2-4
2
Basic operation
Code Error name and description
Ea02779
BNC NOZZLE STORE ERROR
State
Failed to store a nozzle from the nozzle station.
Since the vacuum level of the head is larger than the Shaft Release Level, the machine cannot be confirmed
to store a nozzle.
Cause
1. The head was not able to store a nozzle.
2. Although the head has stored a nozzle, the vacuum level is larger than the Shaft Release Level.
Action
1. Please adjust the height, angle and position data of the nozzle station.
2. Please adjust the [VmSpec] - [Machine Data] - [Head] - [Vacuum Level] - [Shaft Release Level].
Ea02906
NOZZLE CHANGE STATUS ERROR
State
The specified nozzle on this head is impossible. Please make sure the following item:
- Status of Nozzle Station.
Cause Cannot identify the currently attached ANC nozzle.
Action Check the nozzle station sensor status.
Ea07563
Shaft Cleaning Blow Nozzle Misplaced Error.
State Could have been out of nozzle from head, when execute shaft clean blow.
Cause No nozzle can be detected at the head.
Action
Each head at the above table, check the following contents.
- That it is not left behind the nozzle to blow unit.
- Come away the nozzle from the head, fell in the machine or not.
- Do not under-take the nozzle from the head.
Ea29528
INTERLOCK ERROR
State Failed to move the scan axis (SC-axis).
Cause
The scan axis (SC-axis) cannot be moved since the head lowers to a height where it interferes with the scan
camera.
Action Execute the reset and restart the work.
2-5
2
Basic operation
n
Conveyor-related errors
Code Error name and description
Ea00070
BOARD TRANSFER ERROR
State Even when the board request signal was not output, the entrance sensor detected the board.
Cause
1. Boards exceeding the specified number of boards were inserted.
2. I/O board or sensor malfunctioned.
Action
1. Remove the boards that were inserted.
2. Use the conveyor motor or I/O monitor to check the sensor response status.
Ea00851
INTERLOCK ERROR
State Transfer axis up/down sensor is OFF. Remove the cause of this sensor being OFF.
Cause Board conveyor unit is left lowered, or sensor error occurred.
Action Check the conveyor unit for up/down movement.
Ea02204
BOARD TRANSFER ERROR [CARRY-IN PROCESS TIMEOUT]
State Board to be carried in was lost.
Cause
Board may exist around the entrance/exit area of the conveyor of the upstream machine or the conveyor
entrance of this machine.
Action Set the board at the proper position to restore the operation.
Ea07319
Remove the Board at the Entrance
State The conveyor entrance sensor responds.
Cause Unclear board was detected at the entrance position.
Action Remove the board and restart the operation.
Ea07876
CAN NOT EXECUTE COMMAND
State
Failed to execute this command, because the push-up unit's position is not enough low. Please execute this
command after moving it down again,
Cause Unable to run this command since servo push-up is not sufficiently lowered.
Action Lower the servo push-up by conveyor unit operation or reset, then re-run this command.
Ea29701
PUSH UP PIN INTERLOCK ERROR
State The push-up pin was detected.
Cause The push-up pin was detected in the AT-axis movement rage of the push-up plate.
Action Remove unnecessary push-up pins, etc. from the push-up plate.
Ea29717
Ea29718
Ea29719
Ea29720
PIN PUSH-UP PIN INTERLOCK ERROR
State
The push-up pin interfered with the conveyor rail of the stage *.
(The target stage number is displayed in the "*" portion.)
Cause As the push-up pin position on the push-up plate was inappropriate, the push-up axis could not move up.
Action Remove the push-up pin and check the conveyor rail.
2-6
2
Basic operation
n
Data-related errors
Code Error name and description
Ea00036
VACUUM LEVEL ERROR
State Vacuum level has not reached the specified level. The component might have dropped after recognition.
Cause
Pickup vacuum pressure is not appropriate, or component is not correctly picked up. Component pickup
position coordinate is inaccurate or pickup accuracy is poor.
Action
Make adjustment so that the component is picked up properly, then readjust the pickup vacuum pressure in
Adjust mode.
Ea00267
FIDUCIAL FINE CORRECTION ERROR
State
Failed to adjust the XY position for FINE mode within limit. The limit is specified as FINE mode in machine
data.
Cause Correction range is too narrow.
Action Widen the correction range.
Ea00502
DATA READING ERROR
State Failed to read data.
Cause File may be destroyed.
Action Relevant data cannot be loaded. If backup data is available, copy and load it.
Ea02702
NOZZLE STATION MACS ERROR
State Failed to execute Nozzle Station MACS. Please check the machine data, and mark data in mark database.
Cause Failed to recognize marks while recognizing nozzle station MACS to perform a nozzle change.
Action Correct the positions of nozzle station MACS, or set the correct mark database No.
Ea30100
Feed Not Completed
State Feeder could not finish feeding parts when the head reaches parts.
Cause Feeder Set Pos 0
Action Please confirm whether never to hinder the feeding operation.
n
Component supply unit-related errors
Code Error name and description
Ea09657
cATS UNCLAMP ERROR
State The carriage clamp switch was OFF.
Cause cATS cannot be unclamped with the carriage switch.
Action Return the clamp switch to its original state.
Ea29259
Upper Guide Rail Cover Open
State The upper guide rail cover was open, it changed into the emergency stop state.
Cause The feeder cart upper guide rail cover is not properly closed.
Action Please close the upper guide rail cover on the front.
Ea30106
Feeder Control Board Detection Error.
State Feeder control board could not be detected.
Cause Normal feeder cart communication is not possible because the cart is improperly connected (docked).
Action
Please confirm the state of electric contact of the feeder cart.
The feeder cart state can be confirmed from feeder cart LED.
When this error occurs repeatedly, the breakdown of the feeder cart board is thought.
