AHB01ESPP
*2 "Type" Group Box
Set the type of lighting to be used for teaching operations.
The following buttons are provided in this group box.
[Standard] Button
When this is selected, the standard lighting is used for teaching
operations.
[Ceramic] Button
When this is selected, the ceramic lighting is used for teaching op-
erations.
*3 [Fdr. No.] Button
When this button is pressed, the "Fdr. No." edit window opens. En-
ter the feeder No. to which the head must be moved, using the ten-
key pad.
*4 "Selection of Teaching Operation" Group Box
The following buttons are provided in this group box.
[All Beam Zero] Button
When this button is pressed, all X/Y beams are zeroed.
[P.E.C. Recog Ltg Teach] Button
When pressed, this button performs a teaching operation on the
lighting for the P.E.C. recognition camera on the head section.
[Offset Lighting Teach] Button
When pressed, this button performs a teaching operation on the
lighting for the backlight plate (used for offset teaching).
[Fixed camera Back Lighting Teach] Button
When pressed, this button performs a teaching operation on the
back lighting for the fixed recognition camera.
[Fixed camera Front Lighting Teach] Button
When pressed, this button performs a teaching operation on the
front lighting for the fixed recognition camera.
[Movable camera Back Lighting Teach] Button
When pressed, this button performs a teaching operation on the
back lighting for the movable recognition camera.
[Movable camera Front Lighting Teach] Button
When pressed, this button performs a teaching operation on the
front lighting for the movable recognition camera.
5.22 "Lighting Teach" Tab
0308-001 6-206-2
AHB01ESPP
[Jig Cmpnt Pickup Posn Mvt] Button
When pressed, this button moves the head to the position specified
by the feeder No.
*5 [Vac Pick-Up On/Off] Button
When this button is pressed, the vacuum of the selected head is
turned ON or OFF.
*6 Offset Values
Displayed are the current values and the adjusted ones after teach-
ing.
*7 Set Status
When the "P.E.C. Dsbl." or the "Comp. Recognition Dsbl." check
box in the "Test Run" tab sheet is turned on (checked), the back-
ground color of "Recognition Dsbl." turns light red. (No background
color in normal cases)
No recognition processing is made even if a teaching op-
eration is performed when each check box is turned on
(checked) in the "Test Run" tab sheet. Therefore, various
teaching operations will get incorrect results.
When "All Beam (Incl. NC Axis) Heads Zero" is completed, the back-
ground color of "All Beam Zero" turns green. (Otherwise, the back-
ground has no color.)
(a) When each device is not zeroed and the teaching op-
erations are performed, note that the offset values may
not be taught correctly.
(b) Before performing a teaching operation, be sure to zero
all beams.
*8 [P.C.B. Transfer Manual Mode] Button
When this button is pressed, the "P.C.B. Transfer Manual Mode"
sheet appears.
Refer to "5.3.1 "P.C.B. Transfer Manual Mode" Sheet" for details.
*9 [Mnl Noz Chng] Button
When this button is pressed, the "Nozzle Set/Reset" sheet appears,
enabling the cycle operation for opening or closing the nozzle stocker
and attaching or storing a vacuum nozzle through manual opera-
tions.
Refer to "4.3 "Nozzle Change" Tab" for details.
5.22 "Lighting Teach" Tab
0308-001 6-206-3
Note
Note
AHB01ESPP
*10 [Clear Adj.] Button
When pressed, this button clears the results of the teaching opera-
tion.
*11 [Cancel] Button
When pressed, this button cancels the results of the teaching op-
eration without reflecting them on the offset data.
*12 [End] Button
When this button is pressed, a "Confirmation" dialog box opens.
When the [YES] button is pressed, the results of the teaching op-
eration are reflected on the offset data and the dialog box closes.
*13 "Control Switch" Group Box
Select one of the buttons in the "Selection of Teaching Operation"
group box (*4) and press the [ON] button entitled "MOVE". After that,
press the [ENABLE] button on the operation panel in two seconds.
A teaching operation is performed on the selected item.
5.22 "Lighting Teach" Tab
0308-001 6-206-4
