4OM-1603

3-59

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

431809 Tray Feeder in advanced check error (Block1)

Tray Safety Cover(Lower) is open.

Please close Tray safety cover(Lower), and then press "READY" button, lock the

cover.

43180a Tray Feeder in advanced check error (Block1)

Feeder base is "Ready On"

PleaseconrmFeederCartsetcorrectly,andpressFeederBase"READY"

button.

43180b Tray Feeder in advanced check error (Block1)

No Magazine(Upper)

Please set Magazine(Upper).

43180c Tray Feeder in advanced check error (Block1)

No Magazine(Lower)

Please set Magazine(Lower).

43180e Tray Feeder in advanced check error (Block1)

Traverse axis Servo Alarm

-----

431810 Tray Feeder in advanced check error (Block1)

Elevator axis Servo Alarm

-----

431811 Tray Feeder in advanced check error (Block1)

Miss-Pickup comp. Detection 8mm[B15417]

-----

431812 Tray Feeder in advanced check error (Block1)

Miss-Pickup comp. Detection 14mm[B15418]

-----

431813 Tray Feeder in advanced check error (Block1)

Miss-Pickup comp. Detection 28mm[B15419]

-----

431814 Tray Feeder in advanced check error (Block1)

Pallet chuck is not shut

-----

431815 Tray Feeder in advanced check error (Block1)

The pallet Miss-Set was detected.

-----

431816 Tray Feeder in advanced check error (Block1)

Magazine(Lower) Rack Shutter on the operator side is open.

-----

431817 Tray Feeder in advanced check error (Block1)

Magazine(Lower) Rack Shutter on the side of Traverse is open.

-----

431818 Tray Feeder in advanced check error (Block1)

Magazine(Lower) is not done positioning yet.

PleaseconrmtheMagazinepositionandMagazinelocklever.

431819 Tray Feeder in advanced check error (Block1)

Elevator axis safety relay

-----

4OM-1603

3-60

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

43181a Tray Feeder in advanced check error (Block1)

Magazine(Upper) Rack Shutter on the operator side is open.

-----

43181b Tray Feeder in advanced check error (Block1)

Magazine(Upper) Rack Shutter on the Traverse side is open.

-----

43181c Tray Feeder in advanced check error (Block1)

Magazine(Upper) is not done positioning yet.

PleaseconrmtheMagazinepositionandMagazinelocklever.

43181d Tray Feeder in advanced check error (Block1)

Pick-up miss cmpnt detect

-----

431820 Tray Feeder in advanced check error (Block1)

Zeroing incomplete

-----

434001 Tray Feeder Sequence Error (Block1)

Tray feeder sequence timeout

-----

438302 Elevator Unit exchange (Attach) (Block1)

Elevator unit was not detected.

Please set up Tray Unit in Exchange location.

438303 Elevator Unit exchange (Attach) (Block1)

Connector of Feeder base is not positioned correctly

Please Operate it after connecting connector of Feeder Base.

438304 Elevator Unit exchange (Attach) (Block1)

Connector of Tray is not positioned correctly

Operate it after connecting connector of Tray.

438305 Elevator Unit exchange (Attach) (Block1)

Time-out of Clamp operating of Elevator Unit.

-----

438306 Elevator Unit exchange (Attach) (Block1)

Feeder base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

438402 Elevator Unit exchange (Detach) (Block1)

Time-out of Unclamp operating of Elevator Unit.

-----

438403 Elevator Unit exchange (Detach) (Block1)

Feeder base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

438405 Elevator Unit exchange (Detach) (Block1)

There were error when multi-tray receded.

-----

438406 Elevator Unit exchange (Detach) (Block1)

There were error when elevator1(Down) receded.

-----

4OM-1603

3-61

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

438407 Elevator Unit exchange (Detach) (Block1)

There were error when elevator2(Up) receded.

-----

438408 Elevator Unit exchange (Detach) (Block1)

There were error when traverse receded.

-----

438501 Multi-Tray (Block1)

Time-out of waiting for initialization
