4OM-1603
3-163
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
6b1091 Coplanarity System Error
Unsteady motor rotation in sensor. (1090)
Check the connection of the power cable for the sensor head.
6b1101 Coplanarity System Error
Laser OFF. (1100)
Error in Coplanarity Unit. Shut down the device, and turn it on again. Please
contact the service when not repaired even if turns it on again.
6b2001 Coplanarity Operation Error
-----
-----
6b2011 Coplanarity Operation Error
Wrong level adjustment. (2010)
There is a possibility of following error.
1. Coplanarity Unit
2. Data loss
3. Software Error
Shut down the device, and turn it on again. Please contact the service when not
repaired even if turns it on again.
6b2031 Coplanarity Operation Error
Wrong component no. (2030)
There is a possibility of following error.
1. Coplanarity Unit
2. Data loss
3. Software Error
Shut down the device, and turn it on again. Please contact the service when not
repaired even if turns it on again.
6b2041 Coplanarity Operation Error
Measurement Start Signal Not Recognized. (2040)
Check the coupling cable between the Coplanarity unit PC and the main machine.
(Measurement Start Signal)
6b2051 Coplanarity Operation Error
Illegal Command Parameter. (2050)
There is a possibility of following error.
1. Coplanarity Unit
2. Data loss
3. Software Error
Shut down the device, and turn it on again. Please contact the service when not
repaired even if turns it on again.
6b2061 Coplanarity Operation Error
Unknown Reference Component Data. (2060)
There is a possibility of following error.
1. Coplanarity Unit
2. Data loss
3. Software Error
Shut down the device, and turn it on again. Please contact the service when not
repaired even if turns it on again.
4OM-1603
3-164
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
6b2071 Coplanarity Operation Error
Improper Measurement Mode. (2070)
Make the measurement in the high accuracy mode.
6b3001 Coplanarity Check Error
Coplanarity Error! (3000)
Check for any bent terminals (vertically bent balls and leads).
6b3011 Coplanarity Check Error
Terminal Miss registration Error! (3010)
Check for the position and pitches of the terminals (balls and leads).
6b3021 Coplanarity Check Error
Terminal Detection Error! Wrong Measurement Data (Completely Dark Image).
(3020)
Check the component size and thickness data.
6b3031 Coplanarity Check Error
Terminal Detection Error! Error in Number of Extracted Terminals (labeling). (3030)
Check the size and pickup position of the component.
6b3041 Coplanarity Check Error
Terminal Detection Error! Terminal Allocation Error (Impossible Terminal
Arrangement Detection). (3040)
Check the component size and thickness data.
6b3061 Coplanarity Check Error
Terminal Detection Error! Edge Detection Error (Impossible Edge Detection of
Gauge during Installation Calibration). (3060)
Check the pickup condition of the calibration gauge and the installation of the unit.
6b3071 Coplanarity Check Error
Coplanarity Error! (3070)
-----
6b3081 Coplanarity Check Error
Impaired Terminal (Nicked) Error. (3080)
Check the position of the leads or the balls and the quantity data.
6b3091 Coplanarity Check Error
2pinTr Error! (ONE all NG)
Check the component size and thickness data.
6b30a1 Coplanarity Check Error
2pinTr Error! (PIN1 upper)
Check for any bent terminals (vertically bent leads).
6b30b1 Coplanarity Check Error
2pinTr Error! (PIN1 lower)
Check for any bent terminals (vertically bent leads).
6b30c1 Coplanarity Check Error
2pinTr Error! (PIN2 upper)
Check for any bent terminals (vertically bent leads).
6b30d1 Coplanarity Check Error
2pinTr Error! (PIN2 lower)
Check for any bent terminals (vertically bent leads).
1012-005
4OM-1603
3-165
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
6b3101 Coplanarity Check Error
Reference Plane Flapping Error. (3100)
Check the pickup surface and condition of the component.
6b3111 Coplanarity Check Error
Terminal Detection Error! Out of Edge Position Measurable Range ("Near" Side).
(3110)
Check the component thickness and Coplanarity unit height offset data.
6b3121 Coplanarity Check Error
Terminal Detection Error! Out of Edge Position Measurable Range ("Far" Side).
(3120)
Check the component thickness and Coplanarity unit height offset data.
6b3131 Coplanarity Check Error
Sampling Error ("DARK" Alarm). (3130)
Decrease the dark level (dlv) of the component library data.
6b3141 Coplanarity Check Error
Sampling Error ("BRIGHT" Alarm). (3140)
Decrease the laser power (lpw) of the component library data.
6b9001 Coplanarity System Error
System error. (9000)
Error in Coplanarity Unit. Shut down the device, and turn it on again. Please
contact the service when not repaired even if turns it on again.
