4OM-1603 2-35 3. Machine Information : Chap.2 Machine Information Code Display Area A (The outline of the Machine Information) Display Area B (The details of the Machine Information) 80c301 Multi-layered T ray Safety Cov…
4OM-1603
2-34
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c001 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Block1) Magazine1(Lower).Please
conrmthewiringofMachine
-----
80c002 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Block1) Magazine1(Upper).Please
conrmthewiringofMachine
-----
80c003 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Block2) Magazine2(Lower).Please
conrmthewiringofMachine
-----
80c004 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Block2) Magazine2(Upper).Please
conrmthewiringofMachine
-----
80c101 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Block1) Magazine1(Lower)
-----
80c102 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Block1) Magazine2(Upper)
-----
80c103 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Block2) Magazine1(Lower)
-----
80c104 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Block2) Magazine2(Upper)
-----
80c201 Multi-layered Tray ACV miss-placement error(Magazine)
Tray (Block1) Magazine1(Lower) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
-----
80c202 Multi-layered Tray ACV miss-placement error(Magazine)
Tray (Block1) Magazine2(Upper) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
-----
80c203 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Block2) Magazine1(Lower) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
-----
80c204 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Block2) Magazine2(Upper) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
-----
1109-006
4OM-1603
2-35
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c301 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Block1)
Magazine1(Lower).
-----
80c302 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Block1)
Magazine2(Upper).
-----
80c303 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Block2)
Magazine1(Lower).
-----
80c304 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Block2)
Magazine2(Upper).
-----
80c401 Nozzle Exchange
There are neither a free space nor a nozzle for nozzle exchange.
-----
80c402 Nozzle Exchange
There is no free space for Nozzle in Stocker.
Please take off unnecessary Nozzle from Stocker, and then update the nozzle
data.
-----
80c403 Nozzle Exchange
ODD Noz of Head is stored for storing high-speed Noz.
-----
80c404 Nozzle Exchange
Noz is stored due to error in teaching Noz Position.
-----
80c405 Nozzle Exchange
Please take down the nozzle stocker.
-----
80c406 Nozzle Exchange
A necessary nozzle is installed in the head that has not been selected. Please
select the back and forth block, and execute the nozzle exchange.
-----
80c501 Overall Setup(Exchange support pin)
Pattern Program data set the support pin as [No exchange], so that skipped it.
-----
80c502 Overall Setup(Exchange support pin)
Noz is not for Support Pin Exchange, so that it is stored.
-----
80c503 Overall Setup(Exchange support pin)
Noz for Support Pin Exchange on Head is not found.
-----
1109-006
4OM-1603
2-36
3. Machine Information : Chap.2
1109-006
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c504 Overall Setup(Exchange support pin)
Conveyor Width is stopped at the position for exchanging support pins because
the Support pins of Lane A are stored. Please take out Support pins from
machine, or install Conveyor Width after setting them at production position.
-----
80c601 Overall Setup(Conveyor width setup)
Pattern Program data set the conveyor width as [No Setup]. So that skipped it.
-----
80c701 Nozzle Level Offset Teaching
All E/NR from linear measure sensor is detected.
PleaseconrmitbecausethereisapossibilitythatODDNozisplaced.
-----
80c702 Nozzle Level Offset Teaching
Could not do Teaching because Noz for measurement on Head1 is not set.
-----
80c703 Nozzle Level Offset Teaching
Could not do Teaching because Noz for measurement on Head2 is not set.
-----
80c704 Nozzle Level Offset Teaching
The Length of measured Noz is out of Allowable Range.
PleaseconrmtheNozofHead.
-----
80c801 Cutter Auto Reset
Cutter Auto Reset of Device(Block1) is executed.(The 1st)
-----
80c802 Cutter Auto Reset
Cutter Auto Reset of Device(Block2) is executed.(The 1st)
-----
80c803 Cutter Auto Reset
Cutter Auto Reset of Device(Block1) is executed.(The 2nd)
-----
80c804 Cutter Auto Reset
Cutter Auto Reset of Device(Block2) is executed.(The 2nd)
-----
80c805 Cutter Auto Reset
Cutter Auto Reset of Device(Block1) is executed.(The 3rd)
-----
80c806 Cutter Auto Reset
Cutter Auto Reset of Device(Block2) is executed.(The 3rd)
-----
80e001 Noz Selection axis position offset teaching
The 1st Re-trial for Noz Selection axis position offset teaching started.
-----
80e002 Noz Selection axis position offset teaching
The 2nd Re-trial for Noz Selection axis position offset teaching started.
-----
