Machine Operati on Manual Revision L / February 2020 Page 180 of 2 00 Appendix D: Working with M aterials O verv iew W orkcell s opera te with ma ny differen t materia l s in a variety of applications . It is not easy to…
Machine Operation Manual
Revision L /
February 2020
Page 179 of 200
[Profile Type]
0… Enum Enumerated list of Profile Types
Default:
0=None
1=Non-Contact
2=Contact
Note:
Profile Type None is a reserved Profile Type
and cannot be modified. All others types can
be customized as needed
[vRETMsgs]
2… Enum vRET handshake response messages
When the vRET response from the Galil
corresponds to a RETMsg, PathMaster
presents the message to operator
[GalilMemory]
MaxMain Num Maximum length of Main program in lines
(80 Char / Line)
Default = 3200
MaxPath Num Maximum length of Path program in lines
(80 Char / Line)
Default = 1600
MaxRam Num Maximum length of Main Prog + Path
Program in Memory
Default = 4800
MaxSpiralSegments Num Maximum Number of motion segments
allowed in a Rectangular or Circular Spiral
Default =1000
MaxSegment Num Maximum number of motion segments for a
dispense sequence (other than spirals)
Default = 2047
Machine Operation Manual
Revision L /
February 2020
Page 180 of 200
Appendix D: Working with Materials
Overview
Workcells operate with many different materials in a variety of applications. It is not easy to
program with these materials because there are no set rules for an operator to obey. The
best procedure to find system settings for the system is trial-and-error. When satisfactory
parameters are found, it is easy to maintain those parameters.
It is necessary to adjust each part of the material delivery system for the selected material.
Adjust the components in the order shown.
Material Feed
First, refer to the manufacturer’s material specifications to find the applicable settings for
the material delivery system. Usually, material is moved through the system by a pump or a
pressure vessel. If a pump is used on the system, read the separate pump manual to find
the best settings for the material. If a pressure vessel is used, the pressure is too high if
material flow is too much, inconsistent, or if air is forced into the material. The pressure is
too low if material flow is not sufficient.
Dispense (Needle) Valve
The stroke of the needle valve can be adjusted. Turn the micrometer knob on the top of the
valve counter-clockwise to increase material flow. A fine steady stream of material is all
that is necessary. Tighten the locking nut when the flow is satisfactory. Make sure the
valve flow rate is correct before you continue.
Needle Selection
Try different needle sizes to find a satisfactory needle for your procedure. If the needle is
too large, there will be a drip at the end of the needle. If the needle is too small, the flow will
not be sufficient.
Machine Operation Manual
Revision L /
February 2020
Page 181 of 200
Spray Valve
Valve stroke and atomizing air are adjustable on spray valves.
The stroke controls the flow of material through the valve. Turn the micrometer knob on
the top of the valve counter-clockwise to increase material flow. Tighten the locking collar
when the flow is satisfactory. Make sure the valve flow rate is correct before you continue.
Atomizing air is controlled by a pressure regulator on the front of the machine. Turn this
clockwise to increase air pressure. This pressure can only be adjusted while the valve is
active. When the flow is satisfactory, push the cap or tighten the locking collar. When first
operating the machine, follow this list of instructions to adjust the spray valve:
1. Set the atomizing air to 0 psi.
2. Take off the spray cap.
3. Turn the stroke down all the way.
4. Purge the valve and open the stroke until the flow is a few drops per second.
5. Put the spray cap on.
6. Purge the valve and adjust the atomizing air until the spray is satisfactory. Test the
spray pattern on scrap.
If the atomizing air pressure is too high, the spray will be misty. If it is too low, there will be
splatter. For thin, solvent based materials 0.5 psi may be all that is necessary, and with
some silicones 15 psi may be necessary.
Programming
Once the satisfactory physical parameters for the delivery system are set, do not change
them. It is better to change the program. Usually, if you increase or decrease the speed of a
dispense path, the material output changes to a satisfactory level.
Program with the dispense valve close to the part surface, but not so close that different
needle length tolerances will cause the needle to touch the product surface.
With the spray valve, start about ¾” (19 mm) above the product surface. With atomizing air,
this should produce a spray width approximately ½” to ¾” (19 mm) wide. If necessary,
adjust the spray height so the pattern on the product is consistent and uniform.
