Offset Details – An information screen that shows the teach Tool Reference Position, Run
Tool Reference Position, Tooling Offset, and Profile Offset for the selected tool.
PathMaster® – Windows® Operating System based programming software. Used to create,
maintain and download program files for the workcell.
Profile Base – A physical device which has a plunger that is used as the Profile Z Reference
position for all run tools.
Profile Calibration – The process by which the Profile Offset is calculated for a given run
tool. This is accomplished by determining the difference of the Z position of the run tool
and the
Profile Tool at the Profile Z Reference.
Profile Offset – Distance between the Profile Z Reference and the tip of a given tool.
Profile Plunger Locate – The process by which the Profile Offset is calculated for a given
Profile Tool. This is accomplished by taking a Profile Tool reading at the surface of the
Profile Base’s plunger.
Profile Tool – A tool which may be used to determine the height of a desired dispense
surface in units of distance relative to a common surface.
Profile Z Reference – The common surface that is used in profile calculations. Usually, this
is the plunger of the
Profile Base.
Program – A collection (or series) of Dispense Paths and general commands.
Program Offset – Change in position that is applied to all programs in all projects. Program
offsets are generated by
Tool Offset Setup, Tool Change, and Needle Calibration.
Project – File consisting of up to 30 Programs.
Purge Position – The location in the workspace where the end effector moves to perform
all auto purge operations.
PVA –Precision Valve and Automation.
Run Tool Reference – The workspace position where the run tool is centered above the
system’s
Teach Tool Reference position.
Standby Position – The rest position for the end effector. The machine moves here after
homing and after each cycle. This position is usually located near the start point for the
program(s). It is not the same as the
Home Position.
Sensor Locate Sequence – Establish the spatial relationship between the Needle
Calibration Reference position and a repeatable location relative to the X and Y sensors.
Solvent Position – The location in the workspace where the end effector moves to idle in
solvent cups.
Machine Operation Manual
Revision L /
February 2020
Page 175 of 200
Teach Tool Reference – The workspace position where the teach tool is centered above a
crosshair or other identifying mark. This identifying mark will be used as a common location
for calculating
Tooling Offsets.
Terminal – A program used as a communication link between the controller and operator.
Tool – A virtualized instance of a Device, usually configured to a specific orientation.
Tool Change – Modifying the Run Tool Reference position relative to the Teach Tool
Reference to change the Tooling Offset. This function is generally used for adjusting a tool
position after a needle change, tool maintenance, etc.
Tooling Offset – Spatial relationship between the teach tool and the run tool.
Tool Offset Setup – Teaching the teach tool to run tool relationship (XYZW) in machine
parameters. This function is generally reserved for initial tool setup.
Workspace Reference – A fixed position in gantry space relative to the part fixturing. This
position is used as a source and destination machine for the purpose of transporting
machine programs. It may also be used to apply a global offset on all programs in all
projects.
Machine Operation Manual
Revision L /
February 2020
Page 176 of 200
Appendix C: PathMaster INI Details
Sections
Key
Value
Description
[General]
Equip_ID String Machine database that is loaded when
PathMaster Starts
Default = Default
Language Enum Enumerated Value representing current
display language
1 – English
2 – Spanish
3 – French
4 – German
5 – Mandarin
6 – Japanese
ManualFile Path File Path to PathMaster User manual PDF file
Default = ‘C:\Program
Files\PVA\PathMaster\manual\PathMasterMa
nual.pdf’
NeedleCalImage Path Path to Needle calibration image that is
displayed during needle calibration
Default = ‘C:\Program
Files\PVA\PathMaster\Graphics\NdlCal.jpg’
ProjectFileOutput Path Path to write PartManager project files.
These files are in DMC format
NOTE: UserDefaultProjectFileOutput=1
must be set for this file output path to be
used
Default = ‘C:\Program
Files\PVA\PathMaster\Projects’
SpiralSlowSegments Num Defines the number of segments before the
end of a circular spiral to begin
incrementally slowing down
Default = 3
UseDefaultProjectFileOut
put
Bool 0 – Prompt User for Path When Saving for
PartManager
1 – Use Default Project File Output Path to
Store Paths when Saving for PartManager
Default = 1
EnableAutoBackup Bool 0 – Disable Auto Backups
1 – Enable Auto Backups
Auto backups occur prior to changing path
data as a result of offsets from Setup, Tool
Change, or Needle Calibration
