Comparison Table ( English - Chinese ) VGOS V2.46STD R1.000 1 17 / 237 Copyright (C) 2009 Y amaha Motor Co.,Ltd. All Rights Reserved. Code Code Code Code Englis h Englis h Englis h Englis h Chinese Chinese Chinese Chines…

100%1 / 237
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 116 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Please execute it again after moving up SZ axis on axis move dialog
or reset operation.
Ea08097 UNABLE TO UP PUSH-UP
PU axis is not enable to up, because a Board is detected
by interference confirmation sensor
禁止󳕋板上升
因确󲡹干的感器󰖕出了基板，
所以禁止 PU 󲱉上升。
Ea08098 MAIN STOPPER AXIS MOVE ERROR
A main stopper axis cannot be moved.
Cause
A board is in a machine and the main stopper up.
Measure
1. Please remove the board in a machine.
2. Please down a main stopper.
禁止主板󲱉作
无法使主板󲱉作。
原因
机器内的基板固定位置存在基板，
或主板于上升状。
措施
1. 取出机器内的基板。
2. 使主板下降。
Ea08099 MAIN STOPPER UP ERROR
A main stopper cannot be up.
Cause
A board is in a machine
Measure
The board in a machine is removed.
禁止主板作
无法使主板上升。
原因
机器内的基板固定位置存在基板。
措施
取出机器内基板固定位置上的基板。
Ea08100 SQUEEGEE UP ERROR
Failed to move squeegee up.
刮刀上升󳇮󲣄
刮刀不上升。
Ea08101 SQUEEGEE DOWN ERROR
Failed to move squeegee down.
刮刀下降󳇮󲣄
刮刀不下降。
Ea08102 PRINT FORCE CONTROLL ERROR
Fail to control Print Force.
Please check the attachment status of squeegee,
and the fixed status of the board.
Target Force
Current Force
印控制󳇮󲣄
印控制已失󲧺。
󲣌确󲡹刮刀的安装状、基板的固定状。
󲢓置印
当前印
Ea08103 SOLDER AMOUNT ERROR
Enclosed Head is lack of solder.
Please Check which squeegee position is.
[Front side]
(1) Please supply solder with no operation.
[Rear side]
(1) Reset auto-running
(2) Press "Move Squeegee" button to move squeegee
to front side.
(3) Please Supply solder.
󳇶膏余量󳇮󲣄
󳇶膏的余量已越来越少。
[刮刀在前]
(1) 󲣌󱮼󱯂供󱮮󳇶膏。
[刮刀在后]
(1) 位自运行
(2) 用"移刮刀"按󳆃将刮刀移至装卸位置。
(3) 󲣌供󳇶膏。
Ea08104 SQUEEGEE TYPE ERROR
"Enclosed Head" is selected for "Squeegee Type"
parameter in Board data.
刮刀󱥐型󳇮󲣄
基板程序的"刮刀󱥐型"参数󲣄󲢓置了"封󳋂型刮刀"。
Ea08105 SQUEEGEE TYPE ERROR
Double Squeegee is attached on squeegee head.
But "Double" is not selected for "Squeegee Type"
parameter in Board data.
刮刀󱥐型󳇮󲣄
󲍒然基板程序的"刮刀󱥐型"参数已󲢓置"双刮刀"，
但并没有安装双刮刀。
Ea08106 SQUEEGEE TYPE ERROR
Enclosed Head is attached on squeegee head.
But "Enclosed Head" is not selected for "Squeegee Type"
parameter in Board data.
刮刀󱥐型󳇮󲣄
󲍒然基板程序的"刮刀󱥐型"参数已󲢓置"封󳋂型刮刀"，
但并没有安装封󳋂型刮刀。
Ea08107 SQUEEGEE TYPE ERROR
3S Head is attached on squeegee head.
But "3S Head" is not selected for "Squeegee Type"
parameter in Board data.
刮刀󱥐型󳇮󲣄
󲍒然已安装 3S 刮刀，但基板程序的"刮刀󱥐型"参数没有
󲢓置"3S 刮刀"。
Ea08108 DOUBLE SQUEEGEE ATTACHMENT ERROR
Double Squeegee is attached on squeegee head.
But "Double" is not selected for "Squeegee Type"
parameter in machine data.
Please change machine data to "Double", and
reboot the machine.
双刮刀安装󳇮󲣄
󲍒然已安装双刮刀，但机器数据中的"刮刀󱥐型"参数没有
󲢓置"双刮刀"。󲣌将机器数据中的"刮刀󱥐型"参数󲢓置
"双刮刀"后，重新启机器。
Ea08109 ENCLOSED HEAD ATTACHMENT ERROR
Enclosed Head is attached on squeegee head.
But "Enclosed Head" is not selected for "Squeegee Type"
parameter in machine data.
Please change machine data to "Enclosed Head", and
reboot the machine.
封󳋂型刮刀安装󳇮󲣄
󲍒然已安装封󳋂型刮刀，但机器数据中的"刮刀󱥐型"参数没有
󲢓置"封󳋂型刮刀"。󲣌将机器数据中的"刮刀󱥐型"参数󲢓置
"封󳋂型刮刀"后，重新启机器。
Ea08110 3S HEAD ATTACHMENT ERROR
3S Head is attached on squeegee head.
But [3S Head] is not selected for [Squeegee Type]
parameter in machine data.
Please change machine data to [3S Head], and
reboot the machine.
3S 刮刀安装󳇮󲣄
󲍒然已安装 3S 刮刀，但机器数据的[刮刀󱥐型]参数没有
󲢓置[3S 刮刀]。󲣌将机器数据的[刮刀󱥐型]参数󲢓置
"3S 刮刀"后，重新启机器。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 117 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Ea08150 MAIN STOPPER UP ERROR
Failed to move main stopper up.
主板上升󳇮󲣄
主板不上升。
Ea08151 MAIN STOPPER DOWN ERROR
Failed to move main stopper down.
主板下降󳇮󲣄
主板不下降。
Ea08152 BOARD FLAP UP ERROR
Failed to move Board flap up.
基板板上升󳇮󲣄
基板板不上升。
Ea08153 BOARD FLAP DOWN ERROR
Failed to move Board flap down.
基板板下降󳇮󲣄
基板板不下降。
Ea08154 EDGE CLAMP FIX ERROR
Failed to move edge clamp for fixation.
󲲎具作󳇮󲣄
󲲎具不作。
Ea08155 EDGE CLAMP RELEASE ERROR
Failed to move edge clamp for release.
󲲎具󲺟放󳇮󲣄
󲲎具不󲺟放。
Ea08156 BOARD PRESS UP ERROR
Failed to move Board press up.
基板整板上升󳇮󲣄
基板整板不上升。
Ea08157 BOARD PRESS DOWN ERROR
Failed to move Board press down.
基板整板下降󳇮󲣄
基板整板不下降。
Ea08158 BOARD VACUUM CHECK ERROR
The result of Board vacuum check was NG.
There is a possibility that Board is not fixed on the conveyor
or mount height offset is too big or adjustment of the vacuum
sensor is not good.
吸附基板的真空󰖕󰨠󳇮󲣄
吸附基板的真空感器󰖕󰨠󱮨果 NG。
可能没有正确吸附基板，󲨉装高度偏差量󲲜大，
或真空感器的󲣘整状不正确。
Ea08159 CONVEYOR ERROR
The main-stopper position can not change,
because of the board on the conveyor.
Try to remove it.
送󳇮󲣄
因送上有基板，所以不能改主板的位置。
󲣌将机器置于󱧼急停机状，并取出基板。
取出基板后，󲣌解除󱧼急停机，并再次行。
Ea08162 UNABLE TO MOVE FLAP IN DANGEROUS POSITION
Operation of the flap in this table height cannot be performed.
Please lower the Board table.
基板板作危󳌾
此工作台高度下，不能󲲰行基板板作。
󲣌降低基板工作台高度。
Ea08163 THE MAIN STOPPER OPERATION IS DANGEROUS.
The board press is descending.
Under such a condition, there is a possibility of coming in contact
when the main stopper is raised.
Please execute it again after it rises in the board press.
主板作危󳌾
基板整板正在下降。
在此状下上升主板可能会生碰撞。
󲣌上升基板整板后，重新行。
Ea08164 UNABLE TO MOVE FLAP
It is unable to move flap, because there is a possibility that
the flap interferes with the camera axis or the board press.
There are possible causes as follows, please remove the causes.
(1) The board table is not in the height of the board recognition.
(2) The board press is down.
板作危󳌾
因板可能与相机󲱉、或基板整板相干，所以板不能正常作。
󲣌排除如下故障原因后，重新行。
(1) 基板工作台不在基板󲢛高度。
(2) 基板整板正在下降。
Ea08165 UNABLE TO MOVE BOARD PRESS
It is unable to move board press, because there is a possibility
that the board press interferes with the board table or the
conveyor unit.
There are possible causes as follows, please remove the causes.
(1) The board table is not in the height for the board transfer.
(2) The main stopper is up.
(3) The flap is up.
基板整板作危󳌾
因基板整板可能与基板工作台、或固定装置相干，
所以基板整板不能正常作。
󲣌排除如下故障原因后，重新行。
(1) 基板工作台不在基板送高度。
(2) 主板正在上升。
(3) 板正在上升。
Ea08166 Edge Clamp Pressure Error
The pressure of edge clamp has not reached the specified pressure.
󲲎具力󳇮󲣄
󲲎具的力已达到󲚙定。
Ea08167 UNABLE TO MOVE FLAP
It is unable to move flap while "EMERGENCY STOP".
Please release "EMERGENCY STOP".
板作危󳌾
󱧼急停机状下，板不能正常作。
󲣌解除󱧼急停机状。
It is unable to move flap while "EMERGENCY STOP".
Please release "EMERGENCY STOP".
Ea08172 CONV WIDTH CHECK ERROR
Because the width of the conveyer doesn't become complete,
the board cannot be transported.
Please remove the board, and adjust conveyer width.
___CONV WIDTH CHECK ERROR
Because the width of the conveyer doesn't become complete,
the board cannot be transported.
Please remove the board, and adjust conveyer width.
Ea08200 UNABLE TO LOAD BOARD
Unable to carry Board in.
Possible causes:
(1) There is no Board on entrance position of the
conveyor.
(2) There is a Board on print position of the conveyor.
(3) There is a Board on exit position of the conveyor.
基板不能入
不能入基板。
可能由以下原因造成。
(1) 送入口没有基板。
(2) 作位置上有基板。
(3) 送出口有基板。
Ea08201 UNABLE TO UNLOAD BOARD
Unable to carry Board out.
Possible causes:
(1) There is a Board on entrance position of the
conveyor.
(2) There is no Board on print position of the
conveyor.
基板不能出
不能出基板。
可能由以下原因造成。
(1) 送入口有基板。
(2) 作位置上没有基板。
(3) 送出口有基板。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 118 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
(3) There is a Board on exit position of the conveyor.
Ea08202 UNABLE TO FIX BOARD
Unable to fix Board.
Possible cause:
(1) There is no Board on print position of the
conveyor.
基板不能固定
不能固定基板。
可能由以下原因造成。
(1) 作位置上没有基板。
Ea08203 CARRY-IN BOARD ERROR
Failed to load Board on the conveyor.
基板入󳇮󲣄
基板的入失󲧺了。
Ea08204 CARRY-OUT BOARD ERROR
Failed to unload Board from the conveyor.
基板出󳇮󲣄
基板的出失󲧺了。
Ea08205 CONVEYOR WIDTH ERROR
Conveyor width is different from Board size Y.
送度󳇮󲣄
送度与基板尺寸 Y 不一致。
Ea08206 UNABLE TO MOVE BOARD TABLE
Unable to move Board table with a Board on the conveyor.
Please remove the Board.
基板工作台不能移
因送上有基板，所以不能移基板工作台。
󲣌取下送上的基板。
Ea08207 FAILED TO FIX BOARD
Failed to fix Board.
There is no Board on the fixation position of the
conveyor.
基板固定󳇮󲣄
基板的固定已失󲧺。
󲢺已󱮤入和固定的基板
并不在基板固定位置。
Ea08208 UNABLE TO LOAD BOARD FROM UPSTREAM BUFFER CONVEYOR
Unable to carry Board in.
Followings are possible as the reason.
(1) There is no Board on entrance position of the
upstream buffer conveyor.
(2) There is a Board on exit position of the upstream
buffer conveyor.
Please remove the Board on the upstream buffer conveyor.
上流󱯨冲送不能入基板
不能将基板入上流󱯨冲送。
可能由以下原因造成。
(1) 上流󱯨冲送入口没有基板。
(2) 上流󱯨冲送出口有基板。
󲣌取出上流󱯨冲送上的基板。
Ea08209 FAILED TO CARRY BOARD ON UPSTREAM BUFFER CONVEYOR
Failed to carry Board.
Please remove the Board on the upstream buffer conveyor.
上流󱯨冲送基板送󳇮󲣄
基板的送失󲧺了。
󲣌取出上流󱯨冲送上的基板。
Ea08210 ILLEGAL BOARD DETECTION ON UPSTREAM BUFFER CONVEYOR
More than 2 boards are detected on the conveyor.
Please remove the boards on the buffer conveyor.
上流󱯨冲送󰖕出异常基板
送上已󰖕出 2 枚基板。
󲣌取下上流󱯨冲送上的基板。
Ea08211 UNABLE TO CARRY BOARD IN DOWNSTREAM BUFFER CONVEYOR
Unable to load Board into downstream buffer conveyor.
Possible causes:
(1) There is no Board at entrance position of the
downstream buffer conveyor.
(2) There is Board at exit position of the downstream
buffer conveyor.
Please remove the Board on the downstream buffer conveyor.
下流󱯨冲送不能入基板
不能将基板入下流󱯨冲送。
可能由以下原因造成。
(1) 下流󱯨冲送入口没有基板。
(2) 下流󱯨冲送出口有基板。
󲣌取出下流󱯨冲送上的基板。
Ea08212 FAILED TO CARRY BOARD ON DOWNSTREAM BUFFER CONVEYOR
Failed to carry Board on downstream buffer conveyor.
Please remove the Board on the downstream buffer conveyor.
下流󱯨冲送基板送󳇮󲣄
基板的送失󲧺了。
󲣌取下下流󱯨冲送上的基板。
Ea08213 ILLEGAL BOARD DETECTION ON DOWNSTREAM BUFFER CONVEYOR
More than 2 boards are detected on the conveyor.
Please remove the boards on the downstream buffer conveyor.
下流󱯨冲送󰖕出异常基板
送上已󰖕出 2 枚基板。
󲣌取出下流󱯨冲送上的基板。
Ea08214 BOARD TRANSFER ERROR
Unable to load Board into the main conveyor.
Possible causes:
(1) There is a Board on print position of the main
conveyor.
(2) There is a Board on exit of the main conveyor.
基板送󳇮󲣄
不能向印刷主机送入基板。
可能由以下原因造成。
(1) 印刷位置上有基板。
(2) 送出口有基板。
Ea08215 BOARD TRANSFER ERROR
Failed to load Board into the main conveyor.
基板送󳇮󲣄
向印刷主机送入基板失󲧺了。
Ea08216 BOARD TRANSFER ERROR
Failed to load Board from entrance of the main conveyor.
基板送󳇮󲣄
自印刷主机送入口的基板送失󲧺了。
Ea08217 BOARD TRANSFER ERROR
Failed to load Board from exit of the main conveyor.
基板送󳇮󲣄
自印刷主机送出口的基板送失󲧺了。
Ea08218 BOARD TRANSFER ERROR
Failed to carry Board from extended guide of the main
conveyor.
基板送󳇮󲣄
自印刷主机延󳉔送󲰽的基板送
失󲧺了。
Ea08219 BOARD TRANSFER ERROR
Failed to carry Board from entrance to print position of
the main conveyor.
基板送󳇮󲣄
自印刷主机送入口到印刷位置的
基板送失󲧺了。
Ea08220 BOARD TRANSFER ERROR
Failed to carry Board from exit to print position of the
main conveyor.
基板送󳇮󲣄
自印刷主机送出口到印刷位置的
基板送失󲧺了。
Ea08221 <<WARNING>> The printed board was missed.
When The board fixation was released after board detached,
the board was not deteced by the printing position sensor.
The following causes can be considered.
基板送󳇮󲣄
不能从印刷机主机送出基板。
可能由下列原因造成:
(1) 送入口有基板。
