4OM-1603

3-70

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

44180a Pre-check Error of Tray Feeder (Block2)

Feeder base is "Ready On"

PleaseconrmFeederCartsetcorrectly,andpressFeederBase"READY"

button.

44180b Pre-check Error of Tray Feeder (Block2)

No Magazine(Upper)

Please set Magazine(Upper).

44180c Pre-check Error of Tray Feeder (Block2)

No Magazine(Lower)

Please set Magazine(Lower).

44180e Pre-check Error of Tray Feeder (Block2)

Traverse axis Servo Alarm

-----

441810 Pre-check Error of Tray Feeder (Block2)

Elevator axis Servo Alarm

-----

441811 Pre-check Error of Tray Feeder (Block2)

Miss-Pickup comp. Detection 8mm[B15417]

-----

441812 Pre-check Error of Tray Feeder (Block2)

Miss-Pickup comp. Detection 14mm[B15418]

-----

441813 Pre-check Error of Tray Feeder (Block2)

Miss-Pickup comp. Detection 28mm[B15419]

-----

441814 Pre-check Error of Tray Feeder (Block2)

Pallet chuck is not shut

-----

441815 Pre-check Error of Tray Feeder (Block2)

The pallet Miss-Set was detected.

-----

441816 Pre-check Error of Tray Feeder (Block2)

Magazine(Lower) Rack Shutter on the operator side is open.

-----

441817 Pre-check Error of Tray Feeder (Block2)

Magazine(Lower) Rack Shutter on the Traverse side is open.

-----

441818 Pre-check Error of Tray Feeder (Block2)

Magazine(Lower) is not done Positioning yet.

PleaseconrmtheMagazinepositionandMagazinelocklever.

441819 Pre-check Error of Tray Feeder (Block2)

Elevator axis safety relay

-----

44181a Pre-check Error of Tray Feeder (Block2)

Magazine(Upper) Rack Shutter on the operator side is open.

-----

1109-006

4OM-1603

3-71

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

44181b Pre-check Error of Tray Feeder (Block2)

Magazine(Upper) Rack Shutter on the Traverse side is open.

-----

44181c Pre-check Error of Tray Feeder (Block2)

Magazine(Upper) is not done Positioning yet.

PleaseconrmtheMagazinepositionandMagazinelocklever.

44181d Pre-check Error of Tray Feeder (Block2)

-----

441820 Pre-check Error of Tray Feeder (Block2)

Zeroing incomplete

-----

444001 Tray Feeder Sequence Error (Block2)

Tray feeder sequence timeout

-----

448302 Elevator Unit Exchange (Attach) (Block2)

Elevator Unit is not detected.

Please set up Tray Unit in Exchange location.

448303 Elevator Unit Exchange (Attach) (Block2)

Connector of Feeder base is not positioned correctly.

Please Operate it after connecting connector of Feeder Base.

448304 Elevator Unit Exchange (Attach) (Block2)

Connector of Tray is not positioned correctly.

Operate it after connecting connector of Tray.

448305 Elevator Unit Exchange (Attach) (Block2)

Time-out of Clamp operating of Elevator Unit.

-----

448306 Elevator Unit Exchange (Attach) (Block2)

Feeder Base is not in Upward position.

Please set Feeder Cart, and then press READY switch to rise it on Feeder Base.

448402 Elevator Unit Exchange (Detach) (Block2)

Time-out of Unclamp operating of Elevator Unit.

-----

448403 Elevator Unit Exchange (Detach) (Block2)

Feeder Base is not in Upward position.

Please set Feeder Cart, and then press READY switch to rise it on Feeder Base.

448405 Elevator Unit Exchange (Detach) (Block2)

There were error when multi-tray receded.

-----

448406 Elevator Unit Exchange (Detach) (Block2)

There were error when elevator1(Down) receded.

-----

448407 Elevator Unit Exchange (Detach) (Block2)

There were error when elevator2(Up) receded.

-----

1109-006

4OM-1603

3-72

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448408 Elevator Unit Exchange (Detach) (Block2)

There were error when traverse receded.

-----

448501 Multi-Tray(Block2)

Time-out of waiting for initialization
