4OM-1603
2-14
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018702 Feeder Alternate
Invalid feeder in alternating. Set feeder valid
018801 XY Origin Offset
Illegal XY-Origin offset of Beam1.
Please retry to send Device data from NT, or execute teaching XY-Origin offset.
018802 XY Origin Offset
Illegal XY-Origin offset of Beam2.
Please retry to send Device data from NT, or execute teaching XY-Origin offset.
018901 Feeder communication
Feeder (Block1) is on communication.
Please wait for a second, and then operate again.
018902 Feeder communication
Feeder (Block2) is on communication.
Please wait for a second, and then operate again.
018a01 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Block1)
018a02 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Block2)
018b01 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Block1)
018b02 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Block2)
019001 Support Pin
Please move exchange position of support pin.
019002 Support Pin
Noz for exchanging support pin is not set, or Odd type noz is set.
019003 Support Pin
Arranging data in current differs from it of Support Pin of current pattern program.
Please set-up the support pin.
019004 Support Pin
When PCB size 216mm is exceeded, it is impossible to operate if Support pins of
Lane A remain. Please exchange Lane A, or take out it from machine.
019005 Support Pin
It is impossible to do operation for only Lane B because Support Pins of Lane A
remain. Please exchange Lane A, or take out it from machine.
019006 Support Pin
Operation for Lane A is impossible because Support Pins of Lane A have not been
installed. Please exchange Support pins or store them.
019007 Support Pin
It is impossible to do Operation for only Lane A because Support Pins of Lane B
remain. Please exchange Lane B, or take out it from machine.
019008 Support Pin
Support pins of Lane B remain on the base for Support pins of Lane A, so that it is
impossible to do Conveyor width. Please exchange Support pins or store them.
019009 Support Pin
Arrangement of Support Pins interferes in Conveyor. Please retry to arrange it.
1109-006
4OM-1603
2-15
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
01900A Support Pin
"Vacuum/Blower" of Test Operation Mode is set "Disable".
Execute it after cancelling Test Operation Mode.
030162 Operation Requirement
The pattern cannot be switched
030413 Operation Requirement
Specify the order No.
030416 Operation Requirement
ACV server does not pass the authorization.
Please retry to connect to server on a screen [UNIT ADJ]-[ACV Set].
03041c Operation Requirement
ACVCheckError.ComponentIDonthefeederisnotsameasonespeciedby
current program.
030420 Operation Requirement
CommunicationswiththeACVserverisimpossible.AfterconrmingtheACV
server, please retry to perform it. [MAINT]-[UNIT ADJ]-[ACV ADJ].
030430 Operation Requirement
Can not detect Feeder cart(Block1).
Please set Feeder cart to the inside.[B0910, B0911]
030431 Operation Requirement
Can not detect Feeder cart(Block2).
Please set Feeder cart to the inside.[B0910, B0911]
030432 Operation Requirement
The connector of the feeder base (Block1) is not connected to the main body, so
that please connect it. [B0916]
030433 Operation Requirement
The connector of the feeder base (Block2) is not connected to the main body, so
that please connect it. [B0916]
030440 Operation Requirement
The Safety cover is open. Please close it.
030441 Operation Requirement
It is impossible to do Pass Operation without Cart because func of Traceability is
valid. Please restart after setting Option invalid.
030442 Operation Requirement
It cannot run because a simple Cover locked. First, set Stage ready OFF, then set
Stage ready ON.
030450 Operation Requirement
To run is impossible by start protect.
030451 Operation Requirement
Cannot start to run because the output folder on server is disconnected.
Please check output folder setting and the server status of output folder.
030501 Misidenticationatypeofmulti-tray
TheconnectedTrayunit(Block1)doesn'tmatchsettingsofDevice.Pleaseconrm
a type of tray unit, and set it on unit exchange screen.
4OM-1603
2-16
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030502 Misidenticationatypeofmulti-tray
TheconnectedTrayunit(Block2)doesn'tmatchsetupofDevice.Pleaseconrma
type of tray unit, and set it on Unit Exchange Screen.
030601 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block1) on Unit exchange
Screen.
030602 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block2) on Unit exchange
Screen.
030603 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
PleaseconrmthelocationofNozstockerofDevice(Block1).
030604 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
PleaseconrmthelocationofNozstockerofDevice(Block2).
030701 Conrmationof2DBarcodeData
MarkNo.ofOperatingParameter/2DBarCodedataisspeciedasAllSkip(0).
Please specify proper Mark No.
030801 Detect nozzle coming off multi-functional stocker
Machine (Block1) Detected that nozzle has come off the multi-functional stocker
of the 1st line.
030802 Detect nozzle coming off multi-functional stocker
Machine (Block1) Detected that nozzle has come off the multi-functional stocker
of the 4th line.
030803 Detect nozzle coming off multi-functional stocker
Machine (Block2) Detected that nozzle has come off the multi-functional stocker
of the 1st line.
030804 Detect nozzle coming off multi-functional stocker
Machine (Block2) Detected that nozzle has come off the multi-functional stocker
of the 4th line.
030901 Head nozzle dropped detect
Please lock the main safety cover. Please perform all-zeroing when the main
safety cover has already been locked.
050201 ConrmationofP.C.B.existence
Remove PCB from the conveyor. Please delete the PCB memory information on
the edit screen if it remains.
050202 ConrmationofP.C.B.existence
PCB is detected from Input position when Finish mode is set [Output].
Please PCB from conveyor.
050203 ConrmationofP.C.B.existence
PCB is detected from Output position when Finish mode is set [Input].
Please PCB from conveyor.
050204 ConrmationofP.C.B.existence
PCB is detected from Inlet sensor of input conveyor. Please remove PCB.
