4OM-1603 4-2 2. Recognition Error IDs and Controlled Areas : Chap.4 2. Recognition Error IDs and Controlled Areas Basic System of Recognition Error IDs An error ID is expressed by 8 digits (hexadecimal) as follows. Z A B…
4OM-1603
4-1
1. Description of Recognition Error ID (Example) : Chap.4
1012-005
1. Description of Recognition Error ID (Example)
[1]
[2]
Recognition Error ID Description of Recognition Error
050**001 Component was not found.
051**001 Component was not detected.
T4D1
[1] Recognition Error ID
The recognition error IDs (IDs displayed in the "ERROR" window) are
described in the numerical order.
[2] Description of Recognition Error
Described are the contents of a recognition error that will be displayed in the
"ERROR" window.
4OM-1603
4-2
2. Recognition Error IDs and Controlled Areas : Chap.4
2. Recognition Error IDs and Controlled Areas
Basic System of Recognition Error IDs
An error ID is expressed by 8 digits (hexadecimal) as follows.
Z A B CC DDD
Detailed Classification
Small Classification
Middle Classification
Large Classification : Classification based on individual
recognition functions
Classification Criteria : Distinction between Recognition
System and Ordinary Errors
ClassicationCriteria
ClassicationCriteria ClassicationofRecognitionFunctions
0 Ordinary Errors
1 Recognition System Errors
T4D2
LargeClassication
ClassicationCriteria ClassicationofRecognitionFunctions
0 Recognition Internal Errors
1 Recognition Communication Errors
2 Recognition Communication Errors
5 Component Recognition Errors
6 PEC Recognition Errors
7 Nozzle Recognition Errors
8 Character Recognition Errors
9 Bad Mark Detection Errors
a Recognition Teaching Errors (Reserved)
b
Component Library
Teaching Function Errors
c 2D Barcode Errors
d Support pin Detection Errors
f Vision System Start-up Errors
T4D3
1012-005
4OM-1603
4-3
3. Recognition Error IDs and Remedial Procedures : Chap.4
3. Recognition Error IDs and Remedial Procedures
Z A B CC DDD
Detailed Classification: Detailed Classification
Small Classification: Small Classification
Middle Classification: Middle Classification
1: Error in Recognition internal
2: Error in Recognition internal
3: Error in Recognition internal
4: Error in Recognition internal
Large Classification
Classification Criteria
Notice
Recognition Internal Error !
In normal cases, this is not issued outside.
Recognition Error ID Description of Recognition Error
00000000 Error in Recognition internal.
10000000 Error in Recognition internal.
01000000 Error in Recognition Communication Data
11000000 Error in Recognition Communication Data
02100000 Error in Recognition Communication Data
02200301 "Mark Size D1" is small.
02200302 "Mark Size D1" is big.
02200303 "Window Size" is smaller than "Mark Size".
02200304 "Mark Size D2" is big, compared with "D1".
02200305 "Mark Size D2" is not set.
02200501 The total of "Corner 1 Dim X" and "Corner 4 Dim X" is larger than "Mold Size X".
02200502 The total of "Corner 1 Dim Y" and "Corner 2 Dim Y" is larger than "Mold Size Y".
02200503 The total of "Corner 2 Dim X" and "Corner 3 Dim X" is larger than "Mold Size X".
02200504 The total of "Corner 3 Dim Y" and "Corner 4 Dim Y" is larger than "Mold Size Y".
02200505 Device Size is small.
02200506 Device Size is big.
02200507 The component cannot be recognized in the "Back Lighting" system because the
component size is big.
02200508 component's thickness is large
02200509 The number of effective corners is small.
0220050a No effective combination of edges is found.
02200601 "# of Groups" (lead data) is improper.
02200602 The total of "# of Leads" (lead data) is small.
02200603 No detection is set in all "Insp Condtn" text boxes.
02200611 "Lead Pitch" in "Lead Group 1" is smaller than "Lead Width".
02200612 "Lead Pitch" in "Lead Group 2" is smaller than "Lead Width".
02200613 "Lead Pitch" in "Lead Group 3" is smaller than "Lead Width".
02200614 "Lead Pitch" in "Lead Group 4" is smaller than "Lead Width".
