4OM-1603
3-99
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496801 Transit communication Error
Communication error occurred in the transfer section.
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496802 Conveyor Width W1-axis communication Error
Communication error occurred in the W1-axis transfer driver.
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496803 Conveyor Width W2-axis communication Error
Communication error occurred in the W2-axis transfer driver.
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496901 Conveyor Width-axis Time-out
Time-out of Zeroing
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496902 Conveyor Width-axis Time-out
Time-out
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496a01 Shuttle Conveyor Error (Input side)
The Cover of Shuttle Conveyor is open.
Please close the cover, and then operate. There is a possibility of Loose
Connection or Defect if the cover is close.
496a02 Shuttle Conveyor Error (Input side)
Emergency Stop of Shuttle Conveyor is detected.
Please cancel Emergency Stop, and then restart to operate again.
496a03 Shuttle Conveyor Error (Input side)
Zeroing of Shuttle Conveyor is not completed within predetermined time.
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496a04 Shuttle Conveyor Error (Input side)
Target Width Matching of Shuttle Conveyor is not completed within predetermined
time.
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
1109-006
4OM-1603
3-100
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496a05 Shuttle Conveyor Error (Input side)
Error of Motor communication.
Could not receive the instructions normally.
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(Breaker/24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496b01 Shuttle Conveyor Error (Output side)
The Cover of Shuttle Conveyor is open.
Please close the cover, and then operate.
There is a possibility of Loose Connection or Defect if the cover is close.
496b02 Shuttle Conveyor Error (Output side)
Emergency Stop of Shuttle Conveyor is detected.
Please cancel Emergency Stop, and then restart to operate.
496b03 Shuttle Conveyor Error (Output side)
Zeroing of Shuttle Conveyor is not completed within predetermined time.
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496b04 Shuttle Conveyor Error (Output side)
Target Width Matching of Shuttle Conveyor is not completed within predetermined
time.
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496b05 Shuttle Conveyor Error (Output side)
Error of Motor communication.
Could not receive the instructions normally.
1. Conrmconnectiontocommunicationcable.
2. ConrmPowersupply(Breaker/24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
497001 On manual operation Alarm
Zeroing Error
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
497002 On manual operation Alarm
Out-of-Control was detected.
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
497003 On manual operation Alarm
Error in Motor Power voltage
Motor power voltage dropped. Check out the Power supply line(48V Line)
497004 On manual operation Alarm
STP input was detected.
STP input is detected. The function to stop motor by Hard signal.
1109-006
4OM-1603
3-101
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
497005 On manual operation Alarm
Over-current
Error in Motor output line. Check out the motor wiring,
497006 On manual operation Alarm
Limit Sensor(+) was detected.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
497007 On manual operation Alarm
Limit Sensor(-) was detected.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
497008 On manual operation Alarm
Motor disconnection was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
497009 On manual operation Alarm
Error in Control Power Voltage
Control power for driver dropped. Check out the Power supply line.(24V Line)
49700a On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700b On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700c On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700d On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700e On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700f On manual operation Alarm
System Error
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
497101 Before setup P.C.B. detected
PCB was detected on Input conveyor.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. PleaseconrmthatP.C.B.isexistinginMachine.
497102 Before setup P.C.B. detected
PCB was detected on Positioning Conveyor(Input position)
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. PleaseconrmthatP.C.B.isexistinginMachine.
