AHB01ESPP
1.2.6 Menus for Recognized Image
By using the menus for recognized image, a display pattern of the rec-
ognized image can be specified to determine how the image should be
imposed on the operation window on the touch screen.
••
••
• Menu Selection
1. When the [RECOG.] button on the main menu bar is pressed, the
"Recog. Dspl. Sel" menu opens.
2. Select the desired option (display pattern) from the "Recog. Dspl.
Sel" menu. The imposed area of a recognized image is specified on
the operation window.
Fig. 2D14
1.2 Using the Menus
0308-003 4-16
AHB01ESPP
2. Basic Operations
2.1 Selection of Tab Sheet
When a window is composed of several sheets, all the sheets are pro-
vided with extensions called "Tabs" and laid on top of each other so that
the tab of each is visible.
In this manual, a sheet provided with a tab is called "Tab Sheet".
Each extension (tab) names the corresponding sheet. When a tab is
pressed, the corresponding sheet is brought to the front.
Fig. 2D15
When a tab sheet contains several subtab sheets and a subtab is se-
lected, the corresponding subtab sheet appears inside the main tab
sheet.
0107-001 4-17
2.1 Selection of Tab Sheet
AHB01ESPP
2.2 Setting Operation
2.2.1 Check Box
A check box ( or ) is provided in front of an item that requires an off
or on value, indicating whether the function is selected or not.
Check Boxes
: The item (function) is specified as "Enabled" or "Valid".
: The item (function) is specified as "Disabled" or "Invalid".
Turning on or off a check box
When a check box is unchecked ("Disabled" or "Invalid"), press the box.
A check mark appears inside the box, indicating that the function is speci-
fied as "Enabled" or "Valid". This is called "Checked".
When a check box is checked ("Enabled" or "Valid"), press the box. A
check mark disappears, indicating that function is specified as "Dis-
abled" or "Invalid". This is called "Unchecked".
2.2.2 Option Button
When several items (functions) are grouped and one of them must be
selected, option buttons are provided in front of the items, allowing you
to choose a single item (function) from a group of options.
Option Buttons
: The item (function) is selected.
: The item (function) is not selected.
Turning on or off an option button
When a dot is not in an option button, it means that the item (function) is
not selected. When such an option button is pressed, a dot appears
inside the circle, indicating that the function is selected.
When an option button having a dot in the circle is pressed, the dot
disappears, indicating that the selection of the function is canceled.
0107-001 4-18
2.2 Setting Operation
