4OM-1603 2-8 2. Management Information : Chap.2 Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Information) 015007 Nozzle Location Che…

100%1 / 379
4OM-1603
2-7
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
013102 Feeder set Err
The feeder latch worked off. (Block1)
013103 Feeder set Err
A pickup miss comp is detected.(Block2)
013104 Feeder set Err
Feeder Latch worked off.(Block2)
013105 Feeder set Err
Not connect selected feeder.
013b01 Feeder Ready SW
Please wait stage ready on
013c01 Stage Ready SW
Please wait feeder ready on
013c02 Stage Ready SW
Do not open safety cover while line sensor program updating.
014101 Operation Parameter
Test mode of transfer set "Disable" in pass mode.
Check setting.
014102 Operation Parameter
Operation Mode both Lane A, B is [STOP]. Please execute after reset it.
014103 Operation Parameter
Operation Mode is set except [Placement]. Please set [Placement when do 1
Cmpnt placement.
014201 Device System Setup
Please set Input Machine Output Mode [SMEMA Mode].
014202 Device System Setup
Please set Output Machine Output Mode [SMEMA Mode].
014b01 Nozzle Placement Data Check
Current Program Data differs from Nozzle Arragement Data of Nozzle Stocker.
015001 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "HA09" nozzle as Nozzle1 on Head.
015002 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "HA09" nozzle as Nozzle1 on Head.
015003 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "HA09" nozzle on Head.
015004 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "HA09"nozzle on Head.
015005 Nozzle Location Check
"NotfoundttingnozzleforTeaching(Head1).
Set type "FF01"or "FF02" nozzle on Head.
015006 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "FF01"or "FF02" nozzle on Head.
1109-006
4OM-1603
2-8
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
015007 Nozzle Location Check
The different type nozzle is already set(Head1).
Please remove it.
015008 Nozzle Location Check
The different type nozzle is already set(Head2).
Please remove it.
015009 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
01500A Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
01500B Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "VF02" nozzle on calibrate position.
01500C Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "VF02" nozzle on Head.
01500D Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "HA09" or "VF02" nozzle on Head.
01500E Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "HA09" or "VF02" nozzle on Head.
01500F Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "HA09" nozzle in the stocker position where nozzle can change.
015010 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "HA09" nozzle in the stocker position where nozzle can change.
015011 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "FF01" or "FF02" nozzle in the stocker position where nozzle can
change.
015012 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "FF01" or "FF02" nozzle in the stocker position where nozzle can
change.
015013 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "BF02" nozzle in the stocker position where nozzle can change.
015014 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "BF02" nozzle in the stocker position where nozzle can change.
1109-006
4OM-1603
2-9
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
015015 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "FA04" nozzle in the stocker position where nozzle can change.
015016 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "FA04" nozzle in the stocker position where nozzle can change.
015017 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).Pleasesettype"BF02"or"HA09"
nozzle in the stocker position where nozzle can change.
015018 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).Pleasesettype"BF02"or"HA09"
nozzle in the stocker position where nozzle can change.
015101 Nozzle location teaching, check the position of nozzle on head
No found nozzle (Head1). Or, the different Nozzle could be arranged.
015102 Nozzle location teaching, check on the position of nozzle on head
No found nozzle (Head2). Or, the different Nozzle could be arranged.
015201 Teaching check the conveyor
No P.C.B. on Conveyor. Please put P.C.B. in.
015202 Teaching check the conveyor
Please set P.C.B. positioning. Please set it again after cancel positioning if P.C.B.
positioning is already done.
015203 Teaching check the conveyor
Please push Conveyor Width Moving.
015301 ODD Head Nozzle stocker check
There does not exist stocker that can replace nozzle (Block1).
015302 ODD Head Nozzle stocker check
There does not exist stocker that can replace nozzle (Block2).
016001 Tray teaching
Traverse of Tray is not drawn out (Block1). Draw out Traverse.
016002 Tray teaching
Tray Traverse is not drawn out (Block2). Draw out Traverse.
016101 Coplanarity Teaching
"Coplanarity Detection" of Test Operation Mode is set "No". Execute it after
cancelling Test Operation Mode.
016201 Coplanarity Test
Please pickup part.
017009 Teaching Check on the position of Glass jig
Not found Glass Jig for Teaching. Please check that Glass Jig is set in its position.
017201 Nozzle set-up (Block1)
Nozzle Placement/Store mode of Stocker(Block2) is not possible to operate.
Please specify Stocker(Block1).
017202 Nozzle set-up (Block1)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
