AHB01ESPP 1.1.1 Submenus and T ab Sheets The menus for maintenance are composed of the following submenus and tab sheets. Menus for Maintenance Submenus T abs (T ab Sheets) Reference Item Nos. MNL OPN. Zeroing Opn. (2.1)…
AHB01ESPP
*3 Current Mode
The current mode of the machine is displayed.
There are seven modes - "RUN", "PAUSE", "STOP", "WAIT",
"TEACH", "MOVE", and "TEST".
*4 Operation Guide
The operating condition and results will be displayed.
*5 Submenu Window
When a button on the submenu bar is pressed, the corresponding
window (submenu) opens.
*6 Tabs
When a submenu window is composed of several sheets, all the
sheets are provided with extensions called "Tabs" and laid on top of
each other so that the tab of each is visible.
When a tab is pressed, the corresponding tab sheet is brought to
the front.
When a submenu window has only one sheet, the sheet is not pro-
vided with a tab.
*7 Status Bar
The status bar at the bottom provides additional information such
as page No., time, etc.
01 12-002 6 - 2
1.1 Composition of Menus for Maintenance
AHB01ESPP
1.1.1 Submenus and Tab Sheets
The menus for maintenance are composed of the following submenus
and tab sheets.
Menus for Maintenance
Submenus Tabs (Tab Sheets) Reference Item Nos.
MNL OPN. Zeroing Opn. (2.1)
Manual Axis Opn. (2.2)
DVC. TEST X/Y Beam Test (3.1)
P.E.C. Recog Test (3.2)
Cmpnt Recog Test (3.3)
UNIT ADJ. Conveyor Adj (4.1)
P.C.B. Transfer Adj. (4.1.1)
PCB Lct Sol Adj (4.1.2)
PCB Xfr Adj (4.1.3)
Feeder Base (4.2)
Nozzle Change (4.3)
Others (4.4)
(To the next page)
Fig. 2F2 Composition of Menus for Maintenance (1)
0308-004 6-3
1.1 Composition of Menus for Maintenance
AHB01ESPP
(From the previous page)
Submenus Tabs (Tab Sheets) Reference Item Nos.
TEACHING Pick-Up Location (5.1)
Library Teaching (5.2)
P.E.C. Recog Camr & (5.3)
Beam Ofs
Table Ofs (5.4)
NC Axis Ofs (5.5)
Nozzle Level Ofs (5.6)
Cmpnt Fxd Camr Mag (5.7)
Cmpnt Recog Fxd Camr Ofs (5.8)
Head Center Ofs (5.9)
Head Rotation Ofs (5.10)
Cmpnt Recog Mvbl Mag (5.11)
Cmpnt Recog Mvbl Camr Ofs (5.12)
Nozzle Stocker Ofs (5.13)
Nozzle Stocker Ofs (5.14)
Feeder Base Ofs (5.15)
Feeder (A) Ofs (5.16)
Feeder (B) Offset (5.17)
Teaching Plate Ofs (5.18)
Nozzle Center Ofs (5.19)
Nozzle Tip Pos Ofs (5.20)
Head Master Offset (5.21)
Travers Ofs (Option)
Lighting Teach (5.22)
DVC. CHECK Input Check (7.1)
I/O Diag. (7.1.1)
I/O (Op) (7.1.2)
Motor Cont (EB005) (7.1.3)
Motor Cont (MCB) (7.1.4)
HLS Connect (7.1.5)
Machine Prgm. Info. (7.2)
FILE OPN. Save/Load (8.1)
Fig. 2F2-1 Composition of Menus for Maintenance (2)
The above tree is based on the selection of the multi-layer tray
feeder (option).
0308-003 6-4
