Machine Operation Manual
Revision L /
February 2020
Page 138 of 200
PathMaster 1.5 and Pre 1.5 Projects
PathMaster® 1.5 and earlier projects can be imported into the current version of
PathMaster®.
1. Select
File -> Import -> Project -> PathMaster 1.5 or Pre PathMaster 1.5
option from
the main menu.
2. When the file dialog box opens, select the location and the file name of the project
to import.
3. Select “Open”.
NOTE: You may need to change the file filter (type) to *.txt, or *.dmc to see the project file
in the dialog box.
PathMaster PRJBCK Files
PathMaster® Project Backup files (PRJBCK) can be imported and exported.
To Import
1. Select
File -> Import -> Project -> Project File (PRJBCK)
option from the main menu.
2. When the file dialog box opens, select the location and the file name of the project
to import.
3. Select “Open”.
To Export
1. Select
File -> Export -> Project - > Project File (PRJBCK)
option from the main menu.
2. When the dialog box appears, select a location and file name for the program.
3. Select “Save”.
Text File
A correctly formatted tab delimited text file can be imported into PathMaster® as a path
program. PathMaster® can also export text files.
To Import
1. Select
File -> Import -> Program -> Text File
option from the main menu.
2. When the file dialog box opens, select the location and the file name of the project
to import.
3. Select “Open”.
A text file program is typically a file that was exported as a text file from PathMaster®.
NOTE: You may need to change the file filter (type) to *.txt to see the project file in the
dialog box.
Machine Operation Manual
Revision L /
February 2020
Page 139 of 200
To Export
1. To export a program to a tab delimited text file, select
File -> Export -> Program ->
Text File
option from the main menu.
2. When the dialog box appears, select a location and file name for the program.
3. Select “Save”.
DMC File
A correctly formatted DMC file can be imported into PathMaster® as a path program.
PathMaster® can also export DMC files.
To Import
1. Select
File -> Import -> Program -> DMC File
option from the main menu.
2. When the file dialog box opens, select the location and the file name of the project
to import.
3. Select “Open”.
NOTE: You may need to change the file filter (type) to *.dmc to see the project file in the
dialog box.
To Export
1. Select
File -> Export -> Project - > DMC File or Compressed DMC File
from the main
menu.
2. When the dialog box appears, select a location and file name for the program.
3. Select “Save”.
Compressed DMC Machine File
All of a workcells project files can be exported to compressed DMC Files.
1. Select
File -> Export -> Machine - > Compressed DMC File
from the main menu.
2. When the dialog box appears, select a file folder location.
3. Select “Save”.
Machine Operation Manual
Revision L /
February 2020
Page 140 of 200
Subroutine
A correctly formatted subroutine can be imported into PathMaster® with the import
subroutine option. PathMaster® can also export subroutines.
To Import
1. Select
File -> Import -> Subroutine -> Text File
option from the main PathMaster®
menu or the
File -> Import subroutine
option from the subroutine edit window
menu.
2. Select the location and name of the subroutine.
3. Select “Open”.
NOTE: You may need to change the file filter (type) to *.txt to see the project file in the
dialog box.
When the import is complete, the subroutine edit window will open. Refer to Section 7.5.
To Export
1. Select
File -> Export -> Subroutine -> Text File
option from the main PathMaster®
menu or the
File -> Export Subroutine
option from the subroutine edit window
menu.
2. Select the location and name of the subroutine.
3. Select “Save”.
