4OM-1603
3-37
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
423307 Error in NA-L1 axis
Limit sensor(-) on NA-L1 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423308 Error in NA-L1 axis
Motor disconnection of NA-L1axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423309 Error in NA-L1 axis
Error in control power voltage of NA-L1 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42330a Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330b Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330c Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330d Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330e Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330f Error in NA-L1 axis
System Error on NA-L1 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423310 Error in NA-L1 axis
Communication Error on NA-L1 axis
1. Conrmconnectiontocommunicationcable.
2.ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
423401 Error in NA-L2 axis
Zeroing Error on NA-L2 axis
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423402 Error in NA-L2 axis
Out-of-Control on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
4OM-1603
3-38
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
423403 Error in NA-L2 axis
Error in motor power voltage of NA-L2 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423404 Error in NA-L2 axis
STP input on NA-L2 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423405 Error in NA-L2 axis
Over-current on NA-L2 axis
Abnormalcurrentinmotoroutputlinewasdetected.Conrmthemotorwiring,
supplying power.
423406 Error in NA-L2 axis
Limit sensor(+) on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423407 Error in NA-L2 axis
Limit sensor(-) on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423408 Error in NA-L2 axis
Motor disconnection of NA-L2 axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423409 Error in NA-L2 axis
Error in control power voltage of NA-L2 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42340a Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340b Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340c Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340d Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340e Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340f Error in NA-L2 axis
System Error on NA-L2 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
4OM-1603
3-39
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
423410 Error in NA-L2 axis
Communication Error on NA-L2 axis
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
423501 Error in NR-L1 axis
Zeroing Error on NR-L1 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423502 Error in NR-L1 axis
Out-of-Control of NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423503 Error in NR-L1 axis
Error in motor power voltage of NR-L1 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423504 Error in NR-L1 axis
STP input on NR-L1 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423505 Error in NR-L1 axis
Over-current in NR-L1 axis
Abnormalcurrentinmotoroutputlinewasdetected.Conrmthemotorwiring,
supplying power.
423506 Error in NR-L1 axis
Limit sensor(+) on NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423507 Error in NR-L1 axis
Limit sensor(-) on NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423508 Error in NR-L1 axis
Motor disconnection of NR-L1 axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423509 Error in NR-L1 axis
Error in control power voltage of NR-L1 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42350a Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42350b Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
