Teaching Leaning Nozzle offset
Error of moving for XY Beam.
-----
600906 Teaching Leaning Nozzle offset
Time-out in XY Beam movement
-----
600907 Teaching Leaning Nozzle offset
Time-out of communication with recognition.
-----
600908 Teaching Leaning Nozzle offset
Error of Leaning Nozzle offset teaching
-----
600909 Teaching Leaning Nozzle offset
Error of Noz Select Axis Pos. Offset Teaching
-----
60090A Teaching Leaning Nozzle offset
Noz Select Axis Pos. Offset is out of permission values.
There is a possibility that Head Rotate Theta Axis offset is not correct. / There is
apossibilitythatLightEmitterandReceiverofLinearmeasuringSensorhasaw
and soil / There is a possibility that Nozzle is damaged. / There is a possibility that
Head has some problem.
60090B Teaching Leaning Nozzle offset
Could not measure correctly on Noz Select Axis Pos. Offset Teaching.
There is a possibility that Head Rotate Theta Axis offset is not correct. / There is
apossibilitythatLightEmitterandReceiverofLinearmeasuringSensorhasaw
and soil / There is a possibility that Nozzle is damaged. / There is a possibility that
Head has some problem.
601001 Master nozzle level offset teach
Error is detected before Line Sensor measurement began
-----
601002 Master nozzle level offset teach
Error of NS-axis movement
-----
601003 Master nozzle level offset teach
Error of DD-axis movement
-----
601004 Master nozzle level offset teach
Time-out of NS-axis movement
-----
4OM-1603
3-140
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
601005 Master nozzle level offset teach
Time-out of DD-axis movement
-----
601006 Master nozzle level offset teach
Time-out when Line Sensor measurement began
-----
601007 Master nozzle level offset teach
Read Time-out of Line Sensor measurement
-----
601101 Noz level offset teaching
Time-out when Line Sensor measurement began
-----
601102 Noz level offset teaching
Read Time-out of Line Sensor measurement
-----
601103 Noz level offset teaching
Error during Line Sensor measurement
-----
601104 Noz level offset teaching
Error of dirty Line Sensor
-----
601105 Noz level offset teaching
Error of NS-axis Origin calculation
-----
601106 Noz level offset teaching
Error of NS-axis movement
-----
601107 Noz level offset teaching
Error of DD-axis Origin Calculation
-----
601108 Noz level offset teaching
Error of DD-axis movement
-----
601109 Noz level offset teaching
Program Error
-----
60110a Noz level offset teaching
Error before Line Sensor measurement began
-----
60110b Noz level offset teaching
Nozzle on Head is not placed
-----
601301 Noz stocker offset teaching
Error of coordinates calculation(XY)
-----
4OM-1603
3-141
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
601302 Noz stocker offset teaching
Error of XY-axis movement
-----
601303 Noz stocker offset teaching
Time-out in XY-axis movement
-----
601304 Noz stocker offset teaching
Error of HL-axis movement
-----
601305 Noz stocker offset teaching
Error of NL-axis movement
-----
601306 Noz stocker offset teaching
Error of L-axis movement
-----
601307 Noz stocker offset teaching
Error of HL/NL/L-axis movement
-----
601308 Noz stocker offset teaching
Nozzle stocker is not clamped
-----
601309 Noz stocker offset teaching
Error of Lighting On of P.C.B. Recognition Camera
-----
60130a Noz stocker offset teaching
Timeout of Lighting On of P.C.B. Recognition Camera
-----
60130b Noz stocker offset teaching
Error of Lighting Off of P.C.B. Recognition Camera
-----
60130c Noz stocker offset teaching
Time-out of Lighting Off of P.C.B. Recognition Camera
-----
60130d Noz stocker offset teaching
Error of image capture of Nozzle Stocker Mark
-----
60130e Noz stocker offset teaching
Time-out of image capture of Nozzle Stocker Mark
-----
60130f Noz stocker offset teaching
Error of Recognition Performance of Nozzle Stocker Mark
-----
601310 Noz stocker offset teaching
Time-out of Recognition Performance of Nozzle Stocker Mark
-----
