4OM-1603

3-72

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448408 Elevator Unit Exchange (Detach) (Block2)

There were error when traverse receded.

-----

448501 Multi-Tray(Block2)

Time-out of waiting for initialization

PleaseconrmAE-LINKwiringandPowerwiring.

448502 Multi-Tray(Block2)

Can not communicate Driver.

PleaseconrmAE-LINKwiringandPowerwiring.

448503 Multi-Tray(Block2)

Communication Status Error(Stand by)

PleaseconrmAE-LINKwiringandPowerwiring.

448504 Multi-Tray(Block2)

Communication Status Error(Alarm)

PleaseconrmAE-LINKwiringandPowerwiring.

448505 Multi-Tray(Block2)

Communication Status Error(OT)

PleaseconrmAE-LINKwiringandPowerwiring.

448506 Multi-Tray(Block2)

Communication Status Error(Connection O)

PleaseconrmAE-LINKwiringandPowerwiring.

448507 Multi-Tray(Block2)

Communication Status Error(Driver Alarm)

PleaseconrmAE-LINKwiringandPowerwiring.

448508 Multi-Tray(Block2)

Communication Status Error(SV-net stopping)

PleaseconrmAE-LINKwiringandPowerwiring.

448509 Multi-Tray(Block2)

Communication Status Error(Out of Connection number)

PleaseconrmAE-LINKwiringandPowerwiring.

44850A Multi-Tray(Block2)

Communication Status Error(SV-VET Error)

PleaseconrmAE-LINKwiringandPowerwiring.

44850B Multi-Tray(Block2)

Failed to read the number of Axes

PleaseconrmAE-LINKwiringandPowerwiring.

44850C Multi-Tray(Block2)

Driver-axis is not connected.

PleaseconrmAE-LINKwiringandPowerwiring.

44850D Multi-Tray(Block2)

Elevator1-axis is not connected.

PleaseconrmAE-LINKwiringandPowerwiring.

44850E Multi-Tray(Block2)

Elevator2-aixs in not connected.

PleaseconrmAE-LINKwiringandPowerwiring.

1109-006

4OM-1603

3-73

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448510 Multi-Tray(Block2)

Motor Breaker Trip Error

-----

448511 Multi-Tray(Block2)

Elevator Unit is not connected.

Please connect Elevator unit in Unit exchange menu.

448512 Multi-Tray(Block2)

All connectors of Elevator Unit are not connected.

PleaseconrmtheconnectiontoallconnectorofElevatorUnit

448513 Multi-Tray(Block2)

Failed to start-up Communication of SV-NET.

PleaseconrmAE-LINKwiringandPowerwiring.

448514 Multi-Tray(Block2)

Failed to turn on Multi-tray.(Time-out)

-----

448515 Multi-Tray(Block2)

(AtnishingAutoRun)Multi-trayoperation(Block2)isnotcompletedwithina

speciedtime.

Please Push Emergency Stop button.

448516 Multi-Tray(Block2)

To discriminate the connected tray cart is failed.

Please press READY switch on Feeder Base again.

Please contact to the service when to output the error is continuous.

448517 Multi-Tray(Block2)

Timeout in discriminating the tray cart.

Please press READY switch on Feeder Base again.

Please contact to the service when to output the error is continuous.

448601 Multi-Tray (Servo Error) (Block2)

Error of Power Driver, Over-current

PleaseconrmMotorwiring,ExchangeMotorandDriver.

448602 Multi-Tray (Servo Error) (Block2)

Overload Alarm

PleaseconrmMotorwiring,ExchangeMotorandDriver.

448603 Multi-Tray (Servo Error) (Block2)

Speed Alarm

You need to re-adjust Motor Gain.

448604 Multi-Tray (Servo Error) (Block2)

Multi-rotation Error

PleaseconrmMotorwiring,ExchangeMotorandDriver.

448605 Multi-Tray (Servo Error) (Block2)

The value of Deviation Counter was over the set value

PleaseconrmthewiringofOriginSensor,orexchangeDriver.

448606 Multi-Tray (Servo Error) (Block2)

Power Drive detected temperature error.

Ambient Temperature is too high. Or, exchange driver.

1109-006

4OM-1603

3-74

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448607 Multi-Tray (Servo Error) (Block2)

Sensor Error

PleaseconrmMotorEncoderwiring.Or,exchangemotor

448608 Multi-Tray (Servo Error) (Block2)

High Drive voltage

Insufcientpowercapacity.Pleaseexchangedriver.

448609 Multi-Tray (Servo Error) (Block2)

Low drive voltage

PleaseconrmtheoperatingPowerwiringwhichisinserteddriver.

44860A Multi-Tray (Servo Error) (Block2)

Reading Error on permanent memory

Please exchange driver.

44860B Multi-Tray (Servo Error) (Block2)

Writing Error on permanent memory

Please exchange driver.

44860C Multi-Tray (Servo Error) (Block2)

CPU Error

Please exchange driver.

44860D Multi-Tray (Servo Error) (Block2)

Parameter Error

Pleaseconrmthechangedparameter.

44860E Multi-Tray (Servo Error) (Block2)

Alarm code readout failed

-----

448701 Elevator Recede position operating error (Block2)

Elevator pre-check error

-----

448702 Elevator Recede position operating error (Block2)

Error of calculating Elevator movement position

-----

448703 Elevator Recede position operating error (Block2)

Elevator Start Time-out

-----

448704 Elevator Recede position operating error (Block2)

Elevator movement error

-----

448705 Elevator Recede position operating error (Block2)

Elevator movement Time-out

-----

448801 Elevator comp. position operating error (Block2)

Elevator pre-check error

-----

448802 Elevator comp. position operating error (Block2)

Error of calculating Elevator movement position

-----
