4OM-1603
3-45
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
ThereisanindeniteP.C.B.onOutputpositiondeceleratingsensor.Please
remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
ThereisanindeniteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610c Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610d Detection of positioning conveyor sensor
Decrease sensor of output position was detected after movement completion
ThereisanindeniteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610e Detection of positioning conveyor sensor
Decrease sensor of output position was not detected after movement completion
-----
42610f Detection of positioning conveyor sensor
Stop sensor of output position was detected after movement completion
ThereisanindeniteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
426110 Detection of positioning conveyor sensor
Stop sensor of output position was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426111 Detection of positioning conveyor sensor
P.C.B. on positioning conveyor was detected
Please remove P.C.B. from positioning conveyor.
426112 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
ConrmwhetherP.C.B.isnotdropping.ConrmwhetherSensorisnotbroken.
426113 Detection of positioning conveyor sensor
There is a possibility of interference between Output PCB and Input PCB.
PassingPCBoccurredduringsimultaneoustransfer.Pleaseconrmthatoutputis
running without problems.
426114 Detection of positioning conveyor sensor
PCB has now reached input position.
1. There is a possibility that PCB is inserted and is dropped from conveyor.
Please check the conveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
conveyor. Or, return the removed PCB."
4OM-1603
3-46
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
426201 positioning conveyor timeout
Placement for input position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input conveyor and Input
positionorisdropped.PleaseconrmInput~positioningconveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
conveyor. Or, return the removed PCB.
3. Please check if cutout is on PCB. Please set cutout size in pattern program if
cutout is on PCB.
426202 positioning conveyor timeout
Output from input position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input position and Output,
orisdropped.Pleaseconrmpositioning~outputconveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
position. Or, return the removed PCB.
426203 positioning conveyor timeout
Placement for output position was not completed within predetermined time.
1. There is a possibility that PCB to take in the output position is inserted or
dropped.Pleaseconrminput~positioningconveyor.
2. The state of PCB memory on the conveyor differs from the state of taking.
Please clear the PCB memory in the edit screen when if it is. Or, return the
removed PCB.
3. Please check if cutout is on PCB. Please set cutout size in pattern program if
cutout is on PCB.
426204 positioning conveyor timeout
Output from output position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input position and Output,
orisdropped.Pleaseconrmpositioning~outputconveyor.
2. Please clear the PCB memory information in the edit screen if it is on the
output position. Or, return the removed PCB.
426205 positioning conveyor timeout
Positioning was not completed within the predetermined time.
There is a possibility that PCB is inserted. Please check the PCB on the conveyor.
426301 positioning conveyor Error
Error in positioning conveyor
-----
426302 positioning conveyor Error
Error in positioning change.
Please check the PCB on the conveyor.
427101 Detection of Output conveyor sensor
Decrease sensor was detected before starting.
ThereisanindeniteP.C.B.onOutputconveyor.Pleaseremoveit.
427102 Detection of Output conveyor sensor
Decrease sensor was not detected before starting the movement
P.C.B. to output is not found
1. Please put P.C.B. on Sensor.
2. ThereisapossibilityofP.C.B.fallen.Conrmtheconveyorwidth.
4OM-1603
3-47
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
427103 Detection of Output conveyor sensor
Stop sensor was detected before starting.
ThereisanindeniteP.C.B..Pleaseremoveit.
427104 Detection of Output conveyor sensor
Stop sensor was not detected before starting.
CannotndP.C.B.tooutput.
1. Is P.C.B. detected by sensor?
2. There is a possibility that P.C.B. is falling. Please check the width of conveyor.
427105 Detection of Output conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
ThereisanindeniteP.C.B.onOutputconveyor.Pleaseremoveit.
427106 Detection of Output conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
427107 Detection of Output conveyor sensor
P.C.B. on stop sensor was detected after movement completion
ThereisanindeniteP.C.B.onOutputconveyor.Pleaseremoveit.
427108 Detection of Output conveyor sensor
P.C.B. on stop sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
427109 Detection of Output conveyor sensor
P.C.B. on output conveyor was detected
Please remove P.C.B. from the conveyor
42710a Detection of Output conveyor sensor
P.C.B. on output conveyor was not detected
Please check whether P.C.B. is detected correctly.
Checkwhetherthesensordoesn’thaveError.
42710b Detection of Output conveyor sensor
Stop sensor is not passed during Output operation
The conveyor is stopped before P.C.B. goes through Sensor.
1. Conrmoutputmethod,transitionspeed,timersetting.
2. Check the connected cable.
42710c Detection of Output conveyor sensor
Disengaged P.C.B. of output conveyor
P.C.B. was removed from Output Conveyor.
Please check the state of it if removing P.C.B. does not happen intentionally.
42710d Detection of Output conveyor sensor
P.C.B. was not inserted into output conveyor
Please Remove P.C.B. inserted.
