4OM-1603 3-59 3. Error IDs and Remedial Procedures : Chap.3 1 109-006 Error ID Error Name, Description, Cause, and Remedy 431809 T ray Feeder in advanced check error (Block1) T ray Safety Cover(Lower) is open. Please clo…
4OM-1603
3-58
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
43161a Tray Feeder Zeroing Error (Block1)
Pallet chuck CLOSE error
-----
43161b Tray Feeder Zeroing Error (Block1)
Rack shutter CLOSE error
-----
43161c Tray Feeder Zeroing Error (Block1)
Magazine(Down) Error in shifting Pallet existence detection position.
-----
43161d Tray Feeder Zeroing Error (Block1)
Magazine(Up) Error in shifting Pallet existence detection position.
-----
43161e Tray Feeder Zeroing Error (Block1)
Missing detect sensor is detected although a pallet is stroed.
PleaseconrmwhetherPalletisstoredinUp/downmagazine.
All pallets are stored but missing pallet is detected.
Please adjust the missing detect sensor [B15406].
431801 Tray Feeder in advanced check error (Block1)
Tray power supply not turning on(power supply cut off from main machine)
-----
431802 Tray Feeder in advanced check error (Block1)
The Safety Cover of the body is open.
Please close the safety cover of the body, and then press "READY" button, lock
the cover.
431803 Tray Feeder in advanced check error (Block1)
Tray maintenance cover OPEN
-----
431804 Tray Feeder in advanced check error (Block1)
Traverse axis main circuit was cut off
-----
431805 Tray Feeder in advanced check error (Block1)
Safety circuit cut off
-----
431806 Tray Feeder in advanced check error (Block1)
Elevator axis main circuit cut off
-----
431807 Tray Feeder in advanced check error (Block1)
Tray Safety Cover(Upper) is open.
Please close Tray safety cover(Upper), and then press "READY" button, lock the
cover.
431808 Tray Feeder in advanced check error (Block1)
Tray Safety Cover(Center) is open.
Please close Tray safety cover(Center), and then press "READY" button, lock the
cover.
4OM-1603
3-59
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
431809 Tray Feeder in advanced check error (Block1)
Tray Safety Cover(Lower) is open.
Please close Tray safety cover(Lower), and then press "READY" button, lock the
cover.
43180a Tray Feeder in advanced check error (Block1)
Feeder base is "Ready On"
PleaseconrmFeederCartsetcorrectly,andpressFeederBase"READY"
button.
43180b Tray Feeder in advanced check error (Block1)
No Magazine(Upper)
Please set Magazine(Upper).
43180c Tray Feeder in advanced check error (Block1)
No Magazine(Lower)
Please set Magazine(Lower).
43180e Tray Feeder in advanced check error (Block1)
Traverse axis Servo Alarm
-----
431810 Tray Feeder in advanced check error (Block1)
Elevator axis Servo Alarm
-----
431811 Tray Feeder in advanced check error (Block1)
Miss-Pickup comp. Detection 8mm[B15417]
-----
431812 Tray Feeder in advanced check error (Block1)
Miss-Pickup comp. Detection 14mm[B15418]
-----
431813 Tray Feeder in advanced check error (Block1)
Miss-Pickup comp. Detection 28mm[B15419]
-----
431814 Tray Feeder in advanced check error (Block1)
Pallet chuck is not shut
-----
431815 Tray Feeder in advanced check error (Block1)
The pallet Miss-Set was detected.
-----
431816 Tray Feeder in advanced check error (Block1)
Magazine(Lower) Rack Shutter on the operator side is open.
-----
431817 Tray Feeder in advanced check error (Block1)
Magazine(Lower) Rack Shutter on the side of Traverse is open.
-----
431818 Tray Feeder in advanced check error (Block1)
Magazine(Lower) is not done positioning yet.
PleaseconrmtheMagazinepositionandMagazinelocklever.
431819 Tray Feeder in advanced check error (Block1)
Elevator axis safety relay
-----
4OM-1603
3-60
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
43181a Tray Feeder in advanced check error (Block1)
Magazine(Upper) Rack Shutter on the operator side is open.
-----
43181b Tray Feeder in advanced check error (Block1)
Magazine(Upper) Rack Shutter on the Traverse side is open.
-----
43181c Tray Feeder in advanced check error (Block1)
Magazine(Upper) is not done positioning yet.
PleaseconrmtheMagazinepositionandMagazinelocklever.
43181d Tray Feeder in advanced check error (Block1)
Pick-up miss cmpnt detect
-----
431820 Tray Feeder in advanced check error (Block1)
Zeroing incomplete
-----
434001 Tray Feeder Sequence Error (Block1)
Tray feeder sequence timeout
-----
438302 Elevator Unit exchange (Attach) (Block1)
Elevator unit was not detected.
Please set up Tray Unit in Exchange location.
438303 Elevator Unit exchange (Attach) (Block1)
Connector of Feeder base is not positioned correctly
Please Operate it after connecting connector of Feeder Base.
438304 Elevator Unit exchange (Attach) (Block1)
Connector of Tray is not positioned correctly
Operate it after connecting connector of Tray.
438305 Elevator Unit exchange (Attach) (Block1)
Time-out of Clamp operating of Elevator Unit.
-----
438306 Elevator Unit exchange (Attach) (Block1)
Feeder base is not in Upward position.
Please press READY switch on Feeder Base, and rise it after setting Feeder cart..
438402 Elevator Unit exchange (Detach) (Block1)
Time-out of Unclamp operating of Elevator Unit.
-----
438403 Elevator Unit exchange (Detach) (Block1)
Feeder base is not in Upward position.
Please press READY switch on Feeder Base, and rise it after setting Feeder cart..
438405 Elevator Unit exchange (Detach) (Block1)
There were error when multi-tray receded.
-----
438406 Elevator Unit exchange (Detach) (Block1)
There were error when elevator1(Down) receded.
-----
