Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 128 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
(5) After Manual Auto Cleaning
Ea08556 DATA CHECK ERROR
Print inspection is specified to work for all Board.
But all object are specified not to work for all Board on
current "Inspection Execution Specification".
Check "Inspection Execution Specification" for all Board
and "Execution Specification Number" of object data.
程序󰖕󰒺󳇮󲣄
󲍒然在「󰖕󰒺」󲳞󳕎卡中已将「通常运行(全基板)」
参数󲢓置行印刷󰖕󰒺，但是「行条件󲢓置」
󲳞󳕎卡中的所有象数据却没有󲢓置在通常运行
(全基板)中行印刷󰖕󰒺。
󲣌确󲡹通常运行(全基板)的󰖕󰒺行条件的󲢓置
和象数据的󰖕󰒺条件号󱓖。
Ea08557 DATA CHECK ERROR
Print inspection is specified to work for interval Board.
But all object are specified not to work for interval
Board on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for interval
Board and "Execution Specification Number" of object data.
程序󰖕󰒺󳇮󲣄
󲍒然在「󰖕󰒺」󲳞󳕎卡中已将「通常运行(󳋉隔行)」
参数󲢓置行印刷󰖕󰒺，但是「行条件󲢓置」
󲳞󳕎卡中的所有象数据却没有󲢓置在通常运行
(󳋉隔行)中行印刷󰖕󰒺。
󲣌确󲡹通常运行(󳋉隔行)的󰖕󰒺行条件的󲢓置
和象数据的󰖕󰒺条件号󱓖。
Ea08558 DATA CHECK ERROR
Print inspection is specified to work after dry auto
cleaning.
But all object are specified not to work after dry auto
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for dry
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然在「󰖕󰒺」󲳞󳕎卡中已将「干式自清󰧖后」
参数󲢓置行印刷󰖕󰒺，但是「行条件󲢓置」
󲳞󳕎卡中的所有象数据却没有󲢓置在干式自
清󰧖后行印刷󰖕󰒺。
󲣌确󲡹干式自清󰧖后的󰖕󰒺行条件的󲢓置和
象数据的󰖕󰒺条件号󱓖。
Ea08559 DATA CHECK ERROR
Print inspection is specified to work after wet auto
cleaning.
But all object are specified not to work after wet auto
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for wet
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然在「󰖕󰒺」󲳞󳕎卡中已将「湿式自清󰧖后」
参数󲢓置行印刷󰖕󰒺，但是「行条件󲢓置」
󲳞󳕎卡中的所有象数据却没有󲢓置在湿式自
清󰧖后行印刷󰖕󰒺。
󲣌确󲡹湿式自清󰧖后的󰖕󰒺行条件的󲢓置和
象数据的󰖕󰒺条件号󱓖。
Ea08560 DATA CHECK ERROR
Print inspection is specified to work after manual
cleaning.
But all object are specified not to work after manual
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for manual
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然在「󰖕󰒺」󲳞󳕎卡中已将「手清󰧖后」
参数󲢓置行印刷󰖕󰒺，但是「行条件󲢓置」
󲳞󳕎卡中的所有象数据却没有󲢓置在手清󰧖后
行印刷󰖕󰒺。
󲣌确󲡹手清󰧖后的󰖕󰒺行条件的󲢓置和
象数据的󰖕󰒺条件号󱓖。
Ea08563 DATA CHECK ERROR
Mask Inspection position XYR is out of Soft Limit.
Mask Inspection View Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺位置 XYR 在󲱄极限外。
网板󰖕󰒺󲚛野数据 号
Ea08564 DATA CHECK ERROR
Mask Inspection height Z is out of Soft Limit.
Mask Inspection View Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺高度 Z 在󲱄极限外。
网板󰖕󰒺󲚛野数据 号
Ea08565 DATA CHECK ERROR
Mask Inspection data Error
Object area of object data hasn't been set up.
Mask Inspection Object Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
象数据的面󱛄未󲢓置。
网板󰖕󰒺象数据 号
Ea08566 DATA CHECK ERROR
Mask Inspection data Error
Object size of object data hasn't been set up.
Mask Inspection Object Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
象数据的尺寸 XY 未󲢓置。
网板󰖕󰒺象数据 号
Ea08567 DATA CHECK ERROR
Mask Inspection data Error
Object window size of object data hasn't been set up.
Mask Inspection Object Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
象数据的󲚛窗尺寸 XY 󲲭未󲢓置。
网板󰖕󰒺象数据 号
Ea08568 DATA CHECK ERROR
Mask Inspection data Error
Recognition object of object data is outside window.
Mask Inspection Object Data
数据󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
象数据的󲢛象在󲚛窗外。
网板󰖕󰒺象数据 号
Ea08569 DATA CHECK ERROR
Mask Inspection data Error
Recognition object of object data is outside view.
Mask Inspection Object Data
Mask Inspection View Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
象数据的󲢛象在󲚛野的范外。
网板󰖕󰒺象数据 号
网板󰖕󰒺󲚛野数据 号
Ea08570 DATA CHECK ERROR
Mask Inspection data Error
Object data which cope with view data don't exist.
Mask Inspection View Data
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
󲚛野数据的象数据不存在。
网板󰖕󰒺󲚛野数据 号
Ea08571 DATA CHECK ERROR
Mask Inspection data Error
程序󰖕󰒺󳇮󲣄
网板󰖕󰒺数据󳇮󲣄
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 129 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Light unit level of view data hasn't been set up.
Mask Inspection View Data
󲚛野数据的照明󱭼未󲢓置。
网板󰖕󰒺󲚛野数据 号
Ea08572 DATA CHECK ERROR
Mask inspection function is specified to work.
But all parameter of inspection execution for following
conditions.
(1) After Dry Auto Cleaning
(2) After Wet Auto Cleaning
(3) After Manual Auto Cleaning
程序󰖕󰒺󳇮󲣄
󲍒然已指定使用网板󰖕󰒺，但以下所有条件
的网板󰖕󰒺都󲢓置了"不使用"
(1) "干式自清󰧖后"
(2) "湿式自清󰧖后"
(3) "手清󰧖后"
Ea08573 DATA CHECK ERROR
Mask inspection is specified to work after dry auto
cleaning.
But all object are specified not to work after dry auto
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for dry
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然已󲢓置干式自清󰧖后行网板󰖕󰒺，
但是在干式自清󰧖后的󰖕󰒺行条件󲢓置
中所有的象数据都󲢓置了干式自清󰧖后
不行网板󰖕󰒺。
󲣌确󲡹干式自清󰧖后的󰖕󰒺行条件的󲢓置
和󰖕󰒺条件号󱓖。
Ea08574 DATA CHECK ERROR
Mask inspection is specified to work after wet auto
cleaning.
But all object are specified not to work after wet auto
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for wet
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然已󲢓置湿式自清󰧖后行网板󰖕󰒺，
但是在湿式自清󰧖后的󰖕󰒺行条件󲢓置
中所有的象数据都󲢓置了湿式自清󰧖
后不行网板󰖕󰒺。
󲣌确󲡹湿式自清󰧖后的󰖕󰒺行条件的󲢓置
和󰖕󰒺条件号󱓖。
Ea08575 DATA CHECK ERROR
Mask inspection is specified to work after manual
cleaning.
But all object are specified not to work after manual
cleaning on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for manual
cleaning and "Execution Specification Number" of object
data.
程序󰖕󰒺󳇮󲣄
󲍒然已󲢓置手清󰧖后行网板󰖕󰒺，
但是在手清󰧖后的󰖕󰒺行条件󲢓置
中所有象数据都󲢓置了手清󰧖后
不行网板󰖕󰒺。
󲣌确󲡹手清󰧖后的󰖕󰒺行条件的󲢓置
和󰖕󰒺条件号󱓖。
Ea08576 DATA CHECK ERROR
Local fiducial is specified to work but Board fiducial
is specified not to work.
Local fiducial function requires execution of Board fiducial.
程序󰖕󰒺󳇮󲣄
󲍒然󲢓置使用局部基准󰓜󲢅，但是基板基准󰓜󲢅
呈不使用状。
使用局部基准󰓜󲢅，必󳕐使用基板基准󰓜󲢅。
Ea08577 DATA CHECK ERROR
Board table position XYR during local fiducial
recognition is out of Soft Limit.
程序󰖕󰒺󳇮󲣄
局部基准󰓜󲢅󲢛󰋋的工作台位置 XYR 在󲱄极限外。
Ea08578 DATA CHECK ERROR
Squeeze stroke in print action is not correct.
Please check "Rolling Stroke", "Over Stroke",
"F. Start Offset", "B. Start Offset".
程序󰖕󰒺󳇮󲣄
刮刀的印刷作冲程异常。
󲣌确󲡹"刮刀助跑距离"、"刮刀滑跑距离"、"去程始偏移量"、
"返程始偏移量"的󲢓置。
Ea08579 DATA CHECK ERROR
"Fiducial Position" is specified to "Board&Mask Common".
But the parameters in fiducial setting are different between Board
and Mask.
Please check the following parameters.
(1) Coordinates of Fiducial Position
(2) Fiducial Type
(3) Datum Position
程序󰖕󰒺󳇮󲣄
基准󰓜󲢅位置󲍒󲢓置"基板&网板共同指定"，
但在基板基准󰓜󲢅和网板基准󰓜󲢅以下的󲢓置不同。
(1) 基准󰓜󲢅位置坐󰓜
(2) 基准󰓜󲢅󱥐型
(3) 󰓜准位置
Ea08580 DATA CHECK ERROR
When production starts under specified detail cleaning data,
the cleaner blower motor may overheat.
Working duty of blower motor = Percent
Please change followings.
(1) Increase "Auto Interval".
(2) Decrease "Auto Repeat".
(3) Increase "Dry Auto Speed".
(4) Increase "Wet Auto Speed".
程序󰖕󰒺󳇮󲣄
所󲢓置的󲢻󱮛清󰧖的使用方法，可能会致
清󰧖装置󳖣扇󳝁达的温度上升超出容󲢍范。
󲣌用如下方法更改󲢓置。
(1) 增加"自󳋉隔"。
(2) 减少"自反"。
(3) 加速"干式自速度"。
(4) 加速"湿式自速度"。
Ea08581 DATA CHECK ERROR
Squeegee speed for Feedback Print is out of range.
Please specify correct speed as follows
Double Squeegee : 1 to 200[mm/sec]
Enclosed Head : 1 to 100[mm/sec]
程序󰖕󰒺󳇮󲣄
多重印刷反󳙝用刮刀速度范之外。
󲣌󲢓置如下状。
双刮刀 : 1 to 200[mm/sec]
封󳋂型刮刀 : 1 to 100[mm/sec]
Ea08582 DATA CHECK ERROR
Print pressure for Feedback Print is out of range.
Please specify correct pressure from 0.01 to 200[N].
程序󰖕󰒺󳇮󲣄
多重印刷反󳙝用印󲢓置范之外。
󲣌󲢓置在 0.01 至 200[N]之󳋉。
Ea08584 DATA CHECK ERROR
Printing or Cleaning Feedback is specified to "Exec".
But the data for feedback does not exist.
程序󰖕󰒺󳇮󲣄
󲍒然多重印刷、清󰧖反󳙝功能有效，
但反󳙝辨象的󰖕󰒺数据不存在。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 130 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Please create the data for feedback or repeal Feedback Function. 󲣌生成反󳙝辨象的󰖕󰒺数据或将
反󳙝功能󲢓置无效。
Ea08585 DATA CHECK ERROR
Mask Standard Position which is specified isn't supported.
According to the conveyer standard side, please set it to
the following Mask Standard Position.
A) For "Front side"
(1) Front
(2) Center
B) For "Rear side"
(1) Center
(2) Rear
程序󰖕󰒺󳇮󲣄
不所󲢓置的网板制版基准。
󲣌按送基准，󲢓置下列网板制版基准。
A) 送基准"前"󰋋
(1) 前
(2) 中央
B) 送基准"内"󰋋
(1) 中央
(2) 内
Ea08586 DATA CHECK ERROR
Distance From Printing Height of Squeegee Detail is
out of range.
Please set the following values.
0
From 0.01 to 10.0(mm/sec)
程序󰖕󰒺󳇮󲣄
刮刀󲢻󱮛󲢓置的[离板 自印刷高度的距离]的󲢓置在范外。
󲣌󲢓置下列数。
0，
0.01 至 10.0(mm/sec)。
Ea08587 SQUEEGEE I/O BOARD DATA READ ERROR
Failed to read Loadcell data from Squeegee I/O Board.
刮刀 I/O 端口 数据󲣐取󳇮󲣄
自刮刀 I/O 端口󲣐取󰨠器参数失󲧺了。
Ea08588 SQUEEGEE I/O BOARD DATA READ ERROR
The parameter of Loadcell in machine data is different from
the data of Loadcell in Squeegee I/O Board.
Please readjust the parametor of Loadcell.
The data of Loadcell in Squeegee I/O Board:
%s
Zero Lv.[%6.1f] Gain+[%6.1f] Gain-[%6.1f]
刮刀 I/O 端口 程序󰖕󰒺󳇮󲣄
机器数据的󰨠器参数与从刮刀 I/O 端口󲣐取的
󰨠器参数不一致。
󲣌重新󲣘整󰨠器参数。
从刮刀 I/O 端口󲣐取的数:
%s
自身重量取消 Lv[%6.1f] 增益+[%6.1f] 增益-[%6.1f]
Ea08589 SQUEEGEE I/O BOARD DATACHECK ERROR
The parametor of Loadcell in machine data is different from
the data of Loadcell in Squeegee I/O Board.
Please readjust the parametor of Loadcell.
The data of Loadcell in Squeegee I/O Board:
%s
Zero Lv.[%6.1f] Gain+[%6.1f] Gain-[%6.1f]
%s
Zero Lv.[%6.1f] Gain+[%6.1f] Gain-[%6.1f]
刮刀 I/O 端口 程序󰖕󰒺󳇮󲣄
机器数据的󰨠器参数与从刮刀 I/O 端口󲣐取的
󰨠器参数不一致。
󲣌重新󲣘整󰨠器参数。
从刮刀 I/O 端口󲣐取的数:
%s
自身重量取消 Lv[%6.1f] 增益+[%6.1f] 增益-[%6.1f]
%s
自身重量取消 Lv[%6.1f] 增益+[%6.1f] 增益-[%6.1f]
Ea08590 BOARD TABLE PRINT HIGHT ERROR
The print action cannot be executed because the board table
is not in the print height.
Please confirm the state of the board table and the board.
Please restart Auto-Running after Reset.
基板工作台印刷高度󳇮󲣄
因基板工作台没有达到印刷高度，所以不能行印刷作。
󲣌确󲡹基板工作台和基板的状。
如无异常，󲣌位后，重新始自运行。
Ea08591 DATA CHECK ERROR
If PU axis has been selected detach axis,
Board Clamp cannot be used.
程序󰖕󰒺󳇮󲣄
离版󲱉󲳞 PU 󲱉󰋋，
不能用基板固定固定基板。
Ea08592 DATA CHECK ERROR
Print inspection is specified to work after sizuri.
But all object are specified not to work after sizuri
on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for sizuri
and "Execution Specification Number" of object
data.
数据󰖕󰒺󳇮󲣄
󲍒然已󲢓置印刷后行印刷󰖕󰒺、
但是在󲢪印刷后的行󰖕󰒺条件的󲢓置全部的象文件󲢪印刷后不行。
󲣌确󲡹󲢪印刷后的󰖕󰒺行条件󲢓置、
或象数据的󰖕󰒺条件号󱓖。
Ea08593 DATA CHECK ERROR
Print inspection is specified to work for sizuri less
(Filling adjust).
But all object are specified not to work for sizuri less
B on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for sizuri less
and "Execution Specification Number" of object data.
数据󰖕󰒺󳇮󲣄
󲍒然已󱮤"不行󲢪印刷(󲔺充校正)"󲢓置行印刷󰖕󰒺、
但是在"不行󲢪印刷"的󰖕󰒺行条件上已󱮤󲢓置
全部象数据"不行󲢪印刷"不行。
󲣌确󲡹"不行󲢪印刷"的󰖕󰒺行条件󲢓置或象数据的󰖕󰒺条件号󱓖。
Ea08594 DATA CHECK ERROR
[Real PCB inspection sizuri Less] is set to
[Auto Inspection] in VmSpec.
However, the setting of data is not correct.
Please confirm data.
[SizuriFirstCheck] must be set to [NotUse].
[FillingAdjust(Manual)] must be set to [Use].
数据󰖕󰒺󳇮󲣄
󲍒然机器已󲢓置[不行󲢪印刷󰋋的󳌚生基板󰖕󰒺]、
但是基板程序的󲢓置不正确。
󲣌确󲡹以下的󲢓置。
- "󲢪印刷󰖕󰒺"󲢓置"不使用"。
- "󲔺充校正(手)"󲢓置"使用"。
Ea08599 DATA CHECK ERROR
Cleaning interval should have following relationship.
[Dry Auto] < [Wet Auto] < [Detail Auto] < [Manual]
程序󰖕󰒺󳇮󲣄
清󰧖󳋉隔的󲢓置必󳕐遵循下列大小系。
[干式自󳋉隔] < [湿式自󳋉隔] < [󲢻󱮛自󳋉隔] < [手󳋉隔]
Ea08600 [Vacuum Check] Confirmation
[Vacuum Check] is specified to [IgnoreErr].
When recognition error for the fiducial mark occurs,
the machine continues printing without fiducial
[像理校正]󲢓置警告
[像理校正]的󲢓置[忽略󳇮󲣄]。
即使基准󰓜󲢅󲢛失󲧺，也不会󲲰行
基准󰓜󲢅校正，而是󱮼󱯂施印刷。
