4OM-1603
2-22
2. Management Information : Chap.2
1109-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050801 Warning about Maintenance
It is time to perform the feeder maintenance.
060101 Feeder communication Error
CannotcommunicatewithFeeder.PleaseconrmthatselectedFeederisputin.
060201 Feeder type Error
Library and Feeder are inconsistent.
060301 Feeder preparation Error
Please drop Feeder base once. Then, rise it again.
060401 Feeder No. Error
Cannot Pick-up The Feeder. Please select another one.
060501 Nozzle Check
Nozzle is placed. Please Store it, and then retry to execute.
060601 Cart Check
There is a possibility of Block1/2 of Cart missing. Please set cart normally.
060602 Cart Check
Cart(Block1) is not at upper position. Please put it up.
060603 Cart Check
Cart(Block2) is not at upper position. Please put it up.
060604 Cart Check
Cannot operate it because Cart (Block1) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060605 Cart Check
Cannot operate it because Cart (Block2) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060606 Cart Check
Please operate it after shutting the feeder area cover (Blocks 1 and 2).
060701 Error in Carrier supplying Cmpnt
Itisimpossibletopick-upthiscmpntfromspeciedFeeder.Pleasechangethe
Placement mode as [By Hand].
060801 Cutter
Please close and lock the safety cover, and then operate it(Block1).
060802 Cutter
Please close and lock the safety cover, and then operate it(Block2).
070101 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Enable]. Please set Pattern program [Disable]. Or,
set up Jig and select [Jig] on the unit replace screen.
070102 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Disable]. Please set Pattern program [Enable]. Or,
take off Jig and select [None] on the unit replace screen.
0d0a01 Nozzle position
Nozzle is fallen. Please perform the all zeroing.
4OM-1603
2-23
2. Management Information : Chap.2
1109-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
0d0b01 Cart Check
Openthesafetycover,thencheckthecmpntonPCB.Pleaseremoveorxit.
0d0c01 Pickup miss comp, Disengaged Latch Check
Pleaseopenthesafetydoorandconrmwhetherpickupmisscompisdropped
or no disengaged Latch is exist. If the comp is dropped, there is a possibility of
interference with Head.
0d0d01 ConrmbendingNoz
Openthesafetydoor,andthenconrmwhetherNozplacedinheadisbent.
0d0e01 Zeroing of Cutter is not completed
Perform All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head1).
Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head2).
Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching
Tray's Pallet is not pulled out (Block1). Please pull it out.
0d0f04 Height Teaching
Tray's Pallet is not pulled out (Block2). Please pull it out.
0d0f05 Height Teaching
Cannot teach Stocker Master height of the third and forth line for Stocker 2 of One
side Machine,
0d0f06 Height Teaching
There is no place for Glass Jig in the Head, so that could not teach the height of
Glass Jig.
0d1001 Stop Command
Interlock is detected. Please retry to execute after removing the factor.
0d1101 Flux dispensing unit squeegee error detect
Pleaseputdownsqueegeenottoseparatefromuxdispensingunit.
0d1201 Flux dispensing unit motor warning detect
Pleasetakeout/inuxdispensingandthenrestarttorun.
0d1301 Uninstalled Flux dispensing unit
Pleasesetuxdispensingunittouseinpatternprogramdata.
0d1401 Head type error
Please restart it after setting the head type properly.
0d1501 Keep large nozzle
Please remove the large nozzle on the head1 by hand.
Please retry to operate it after editing nozzle arrangement data
0d1502 Keep large nozzle
Please remove the large nozzle on the head2 by hand.
Please retry to operate it after editing nozzle arrangement data
0d1601 Large nozzle interference
The large nozzle is set positioning in the interfering position.
Please set positioning in the not interfering position, or perform all zeroing.
4OM-1603
2-24
2. Management Information : Chap.2
1109-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
0d1602 Large nozzle interference
Operation is impossible because large nozzles are placed in 2 axes adjacent to
the head1.
Please take off one of them by hand, and then edit the nozzle arrangement data.
0d1603 Large nozzle interference
Operation is impossible because large nozzles are placed in 2 axes adjacent to
the head2.
Please take off one of them by hand, and then edit the nozzle arrangement data.
0d1604 Large nozzle interference
It cannot run because a large nozzle runs to the interfering position.
0d1701 Non-applied function of the long board
The function is not applied to PCB which is longer than 610mm.
0d1801 Transferconrmation
The machine has not stopped.
0d1901 Bowl Feeder
Bowl feeder cart(Block1) has not been set. Please check a type of the cart. And,
Please check the setting for unit exchange screen.
0d1902 Bowl Feeder
Bowl feeder cart(Block2) has not been set. Please check a type of cart. And,
Please check the setting for unit exchange screen.
0d2001 Non-applied function of backup jig support to vacuum
The function is not available if backup jig to support vacuum is applied.
