A-1

Appendix

A1. Specifications

YSM20R/YSM20WR specifications

Item Specifications

Operating ambient temperature

Function guaranteed: 15 to 35°C

Accuracy guaranteed: 20 to 28°C

Operating ambient humidity 20 to 80% (no condensation), optimal range: 50 to 60%

Noise level Under 78dB

Power requirement (voltage and frequency) 3-phase AC 200/208/220/240/380/400/416 V +/- 10%, 50/60 Hz

Power capacity 10.4kVA

Average power consumption

YSM20R

TypePV: 1.9kW

TypeSV: 1.8kW

YSM20WR 1.9kW

Power cable (conductor cross-section area) 6 mm

or more

Overvoltage category *

Category III

Pollution degree *

Degree 2

Supply air pressure *

0.45MPa or more

Air consumption (ANR) *

YSM20R

HM head (1-beam) : 130L/min (average); 290L/min (max.)

HM head (2-beam) : 240L/min (average); 340L/min (max.)

FM head (1-beam) : 80L/min (average); 280L/min (max.)

FM head (2-beam) : 140L/min (average); 320L/min (max.)

YSM20WR

HM head (2-beam) : 240L/min (average); 340L/min (max.)

FM head (2-beam) : 140L/min (average); 320L/min (max.)

Altitude 1000 m or less above sea level

Board transport height *

900 mm +/- 10 mm

Data

Number of mounting

points *

12,800 points

Number of component

types

255 types per board

Number of fiducial

marks *

128 sets per board

*1: Conforms to IEC60664-1.

*2: For air dryer. Cleaning air filters. To be dry. Set pressure to 0.40 MPa.

*3: Distance from the floor surface to the upper surface of conveyor belt.

*4: Decreases with the number of boards, blocks and fiducial marks.

*5: When using 2-point fiducial mode.

*6: If the machine is equipped with tray component supply unit (option), add the air consumption of 10 L/min (ANR)

for each.

If the machine is equipped with an ionizer (option), add the air consumption of 10 L/min (ANR) per ionizer.

NOTE

See speciﬁcation sheets for more detailed information not listed above.

S-1

INDEX

Index

Safety instructions

Cautions during power outages xvi

Cautions regarding ferromagnetic ﬁelds xvi

CE marking i

Handling batteries xx

Handling grease and oil xx

Handling heavy objects xx

Handling solvents xix

Handling the laser xix

Label positions iv

Locking out switches xv

Muzzle plate xviii

Operator and service personnel xv

Safety xiv

Safety message xxi

Warning labels ii

Adjusting board hold plate position 3-15

Air connection port 1-5

Axis 2-19

[Axis] button 2-16

Axis conﬁguration 1-59

X/Y axis and conveyor axis conﬁguration 1-61

Before operation 2-1

Block Skip function

[Block Skip] button 2-12,3-34

Blow station 1-16

[Board Clamp] button 2-18

Board clamping method 3-8

Board position in machine by conveyor

type/board size 1-54

Buttons and parameter input boxes 2-10

Buzzer 1-5

Carriage clamp switch 1-9

Changing conveyor width 3-9,3-10

Check cleanness on nozzle tips 3-25

Checking condition of clamping the

board 3-19

Clearing an error 2-2

Component supply section 1-25

Component tape feed pitch 2-56

Feeder setup 2-58

Conﬁrming nozzles 3-24

Connection between machines 1-6

[Convey Board] button 2-17

[Convey In] button 2-14

Conveyor unit 1-40

YSM20R Dual-stage type 1-40

YSM20R Single-lane L = 360 mm type 1-42

YSM20R Single-lane L = 510 mm type 1-43

YSM20WR Dual-lane L = 360 mm type 1-44

YSM20WR Dual-lane L = 510 mm type 1-45

YSM20WR Single-lane (for transferring heavy

board) 1-46

Conveyor unit setup 3-8

[Convey Out] button 2-14

[Convey-out Stop] button 2-12,3-29

Coplanarity checker 1-64,2-41

[Current Nozzles] button 2-19

[Cycle Stop] button 2-12,3-29

Detaching component tape 2-68

Displaying the production monitors 2-22

Disposing of used carrier tape 2-64

Disposing of used cover tape 2-62

Edge clamp 3-8

Edge delamination (cover tape) 2-44

Emergency stop

Canceling emergency stop 2-1

Empty tape dust box 1-28,2-64

Ending production 3-29

[Entrance Stopper] button 2-18

Error screen 2-11

Exchanging magazine 2-78

Exchanging pallet 2-82

[Exit Stopper] button 2-17

Feeder exchange carriage 1-29

[Feeder Information] button 2-20

Feeder removing conditions 1-34

Feeder set position

Air connector 1-27

Harness connector 1-27,1-31

Power connector 1-27,1-31

[Feeder Setting] button 2-20

Flow from starting up machine to

production 3-1

Handling the pallet 2-71,2-73

Head unit 1-10

FM Head unit 1-12

HM Head unit 1-11

Head unit axis conﬁguration 1-59

How to check the sensor addresses 1-48

Input/output signals between machines

1-6

Ionizer 1-65

Ionizer installation angle 1-66

Keyboard 1-8

Lane switch 1-9

[Lane switch] button 2-14

Laying out push-up pins 3-9

[Machine] button 1-21,3-26

Machine layout 1-25

Machine main unit 1-1

Names and functions of major parts 1-1

Main menu button area 2-8

Main stopper 3-11

[Main Stopper] button 2-17,3-11

Main switch 3-3

Manual conveyor operation 2-14,2-17

Manual feeder operation 2-20

Manual head operation 2-19

Manual I/O operation 2-21

Monitor

Alignment screen 2-28

Badmark screen 2-31

Fiducial screen 2-30

Force screen 2-34

Main screen 2-24

Nozzle health check screen 2-39

Pick Pos. 2-32

Pick Rate Warning screen 2-35,2-36

Production screen 2-22

Retry screen 2-29

Schedule task screen 2-38

Vision screen 2-26

[Monitor] button 2-22

Multi-view camera 1-58

Names of each section of magazine 2-72

Names of each section of pallet 2-71

Non-stop feeder change 1-32

[Nozzle Change] button 2-19

Nozzle health check 2-39

Nozzle shaft blow

Automatic nozzle shaft blow procedure 1-21

Manual nozzle shaft blow procedure 1-17

Nozzle station 1-14

Nozzle types 1-13

S-2

INDEX

[Off] button 3-30

Operation panel and data input unit 1-7

Operation panel buttons 1-9

[ACTIVE] button 1-9

[EMERGENCY STOP] button 1-9,3-29

[ERROR CLEAR] button 1-9

[READY] button 1-9

[RESET] button 1-9

[START] button 1-9

[STOP] button 1-9

Operation screen 2-8

[Operator] button 3-4

[Origin] button 2-12

Password 3-5

Pick Rate Warning 2-35

Pickup position offset 2-32

Powering off the machine 3-30

Power switch 1-3

Pre-operation check 3-2

Preparing component tape 2-42,3-21

Preparing tray component supply unit

3-22

Pressing [Feeder Remove] button 1-35

Pressure gauge 1-5

[Push Up] button 2-18,3-11

Recognition unit 1-56

Fiducial camera 1-56

Scan camera 1-56

Side-view camera 1-56

Reel holder 1-28

[Required Nozzles] button 2-12,3-24

[Required Parts] button 2-12,3-21

[Required Parts] screen 3-21

Resuming operation from the stopped

point 3-32

[Halfway Continue] button 2-12,3-32

Return-to-origin 3-3

Safety cover 1-3

Schedule Speciﬁcation 1-21

Schedule task 2-38

Selecting the board data 3-7

Selecting the operator 3-4

Sensor layout of conveyor unit 1-47

[Sensor Tune] button 2-18

Set air pressure 1-5

Setting alternative component function

1-36

Setting component tape 2-42

Setting feeders on the feeder exchange

carriage 2-49

Setting "Skip Retry" 1-34

Setting the component trays on the pallet

2-73

Setting the Nozzle Tip Cleanliness Check

3-26

Setting the number of pallets to be stored

2-74

Setting the operation speed 3-28

Setting the pallet in the magazine 2-76

Setting tray components on pallet 2-71

Setup screen 2-12

Set-up station 1-3

70-reel ﬁxed feeder bank 1-27

Side-view function 1-57

Signal light 1-5,3-3

Starting and ending the tray component

supply unit 2-70

Starting production 3-28

Starting the machine 3-3

Status area 2-8

[STOP] button 3-29

Submenu button and parameter area 2-8

Switching the language 2-11

[Tip Cln Check] button 2-12,3-25

[TrayCnt] button 2-12,3-22

Tray component supply unit 1-39

cATS10 1-39

sATS30 1-39

sATS30NS 1-39

Tray Counter

“ATS Supp.” screen 3-22

“Tray” screen 3-23

Typical errors 2-3

Unit screen 2-14

UPS (Uninterruptible Power Supply) 1-68

USB ﬂash drive port 1-4

Warm-up 3-6

[Warm Up] button 2-12,3-6

Watch-and-wait mode 2-37

[Width] button 2-12,2-15

Working Ratio 2-25
