4OM-1603
3-124
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
4b5602 Head type error
The set type and the installed type for head2 are different.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5701 Library cmpnt carriage type error
There are errors of the cmpnt carriage type of the library.
Please check the library, and then do Chng. program.
4b5801 Joint detect
A joint is detected.
Please perform consistency check.
4b5901 LISA Communication error
LISA communication has errors.
Please check the followings, PC condition, Hub condition and connection
condition to LAN cable for LISA.
4b5a01 Warning about Maintenance
The total number of the feeder shot exceeded the setting value. It is time to
perform the feeder maintenance.
-----
4b5a02 Warning about Maintenance
The feeder adsorption rate decreased and exceeded the previous notice setting
number. It is time to perform the feeder maintenance.
-----
4b6001 Time Synchronization error
The time difference with the server device is 24 hours and more. Time
synchronization has been stopped.
There is a possibility that the battery of CPU board was dead.
Please inspect the battery of CPU board.
Please check the system time.
4b6101 Bowl Feeder power shut-off
Main power breaker of bowl feeder(Block1) is shut off.
Please check the power breaker of bowl feeder(Block1).
4b6102 Bowl Feeder power shut-off
Main power breaker of bowl feeder(Block2) is shut off.
Please check the power breaker of bowl feeder(Block2).
4b6201 Feeder information output error
Itisafoldertooutputloadedfeederinformationle.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4b6202 Feeder information output error
Couldnotoutputloadedfeederinformationle.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4OM-1603
3-125
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b6203 Feeder information output error
Couldnotdeleteoutputloadedfeederinformationle.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4b7201 BCD PP Change error
Disconnected server for BCD PP change reference folder. Please checking
connection status.
-----
4b7202 BCD PP Change error
CouldnotoutputpatternprogramlistletoserverforBCDPPchangereference
folder.Pleasecheckingconnectionstatusandleofsharedfolder.
-----
4b7203 BCD PP Change error
CouldnotdeletepatternprogramlistleonserverforBCDPPchangereference
folder.Pleasecheckingconnectionstatusandleofsharedfolder.
-----
4b7204 BCD PP Change error
ThePPinfoleisnotfound.PleaseregisterthePPinfolewiththeGCMserver.
-----
4b7205 BCD PP Change error
TheformatisabnormalofthePPinfole(PlacementOK/NGdataisabnormal).
-----
4b7206 BCD PP Change error
TheformatisabnormalofthePPinfole(PlacementpatternIDnameis
abnormal).
-----
4b7207 BCD PP Change error
TheformatisabnormalofthePPinfole(PlacementOK/NGdata:NG).
-----
T4C12
1109-001
4OM-1603
3-126
3. Error IDs and Remedial Procedures : Chap.3
1109-006
3.11 Handling Error
Error ID Error Name, Description, Cause, and Remedy
500101 Comp. Missing (Sensor)
Comp. Missing (Sensor)
There is a possibility that the picked comps. have fallen on the feeder and please
conrmit.
500301 Comp. Missing (Recog)
Comp. Missing (Recog)
There is a possibility that the picked comps. have fallen on the feeder and please
conrmit.
500401 Comp. Recog Error
Comp. Recog Error
-----
500501 Shortage of Component
Shortage of Component
-----
500502 Feeder Reload Stop
Feeder Reload Stop (Splicing)
-----
500c01 Comp. Vertical(Sensor)
Comp. Vertical(Sensor)
-----
500f01 Comp. Thickness(Sensor)
Comp. Thickness(Sensor)
-----
501001 Opt. Error(Feeder)
Feeder falls out
Feeder fell out during operation. Please check out it because there is a possibility
that Nozzle is damaged.
501101 Obverse/Reverse inspection error(Sensor)
Obverse/Reverse inspection error(Sensor)
-----
