4OM-1603
3-11
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
400942 Servo Alarm
The value of variation counter is out of the range
Check out the wiring of Origin sensor. Or, Exchange driver.
400951 Servo Alarm
Power Drive detected temperature error
Ambient Temperature is high. Exchange driver.
400961 Servo Alarm
Sensor Error
Check Motor Encoder wires. Or, exchange the motor.
400962 Servo Alarm
Sensor Error
Check Motor Encoder wires. Or, exchange the motor.
400971 Servo Alarm
high drive Voltage
Insufcientpower.Exchangedriver.
400972 Servo Alarm
Low drive Voltage
Check out the drive power wiring putted in Driver. Or, check out DC48V.
400991 Servo Alarm
Reading Error on permanent memory
Exchange the driver.
400992 Servo Alarm
Writing Error on permanent memory
Exchange the driver.
400998 Servo Alarm
CPU Error
Exchange the driver.
400999 Servo Alarm
Parameter Error
ConrmthechangedvalueofParameter.
400a08 Head Interlock Error
Releasing the brake is impossible during Servo On.
-----
400b01 Feeder preparation complete
A pick up miss comp or disengaged Latch was detected.
Openthesafetycoverandconrmthatthereisnointerferencewiththehead,and
then, release the ready feeder.
400c01 Nozzle stocker down time out
Nozzle stock unit lower bound detection 1 was not turned on in prescribed time.
Pleaseconrmthelowerbounddetection1sensorofnozzlestockunit.
400c02 Nozzle stocker down time out
Nozzle stock unit lower bound detection 2 was not turned on in prescribed time.
Pleaseconrmthelowerbounddetection2sensorofnozzlestockunit.
400c03 Nozzle stocker down time out
Nozzle stock unit lower bound detection 3 was not turned on in prescribed time.
Pleaseconrmthelowerbounddetection3sensorofnozzlestockunit.
4OM-1603
3-12
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
400c04 Nozzle stocker down time out
Nozzle stock unit lower bound detection 4 was not turned on in prescribed time.
Pleaseconrmthelowerbounddetection4sensorofnozzlestockunit.
400d01 Software Interlock Error
Head1 NL axis's poor operation was detected, and the scram of the XY axis was
carried out.
Please perform a zeroing.
400d02 Software Interlock Error
Head2 NL axis's poor operation was detected, and the scram of the XY axis was
carried out.
Please perform a zeroing.
400d03 Software Interlock Error
NL axis(Head2) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
Please perform a zeroing.
400d04 Software Interlock Error
NL axis(Head1) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
Please perform a zeroing.
400d05 Software Interlock Error
L1 axis(Head2) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
PleaseconrmdetectionofPassLine,excesspushing.
400d06 Software Interlock Error
L2 axis(Head2) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
PleaseconrmdetectionofPassLine,excesspushing.
400d07 Software Interlock Error
L3 axis(Head2) Interlock Detected
PleaseconrmdetectionofPassLine,excesspushing.
400d08 Software Interlock Error
L1 axis(Head1) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
PleaseconrmdetectionofPassLine,excesspushing.
400d09 Software Interlock Error
L2 axis(Head1) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
PleaseconrmdetectionofPassLine,excesspushing.
400d0a Software Interlock Error
L3 axis(Head1) Interlock Detected.
Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.
PleaseconrmdetectionofPassLine,excesspushing.
400f01 Safety Cover
Safety cover opened
Close the safety cover and lock it.
4OM-1603
3-13
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
400f02 Safety Cover
FailedinlockingSimpliedCover.
-----
400f03 Safety Cover
Failed in locking Auto Cover.
-----
401001 Cart
No Cart
There is a possibility that the Front/Rear of Cart is missing. Please put the cart in.
401101 Emergency Stop Switch
The [emergency stop] switch was pressed.
(Pleaseconrmthenozzlehasnotfallenwhenyoupushthebeambythehand.)
Please switch on a power supply after canceling an emergency stop switch and
screen return to normal display.
401201 Safety Cover
The safety cover opened. [S131,S132]
Please shut a safety cover and push the [POWER ON] button.
401301 Shut-off Beam
The main circuit of the XY Beam was broken. [K33A,K33B]
-----
401401 Head1 Nozzle descending
Head1 nozzle descent was detected. [A-B3104]
Please perform a zeroing.
401501 Head2 Nozzle descending
Head2 nozzle descent was detected. [B-B3104]
Please perform a zeroing.
401601 Head1 Nozzle descending
Head1 descent was detected. [A-B3103]
Please perform a zeroing.
401701 Head2 Nozzle descending
Head2 descent was detected. [B-B3103]
Please perform a zeroing.
401801 Detecting pickup miss Cmpnt(Block1)
A pickup-failed component (Block1) was detected. [DA-B0514]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
401901 Detecting pickup miss Cmpnt(Block2)
A pickup-failed component (Block2) was detected. [DB-B0515]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
401A01 Feeder Opening Sensor(Block1)
The feeder opening sensor (Block1) was shaded. [B****]
Please remove the factor which is shading the feeder opening sensor (Block1),
and carry out zero return.
