4OM-1603
3-52
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
42b10d Shutter Conveyor Error in Output side
PCB on Shuttle Conveyor is gone.
It is possible to operate continuously.
PleaseconrmwhetherPCBwentoffitspositionifPCBisnotremovedon
purpose.
42b10e Shutter Conveyor Error in Output side
PCB on Shuttle Conveyor is changed.
PCB is inserted while not possible to be inserted. Please remove inserted PCB.
42b10f Shutter Conveyor Error in Output side
The Sensor of Shuttle Conveyor is detected from both sides.
There is a possibility that two pieces of PCB are inserted. Please remove an
uncertain PCB.
42b201 Time-out of Shuttle Conveyor in Output side
Time-out is occurred during insert mode from inner Machine.
There is a possibility that PCB is stopped on conveyor.
1. PleaseconrmPCBposition.
2. PleaseconrmwhetherConveyorWidthist.
3. Please setup Input Conveyor Timer Value of System settings, and adjust
insert time.
42b202 Time-out of Shuttle Conveyor in Output side
Time-out is occurred during Output Mode for Output Machine.
PCB is stopped between Conveyors. Check out PCB position.
1. PleaseconrmwhetherTransitpositionfromshuttleconveyorisproper.
2. PleaseconrmwhetherConveyorWidthist.
42b203 Time-out of Shuttle Conveyor in Output side
Time-out is occurred while Transfer position from Inner Machine is being moved.
PleaseconrmwhetherthereisnoerrorinUnit,nointerferenceornot.
42b204 Time-out of Shuttle Conveyor in Output side
Time-out is occurred while Delivery Position is being moved to Output Machine.
PleaseconrmwhetherthereisnoerrorinUnit,nointerferenceornot.
42b301 Shuttle Conveyor Error in Output side.
Error is made while Shuttle Conveyor is working.
-----
42b401 Transfer check
PCB is detected on the conveyor. Please remove it.
-----
42b501 Transfer check
Going down in PCB stopper(L) was not completed within the predetermined time.
-----
42b502 Transfer check
Going down in PCB stopper(R) was not completed within the predetermined time.
-----
42b503 Transfer check
Going down in PCB stopper(AL) was not completed within the predetermined
time.
-----
1109-001
4OM-1603
3-53
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
42b504 Transfer check
Going down in PCB stopper(AR) was not completed within the predetermined
time.
-----
42b505 Transfer check
Going down in PCB stopper(BL) was not completed within the predetermined
time.
-----
42b506 Transfer check
Going down in PCB stopper(BR) was not completed within the predetermined
time.
-----
42b601 Transfer check
Going down in the backup base(L) was not completed within the predetermined
time.
-----
42b602 Transfer check
Going down in the backup base(R) was not completed within the predetermined
time.
-----
42b603 Transfer check
Going down in the backup base(AL) was not completed within the predetermined
time.
-----
42b604 Transfer check
Going down in the backup base(AR) was not completed within the predetermined
time.
-----
42b605 Transfer check
Going down in the backup base(BL) was not completed within the predetermined
time.
-----
42b606 Transfer check
Going down in the backup base(BR) was not completed within the predetermined
time.
-----
T4C5
4OM-1603
3-54
3. Error IDs and Remedial Procedures : Chap.3
1109-006
3.4 Tray Feeder (Block1)
Error ID Error Name, Description, Cause, and Remedy
430201 Tray Motor Error(Block1)
Elevator abnormal stop
-----
430202 Tray Motor Error(Block1)
Elevator abnormal stop
-----
430203 Tray Motor Error(Block1)
Traverse abnormal stop
-----
430301 Tray Rack Shutter open/close error (Block1)
The Rack Shutter did not open in prescribed time.
-----
430302 Tray Rack Shutter open/close error (Block1)
The Rack Shutter did not close in prescribed time.
Pleaseconrmwhetherthepaletteisnotcaughtintherackshutter.
430401 Tray Pallet Chuck open/close error (Block1)
The Pallet Chuck did not open in prescribed time.
-----
430402 Tray Pallet Chuck open/close error (Block1)
The Pallet Chuck did not close in prescribed time.
-----
431001 Tray Supply Operation Error (Block1)
-----
-----
431002 Tray Supply Operation Error (Block1)
Tray steps No. disagreement of draw out(return operation)
-----
431003 Tray Supply Operation Error (Block1)
Tray steps No. disagreement of draw out(return operation)
-----
431004 Tray Supply Operation Error (Block1)
The operation mode is illegal. (system)
-----
431005 Tray Supply Operation Error (Block1)
The position of TV axis is irregular
-----
431006 Tray Supply Operation Error (Block1)
Magazineclassicationdisagreement
Please carry out the check of ten steps of magazines, and 15-step type.
431101 Tray Pallet Returning Error (Block1)
Elevator pre-check error
-----
431102 Tray Pallet Returning Error (Block1)
Elevator movement position error
-----
