4OM-1603
3-131
3. Error IDs and Remedial Procedures : Chap.3
1109-006
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600101 P.C.B. recog camera & beam offset teach.
-----
-----
600102 P.C.B. recog camera & beam offset teach.
Error of Recognition Command response.
-----
600103 P.C.B. recog camera & beam offset teach.
Error of coordinates calculation.
-----
600104 P.C.B. recog camera & beam offset teach.
Error of Data set for XY Beam.
-----
600105 P.C.B. recog camera & beam offset teach.
Error of moving for XY Beam.
-----
600106 P.C.B. recog camera & beam offset teach.
Time-out in XY Beam
-----
600107 P.C.B. recog camera & beam offset teach.
Time-out of communication with recognition.
-----
600108 P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on parts recognition camera.
-----
600109 P.C.B. recog camera & beam offset teach.
Recognition failure of checker on reference pin.
-----
60010a P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on glass jig.
-----
600201 Comp. Recog. Camera offset teach.
Could not recognize the glass Jig.
PleaseconrmthatGlassJigissetonGlassJigplace.(Checkitbecausethereis
a possibility that nozzle is not on head, or vacuum is not "ON".)
600202 Comp. Recog. Camera offset teach.
The result of Teaching is out of permission values.
PleaseconrmwhetherGlassJigispicked-upcorrectlyornot.Pleaseadjustit
with Teach Plate Offset if not.
600203 Comp. Recog. Camera offset teach.
Error of Recognition command response.
-----
600204 Comp. Recog. Camera offset teach.
Error of coordinates calculation.
-----
4OM-1603
3-132
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
600205 Comp. Recog. Camera offset teach.
Error when Jig pickup started
-----
600206 Comp. Recog. Camera offset teach.
Error in the movement of Jig pickup
-----
600207 Comp. Recog. Camera offset teach.
Error when Jig began to be stored
-----
600208 Comp. Recog. Camera offset teach.
Error in the movement of Jig stored
-----
600209 Comp. Recog. Camera offset teach.
Error when HL-axis began to drop.
-----
60020a Comp. Recog. Camera offset teach.
Error when HL-axis began to rise.
-----
60020b Comp. Recog. Camera offset teach.
Error of Data set for XY Beam.
-----
60020c Comp. Recog. Camera offset teach.
Error of moving for XY Beam.
-----
60020d Comp. Recog. Camera offset teach.
Time-out of moving for XY Beam.
-----
60020e Comp. Recog. Camera offset teach.
Time-out of communication with recognition.
-----
600301 Head Rotate Theta Axis offset
Could not recognize Nozzle
PleaseconrmthatNozzleisplacedandexactNozzlearrangementdataisset.
600302 Head Rotate Theta Axis offset
Error of Recognition Command response.
-----
600303 Head Rotate Theta Axis offset
Could not recognize the section of nozzle shaft
-----
600304 Head Rotate Theta Axis offset
Error of coordinates calculation.
-----
600305 Head Rotate Theta Axis offset
Error when DD-axis began to rotate.
-----
4OM-1603
3-133
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
600306 Head Rotate Theta Axis offset
Error during rotation of DD-axis
-----
600307 Head Rotate Theta Axis offset
Error when HL-axis and NL-axis began zeroing
-----
600308 Head Rotate Theta Axis offset
Error while HL-axis and NL-axis on zeroing movement
-----
600309 Head Rotate Theta Axis offset
Error of Data set for XY Beam.
-----
60030a Head Rotate Theta Axis offset
Error of moving for XY Beam.
-----
60030b Head Rotate Theta Axis offset
Time-out in XY Beam movement
-----
60030c Head Rotate Theta Axis offset
Time-out of communication with recognition.
-----
60030d Head Rotate Theta Axis offset
Error when L-axis began zeroing
-----
60030e Head Rotate Theta Axis offset
Error of L-axis on zeroing
-----
60030f Head Rotate Theta Axis offset
Error when L-axis began to drop
-----
600310 Head Rotate Theta Axis offset
Error in L-axis dropped
-----
600311 Head Rotate Theta Axis offset
Time-out of the movement of L-axis, Z-axis
-----
600312 Head Rotate Theta Axis offset
Error when Z-axis began to move
-----
600313 Head Rotate Theta Axis offset
Error while Z-axis is moving
-----
600314 Head Rotate Theta Axis offset
-----
-----
