4OM-1603
3-93
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496319 Error of Shuttle Conveyor width W1 in Input side
Control Power Voltage of Conveyor Width W1 has error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49631a Error of Shuttle Conveyor width W1 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49631b Error of Shuttle Conveyor width W1 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49631c Error of Shuttle Conveyor width W1 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49631d Error of Shuttle Conveyor width W1 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49631e Error of Shuttle Conveyor width W1 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49631f Error of Shuttle Conveyor width W1 in Input side
System Error in Conveyor Width W1.
System Error of internal driver.
Driver error is supposed if this problem happens frequently.
496410 Error of Shuttle Conveyor width W2 in Input side
System setup of Conveyor Width W2 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
496411 Error of Shuttle Conveyor width W2 in Input side
Zeroing Error in Conveyor Width W2
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
496412 Error of Shuttle Conveyor width W2 in Input side
Out-of-Control in Conveyor Width W2
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496413 Error of Shuttle Conveyor width W2 in Input side
Error in Motor Power voltage of Conveyor Width W2
Motor power voltage dropped. Check out the Power supply line(48V Line)
496414 Error of Shuttle Conveyor width W2 in Input side
STP input in Conveyor Width W2 was detected
STP input is detected. The function to stop motor by Hard signal.
496415 Error of Shuttle Conveyor width W2 in Input side
Over-current in Conveyor Width W2
Error in Motor output line. Check out the motor wiring,
1109-006
4OM-1603
3-94
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496416 Error of Shuttle Conveyor width W2 in Input side
Limit Sensor(+) was detected in Conveyor Width W2.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496417 Error of Shuttle Conveyor width W2 in Input side
Limit Sensor(-) was detected in Conveyor Width W2.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496418 Error of Shuttle Conveyor width W2 in Input side
Motor Disconnection of Conveyor Width W2 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496419 Error of Shuttle Conveyor width W2 in Input side
Control Power Voltage of Conveyor Width W2 has an error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49641a Error of Shuttle Conveyor width W2 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49641b Error of Shuttle Conveyor width W2 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49641c Error of Shuttle Conveyor width W2 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49641d Error of Shuttle Conveyor width W2 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49641e Error of Shuttle Conveyor width W2 in Input side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49641f Error of Shuttle Conveyor width W2 in Input side
System Error in Conveyor Width W2.
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
496510 Error of Shuttle conveyor width W1 in Output side
System setup of Conveyor Width W1 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
496511 Error of Shuttle conveyor width W1 in Output side
Zeroing Error in Conveyor Width W1
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
1109-006
4OM-1603
3-95
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496512 Error of Shuttle conveyor width W1 in Output side
Out-of-Control in Conveyor Width W1
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496513 Error of Shuttle conveyor width W1 in Output side
Error in Motor Power voltage of Conveyor Width W1
Motor power voltage dropped. Check out the Power supply line(48V Line)
496514 Error of Shuttle conveyor width W1 in Output side
STP input in Conveyor Width W1 was detected
STP input is detected. The function to stop motor by Hard signal.
496515 Error of Shuttle conveyor width W1 in Output side
Over-current in Conveyor Width W1
Error in Motor output line. Check out the motor wiring,
496516 Error of Shuttle conveyor width W1 in Output side
Limit Sensor(+) was detected in Conveyor Width W1.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496517 Error of Shuttle conveyor width W1 in Output side
Limit Sensor(-) was detected in Conveyor Width W1.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496518 Error of Shuttle conveyor width W1 in Output side
Motor Disconnection of Conveyor Width W1 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496519 Error of Shuttle conveyor width W1 in Output side
Control Power Voltage of Conveyor Width W1 has error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49651a Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651b Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651c Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651d Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651e Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
