4OM-1603 2-21 2. Management Information : Chap.2 1 109-001 Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Information) 050703 Shuttle …

100%1 / 379
4OM-1603
2-20
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050515 Convert Width Setup
The set value of W2 axis exceeds the soft limit.
Please determine the value within the range from 250.5mm to 418.0mm.
050516 Convert Width Setup
The set value of W2 axis exceeds the soft limit.
Please determine the value within the range from 284.5mm to 452.0mm.
050517 Convert Width Setup
The set value of W3 axis exceeds the soft limit.
Please determine the value within the range from 49.5mm to 382.5mm.
050518 Convert Width Setup
The set value of W3 axis exceeds the soft limit.
Please determine the value within the range from 83.5mm to 416.5mm.
050519 Convert Width Setup
There is an interference between W1 axis and W2 axis.
Please change the value or separate the interfering axis.
05051a Convert Width Setup
There is an interference between W2 axis and W3 axis.
Please change the value or separate the interfering axis.
05051b Convert Width Setup
Please set conveyor width 83.5~511.5mm.
The total of PCB size/offset/clearance is over movable range.
050601 Middle Conveyor
Rotation Direction set of Middle Conveyor in supply side differs from Main Device
transfer direction. Please change the rotation direction of Middle conveyor.
050602 Middle Conveyor
Emergency Stop switch of middle conveyor in supply side is pressed.
Please cancel it.
050603 Middle Conveyor
Safety Cover of middle conveyor in supply side is open. Please close it.
050604 Middle Conveyor
Input Machine communication mode is set [PUSHER].
Cannot use [PUSHER] mode when Middle Conveyor is contacted.
050611 Middle Conveyor
Rotation Direction set of Middle Conveyor in output side differs from Main Device
transfer direction. Please change the rotation direction of Middle conveyor.
050612 Middle Conveyor
Emergency Stop switch of middle conveyor in output side is pressed.
Please cancel it.
050613 Middle Conveyor
Safety Cover of middle conveyor in output side is open. Please close it.
050701 Shuttle Conveyor
Emergency Stop Switch of Shuttle Conveyor in Input side is pressed. Please
cancel it.
050702 Shuttle Conveyor
The safety cover of Shuttle Conveyor in Input side is open. Please close it.
4OM-1603
2-21
2. Management Information : Chap.2
1109-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050703 Shuttle Conveyor
Deceleration sensor of Shuttle Conveyor in Input side is detected. Please remove
PCB because there is a possibility that it is inserted.
050704 Shuttle Conveyor
Deceleration Sensor of Input Conveyor is detected. Please remove PCB because
there is a possibility that it is inserted.
050705 Shuttle Conveyor
Deceleration Sensor of Input Conveyor in Lane A is detected. Please remove PCB
because there is a possibility that it is inserted.
050706 Shuttle Conveyor
Deceleration Sensor of Input Conveyor in Lane B is detected. Please remove
PCB because there is a possibility that it is inserted.
050707 Shuttle Conveyor
Set Value of Delivery Position of Device System/Input Machine PCB is not in the
Movable Range. Please set the value 467mm and less whose value is the sum
with Y size of PCB.
050708 Shuttle Conveyor
Please set [SMEMA] Mode for Device System/Input Machine Output. And, Please
conrmthatInp/OutpMachineSignalissetas[Enable].
050709 Shuttle Conveyor
Please set the same value in Lane A / Lane B of Delivery Position of Device
System/Input Machine PCB.
050711 Shuttle Conveyor
Emergency Stop Switch of Shuttle Conveyor in Output side is pressed. Please
cancel it.
050712 Shuttle Conveyor
The safety cover of Shuttle Conveyor in Output side is open. Please close it.
050713 Shuttle Conveyor
Deceleration Sensor of Shuttle Conveyor in Output side is detected. Please
remove PCB there is a possibility that it is inserted.
050714 Shuttle Conveyor
Stop Sensor of Output Conveyor is detected. Please remove PCB there is a
possibility that it is inserted.
050715 Shuttle Conveyor
Stop Sensor of Output Conveyor in Lane A is detected. Please remove PCB there
is a possibility that it is inserted.
050716 Shuttle Conveyor
Stop Sensor of Output Conveyor in Lane B is detected. Please remove PCB there
is a possibility that it is inserted.
050717 Shuttle Conveyor
Set Value of Delivery Position of Device System/Output Machine PCB is not in the
Movable Range. Please set the value 467mm and less whose value is the sum
with Y size of PCB.
050718 Shuttle Conveyor
Please set [SMEMA] Mode for Device System/Output Machine Output. And,
PleaseconrmthatInp/OutpMachineSignalissetas[Enable].
4OM-1603
2-22
2. Management Information : Chap.2
1109-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050801 Warning about Maintenance
It is time to perform the feeder maintenance.
060101 Feeder communication Error
CannotcommunicatewithFeeder.PleaseconrmthatselectedFeederisputin.
060201 Feeder type Error
Library and Feeder are inconsistent.
060301 Feeder preparation Error
Please drop Feeder base once. Then, rise it again.
060401 Feeder No. Error
Cannot Pick-up The Feeder. Please select another one.
060501 Nozzle Check
Nozzle is placed. Please Store it, and then retry to execute.
060601 Cart Check
There is a possibility of Block1/2 of Cart missing. Please set cart normally.
060602 Cart Check
Cart(Block1) is not at upper position. Please put it up.
060603 Cart Check
Cart(Block2) is not at upper position. Please put it up.
060604 Cart Check
Cannot operate it because Cart (Block1) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060605 Cart Check
Cannot operate it because Cart (Block2) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060606 Cart Check
Please operate it after shutting the feeder area cover (Blocks 1 and 2).
060701 Error in Carrier supplying Cmpnt
Itisimpossibletopick-upthiscmpntfromspeciedFeeder.Pleasechangethe
Placement mode as [By Hand].
060801 Cutter
Please close and lock the safety cover, and then operate it(Block1).
060802 Cutter
Please close and lock the safety cover, and then operate it(Block2).
070101 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Enable]. Please set Pattern program [Disable]. Or,
set up Jig and select [Jig] on the unit replace screen.
070102 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Disable]. Please set Pattern program [Enable]. Or,
take off Jig and select [None] on the unit replace screen.
0d0a01 Nozzle position
Nozzle is fallen. Please perform the all zeroing.
