4OM-1603 2-29 3. Machine Information : Chap.2 Machine Information Code Display Area A (The outline of the Machine Information) Display Area B (The details of the Machine Information) 800807 Start Auto Recovery Mode Comp.…
4OM-1603
2-28
3. Machine Information : Chap.2
1109-006
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
800618 Alternated Feeder
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
-----
800619 Alternated Feeder
Alarm Code:E2 - Origin Position Checking Error (Excessively out of the origin
during servo ON)
-----
80061a Alternated Feeder
Alarm Code:E3 - (1)No supplied history/ (2)Dirty splicing detection sensor (dust
adhesion)
-----
80061b Alternated Feeder
Alarm Code:E4 - Positioning Completion Timeout (Foreign substances in the
sprocket wheel)
-----
80061c Alternated Feeder
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
-----
80061d Alternated Feeder
Alarm Code:E6 - Lane Change Timeout Error
-----
80061e Alternated Feeder
Alarm Code:E7 - Servo ON Timeout
-----
80061f Alternated Feeder
Obverse/Reverse inspection detect (Sensor)
-----
800801 Start Auto Recovery Mode
Shortage of component
-----
800802 Start Auto Recovery Mode
Splice waiting
-----
800803 Start Auto Recovery Mode
Comp. Vertical(Sensor)
-----
800804 Start Auto Recovery Mode
Comp. Thickness(Sensor)
-----
800805 Start Auto Recovery Mode
Comp. Missing (Sensor)
-----
800806 Start Auto Recovery Mode
Comp. Recog. Error(recog.)
-----
4OM-1603
2-29
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
800807 Start Auto Recovery Mode
Comp. Missing (Recog)
-----
800808 Start Auto Recovery Mode
Coplanarity Check Error
-----
800809 Start Auto Recovery Mode
Feeder Alarm
-----
80080a Start Auto Recovery Mode
Feeder unloading
-----
80080b Start Auto Recovery Mode
Device Op is stopped because Feeder is not loaded.
-----
80080c Start Auto Recovery Mode
Etc
-----
80080d Start Auto Recovery Mode
Obverse/Reverse inspection error(Sensor)
-----
800902 Alarm for Shortage of Comp.
Few components to feed.
-----
801101 Nozzlediameterconrmation
The disagreement of the nozzle diameter was detected with the linear measure.
Thereisapossibilityofthelinearmeasuredirtandthenozzledirt,pleaseconrm
whether a different nozzle has adhered.
-----
801b01 Lightning Surge alarm
Lightning Surge Protector works; Q204.
-----
801b02 Lightning Surge alarm
Lightning Surge Protector works; Q204. Running continue.
-----
801b03 Lightning Surge alarm
Protective Fuse error of lightning Surge Protector. Exchange the fuse.
-----
801c05 Information
Warm start mode was canceled.
-----
801c06 Information
The machine stopped by the automatic stop function.
-----
1109-006
4OM-1603
2-30
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
801c07 Information
The machine will be stopped by start protect.
-----
802001 Alarm for Splicing
The feeder is running short of the component to feed.
Please prepare for Splicing, and remove the cover tape from the storage section.
-----
802101 Feeder Maintenance alarm
The total number of feeder's shots reached a previous notice setting number.
-----
802102 Feeder Maintenance alarm
The feeder adsorption rate decreased and exceeded the previous notice setting
number.
-----
802201 ACV Information
ACVCheckError.ComponentIDonthefeederisnotsameasonespeciedby
current program.
-----
802202 ACV Information
Device(Block1) Cannot clear Clamp for feeder communication. Please operate it
again later.
-----
802203 ACV Information
Device(Block2) Cannot clear Clamp for feeder communication. Please operate it
again later.
-----
802204 ACV Information
Device(Block1) Cannot clear Clamp for receiving the result of ACV Check Error.
Please operate it again later.
-----
802205 ACV Information
Device(Block2) Cannot clear Clamp for receiving the result of ACV Check Error.
Please operate it again later.
-----
802206 ACV Information
Device(Block1) Time-out for receiving the result of ACV Check Error.
Please take out Feeder and then take it in again.
-----
802207 ACV Information
Device(Block2) Time-out for receiving the result of ACV Check Error.
Please take out Feeder and then take it in again.
-----
802208 ACV Information
Device(Block1) Time-out of Feeder communication.
Please take out Feeder and then take it in again.
-----
