2. Hierarchical Structure of Data Edit Menus
Data editing is described along with the following hierarchical structure.
The numbers in ( ) show item Nos. to be referred to.
Pattern Program
Component
Library Data
Device Data
(Section 3)
Operation Data
Placement Data
• P.C.B. TRANSFER MODE SET-UP
• MACHINE COMMUNICATION
ADDRESS SET-UP
• TRAY MATRIX MODE
Auto Operation
Set-Up
(P.E.C. MARK DATA EDIT)
(2.3.3 in Section 2)
Offset Data
Test Mode
Nozzle Stocker
Data
Nozzle Library
Info.
(2.3 in Section 2)
Component Data
• TAPE A / B
• VIB. STICK A / B
• TRAY L / R
• PLACEMENT DATA (P) U01
• PLACEMENT DATA (O) U01
• PLACEMENT DATA (V) U01
(PLACE. DATA UNIT EDIT)
(4.7 in Section 2)
(USED NOZZLE
INFORMATION)
(2.1.3 in Section 2)
(Section 4)
• PU CORR/MAINT CY ALM
• RECOG ERR IMAGE SAVE SET-UP
• AUTOMATIC TUNING
(Section 5)
(Section 6)
• DEVICE OFFSET
• FEEDER (A) OFFSET
• FEEDER (B) OFFSET
• HEAD MASTER OFFSET
• HEAD OFFSET
• HEAD CENTER OFFSET
• NOZZLE STOCKER OFFSET
• CAMERA REFERENCE GAIN/LEVEL
• COMP. RECOG CAMERA OFFSET
• P.E.C. RECOG CAMERA OFFSET
• COMP. RECOG BRIGHTNESS
• OFFSET TEACHING BRIGHTNESS
• ROOM TEMPERATURE AT LTG TEACHING
• TRAY FEEDER OFFSET
• COMPONENT REJECT OFFSET
• OFFSET TEACH
• HEAD OFFSET (GET BOTH IMAGE)
• V. BEND DETECTION (Option)
(Section 7)
(Section 8)
• NOZZLE ID LIST
• DELETE NOZZLE
• SEARCH NOZZLE
• DATA EDIT
(Section 2)
(COMPONENT LI-
BRARY)
• PROGRAM CHANGE
• PROGRAM CHECK
• PROGRAM DELETE
• USED NOZZLE
INFORMATION
• PROGRAM EDIT
• DELETE COMPONENT
• SEARCH COMPONENT
• EDIT DATA
(2.4 in Section 2)
(2.5 in Section 2)
(2.6 in Section 2)
Set-Up Data
2. Hierarchical Structure of Data Edit Menus
