Comparison Table ( English - Chinese )

Code

CodeCode

Code

English

EnglishEnglish

English

Chinese

ChineseChinese

Chinese

All components in alternative loop are not available.

This can be caused by the followings:

- Pick up or recognition error happened.

- Component counter reached specified number.

Refill the components or check trays and run again.

Component data

原因如下:

- 生了吸附和󲢛󳇮󲣄

- 使用的元件数量已达到指定的数量。

󲣌󲔺充下列元件后，重新始运行。

元件数据号

Ea00366 All components in alternative loop are not available.

This can be caused by the followings:

- Door of tray unit was opened.

- All components were empty.

Close the door or supply component and run again.

Component data

Tray start No.

Tray end No.

因托󱎭交󰀷器的柜󳊽敞、或元件用完等原因，

下列元件已不可使用的状。

󲣌󳋂柜󳊽或󲔺充元件后，重新始运行。

元件数据号󱓖 号

托󱎭始号󱓖 号

托󱎭󱮨束号󱓖 号

Ea00368 PALLET NUMBER ERR

The pallet number detected by sensor is different

from the pulled pallet. Please check inserted

position of this pallet, and run again.

Proper No.

Detected No.

料架号󱓖󳇮󲣄

抽出的料架号󱓖与感器󰖕出的料架号󱓖不一致。

󲣌将料架改放于正确的料架，重新始运行。

正确的料架号󱓖 号

󰖕出的料架号󱓖 号

Ea00369 PALLET SET IMPOSSIBLE

One of the doors of the tray changer is open.

Please close all the doors and try again.

不能抽出料架

至少有一扇托󱎭交󰀷器的柜󳊽于敞状。

󲣌󳋂所有的托󱎭交󰀷器柜󳊽，并󲲰行重󲢪。

Ea00370 PALLET SET IMPOSSIBLE

The specified pallet number is out of the range.

Please check the pallet number and the machine

data setting.

不能抽出料架

指定的料架号󱓖在有效范外。

󲣌确󲡹料架号󱓖以及机器数据。

Ea00371 TRAY CHANGER ERROR

Unknown pallet is detected by the sensor

during pallet action.

Check the pallet sensor.

托󱎭交󰀷器󳇮󲣄

在退回/抽出料架的作中，󰖕出了不明料架。

󲣌确󲡹料架感器的状。

Ea00372 TRAY CHANGER ERROR

The destination magazine column is already occupied

by another pallet.

Mount data

Component data Name

Pallet

托󱎭交󰀷器󳇮󲣄

料架退回的位置上，

已存在其他料架。

󲨉装数据

元件数据名称

料架号󱓖

Ea00373 TRAY CHANGER ERROR

The destination magazine column is already occupied

by another pallet.

托󱎭交󰀷器󳇮󲣄

料架退回位置上，已存在其他料架。

Ea00374 TRAY CHANGER ERROR

A pallet is lost by the sensor

during pallet action.

Check the pallet sensor.

托󱎭交󰀷器󳇮󲣄

在退回/抽出料架的作中，未能󰖕出本存在的料架。

󲣌确󲡹料架感器的状。

Ea00376 TRAY CHANGER ERROR

Feeder Type of the component information

was defined for Ext.TC or Auto TC,

but no tray changer is configured on this machine.

Please change the setting.

托󱎭交󰀷器󳇮󲣄

󲍒然托󱎭交󰀷器不存在，但元件信息中送料器󱥐型的󲢓置

却[外部托󱎭交󰀷器]或[自托󱎭交󰀷器]。

󲣌更改󲢓置。

Ea00378 CONFIRMATION OF SPECIAL DUMP BACK

A component will be dumped back to the tray.

If you already supply component in the tray unit,

Be sure to press "EMERGENCY STOP" ON, remove the component from the head,

and run again.

Component data Name

托󱎭供󱮮装置作确󲡹

按特殊返󲲭理的󲢓置，正准将元件放回托󱎭。

但，因生󲲜托󱎭󲡶数停止󳇮󲣄，所以可能已󱮤在托󱎭

供󱮮装置󲔺充了元件。如已󲔺充，元件会重叠放置，

󲣌按󱧼急停机按󳆃，从 Head 上取出元件后，重新始运行。

元件数据号名称

Ea00379 TRAY CHANGER ERROR

The entire parts in that tray are not available

This can be caused by the followings:

- The entire parts is empty.

- Tray unit door is open.

Please supply parts or close the door and

start auto-running again.

Parts No. Name

Start Pallet No.

End Pallet No.

托󱎭交󰀷器󳇮󲣄

因托󱎭交󰀷器的柜󳊽被打或元件用完，下列元件

不能󱮼󱯂使用了。

󲣌󳋂柜󳊽或󲔺充元件后，再重新始自运行。

元件数据号名称

托󱎭始号󱓖 号

托󱎭󱮨束号󱓖 号

Ea00380 TRAY CHANGER ERROR

The pallet is protruded from the magazine1 of ATS1.

Please return the pallet to the magazine.

托󱎭交󰀷器󳇮󲣄

从 ATS1 的收󱮈柜 1 出了料架。

󲣌将料架退回收󱮈柜。

Ea00381 TRAY CHANGER ERROR

The pallet is protruded from the magazine2 of ATS1.

Please return the pallet to the magazine.

托󱎭交󰀷器󳇮󲣄

从 ATS1 的收󱮈柜 2 出了料架。

󲣌将料架退回收󱮈柜。

Comparison Table ( English - Chinese )

Code

CodeCode

Code

English

EnglishEnglish

English

Chinese

ChineseChinese

Chinese

Ea00382 TRAY CHANGER ERROR

The pallet is protruded from the magazine1 of ATS2.

Please return the pallet to the magazine.

托󱎭交󰀷器󳇮󲣄

从 ATS2 的收󱮈柜 1 出了料架。

󲣌将料架退回收󱮈柜。

Ea00383 TRAY CHANGER ERROR

The pallet is protruded from the magazine2 of ATS2.

Please return the pallet to the magazine.

托󱎭交󰀷器󳇮󲣄

从 ATS2 的收󱮈柜 2 出了料架。

󲣌将料架退回收󱮈柜。

Ea00384 TRAY CHANGER ERROR

There is no pallet required in the magazine.

Please check whether the pallet and the magazine are set correctly.

Mount data

Component data Name

Pallet

托󱎭交󰀷器󳇮󲣄

收󱮈柜中不存在必需的料架。

󲣌确󲡹料架和收󱮈柜是否已正确安装。

󲨉装数据号

元件数据号名称

料架号󱓖 号

Ea00385 TRAY CHANGER ERROR

There is no pallet required in the magazine.

Please check whether the pallet and the magazine are set correctly.

托󱎭交󰀷器󳇮󲣄

收󱮈柜中不存在必需的料架。

󲣌确󲡹料架和收󱮈柜是否已正确安装。

Ea00386 TRAY CHANGER ERROR

The component was lost during transfer of DX axis.

If the component is on the station or transfer course,

please remove it.

Mount data

Component data Name

Head number

托󱎭交󰀷器󳇮󲣄

在 DX 󲱉的送中失了元件。

如果在送途中或料站上有元件存在󰋋，󲣌取出。

󲨉装数据号

元件数据号名称

Head 号󱓖

Ea00387 TRAY CHANGER ERROR

The component was lost during transfer of DX axis.

If the component is on the station or transfer course,

please remove it.

Mount data

Component data Name

Head number

托󱎭交󰀷器󳇮󲣄

在 DX 󲱉的送中失了元件。

如果在送途中或料站上有元件存在󰋋，󲣌取出。

󲨉装数据号

元件数据号名称

Head 号󱓖

Ea00388 TRAY CHANGER ERROR

DX axis can't move, because DS axis position

safety sensor is OFF.

Please, check the following items:

- Sensor error

- Interference of an axis

托󱎭交󰀷器󳇮󲣄

 DX 󲱉的移，DS 󲱉于危󳌾位置。

可能因下列原因所致。󲣌确󲡹。

- 感器异常

- 󲱉的干

Ea00389 TRAY CHANGER ERROR

DS axis can't move, because DX axis position

safety sensor is OFF.

Please, check the following items:

- Sensor error

- Interference of an axis

托󱎭交󰀷器󳇮󲣄

 DS 󲱉的移，DX 󲱉于危󳌾位置。

可能因下列原因造成。󲣌确󲡹。

- 感器异常

- 󲱉的干

Ea00390 TRAY CHANGER ERROR

The pallet is out of the ExtTray magazine.

Please return the pallet to the magazine.

Stage No.

Magazine No.

托󱎭交󰀷器󳇮󲣄

料架从外部托󱎭的收󱮈柜中出。

󲣌将料架退回收󱮈柜。

基板台号󱓖

收󱮈柜号󱓖

Ea00391 TRAY CHANGER ERROR

ExtTray Magazine Clamp condition is illegal.

Please check fix of Magazine and Magazine Clamp

Stage No.

Magazine No.

托󱎭交󰀷器󳇮󲣄

外部托󱎭的收󱮈柜固定没有安装。

󲣌安装收󱮈柜固定。

基板台号󱓖

收󱮈柜号󱓖

Ea00392 TRAY CHANGER ERROR

The AutoTray magazine is protruded.

Please set the magazine correctly.

托󱎭交󰀷器󳇮󲣄

自托󱎭的󲱒料箱出。

󲣌正确安装收󱮈柜的󲱒料箱。

Ea00393 TRAY CHANGER ERROR

Failed to start the Hook Action.

Please check the following items:

1. The sensor of hook is broken.

2. The hook nail.

3. Pallet access position.

4. The magazine is put illegal position.

If the pallet is out of the magazine, then:

1. Be sure to press "EMERGENCY STOP" ON.

2. Remove the pallet from the stage section.

3. Return the pallet to its magazine.

托󱎭交󰀷器󳇮󲣄

抓手没能正常作。

󲣌注意下列󳕎目。

1. 抓手感器的作不良

2. 抓手的抓弯曲了

3. 将料架重新放入正确的位置上

4. 收󱮈柜没有正常󲲰行收󱮈

料架出了收󱮈柜󰋋，󲣌按下列󰠺󳝹理。

1. 按󱧼急停机按󳆃

2. 取出料架

3. 将料架放入收󱮈柜

Ea00394 TRAY CHANGER ERROR

Failed to start the ExtTray Head Action.

Please check the following items:

1. The sensor of ExtTray head is broken.

2. Part thickness on a pallet.

3. Tray thickness on a pallet.

托󱎭交󰀷器󳇮󲣄

外部托󱎭的 Head 不能正常作。

󲣌注意如下󳕎目。

1. Head 上升、下降感器的作不良。

2. 料架上的元件厚度

3. 料架上的托󱎭厚度

Ea00395 TRAY CHANGER ERROR 托󱎭交󰀷器󳇮󲣄

Comparison Table ( English - Chinese )

Code

CodeCode

Code

English

EnglishEnglish

English

Chinese

ChineseChinese

Chinese

Failed to servo-on because the tray changer door is open.

Please close the open door and press the 'READY' button again.

因托󱎭交󰀷器的柜󳊽敞着，所以无法使伺服 ON。

󲣌将敞着的柜󳊽󳋂，然后按[READY]按󳆃。

Ea00396 TRAY CHANGER ERROR

When parts were mounted, ExtTray detected the error.

There is a possibility of taking parts home to the station.

Please remove when there are parts on the station.

Station No.

托󱎭交󰀷器󳇮󲣄

使用外部托󱎭交󰀷器󲨉装元件󰋋，生了元件回󳇮󲣄。

如果料站上有元件存在󰋋，󲣌取出。

料站号󱓖

Ea00397 CONFIRMATION OF TRAY CHANGER MOVEMENT

The pallet is protruded from the magazine.

Please verify again that it can move the hook axis safely,

and restart Auto-Running.

托󱎭交󰀷器作确󲡹

料架出收󱮈柜后停止了。

了安全，󲣌在确󲡹抓手和料架可以安全移后，

重新始运行。

Ea00398 TRAY CHANGER TIMEOUT ERROR

The head and Tray changer could not shake hand.

Please inform follows No to the maker.

Error Detail

ATS CTRL No

ATS 超󰋋󳇮󲣄

主机准从 ATS 料架中吸附元件，但因与 ATS 无法

取得同󰠺而超󰋋了。

󲣌以下列号󱓖向制造厂商咨󲢷。

󳇮󲣄󲢻󱮛号󱓖

ATS CTRL 号󱓖

Ea00399 TRAY CHANGER ERROR

The reaction of the stage set sensor is abnormal.

Please confirm the state of the sensor and the palette.

托󱎭交󰀷器󳇮󲣄

基板台安装感器的反异常。

󲣌确󲡹感器和料架的状。

Ea00400 DISPENSE CHECK DATA ERROR

Pre Dispense data was defined for dot checking,

but that mark data does not exist in Mark Information.

Pre Dispense data

Mark data

胶点󰖕󰒺 数据󳇮󲣄

󲲰行胶点󰖕󰒺，󲍒已指定了󳕙点胶数据，

但󲢺数据的󰓜󲢅数据并不存在。

󳕙点胶数据号

󰓜󲢅数据号

Ea00401 DISPENSE CHECK DATA ERROR

"On dot station" was selected for dispense check,

but there is no dot station for this machine.

胶点󰖕󰒺 数据󳇮󲣄

󲲰行胶点󰖕󰒺，󲍒指定了打点站，

但此机器中没有装打点站。

Ea00402 DISPENSE CHECK DATA ERROR

Defined mark data for dispense check is illegal.

The mark type must be "Fiducial" or "DispenseDot".

Pre Dispense data

Mark data

胶点󰖕󰒺 数据󳇮󲣄

指定用于胶点󰖕󰒺的󰓜󲢅数据异常。

胶点󰖕󰒺所使用的󰓜󲢅数据中的󰓜󲢅󱥐型必󳕐

是"基准󰓜󲢅"或"胶点"。

󳕙点胶数据号

󰓜󲢅数据号

Ea00403 DISPENSE CHECK DATA ERROR

Defined head number for dispense check is illegal.

The head is not dispense head.

Pre Dispense data

Head number

胶点󰖕󰒺 数据󳇮󲣄

指定胶点󰖕󰒺用的点胶号󱓖异常。

指定的点胶号󱓖并非点胶。

󳕙点胶数据号

点胶号󱓖 号

Ea00404 DISPENSE CHECK DATA ERROR

Dispense check position is out of moving area.

Pre Dispense data

Axis

胶点󰖕󰒺 数据󳇮󲣄

指定胶点󰖕󰒺用的位置在󲱄极限外。

󳕙点胶数据号

󲱉名称

Ea00405 NO DEFINED DOT WAS FOUND.

Dispense fluid might have run out or the nozzle

is clogged up.

Head number

Press the EMG stop and ensure safety,

then remove the cause of this error.

胶液用完󰖕󰨠󳇮󲣄

以下点胶的胶液用完󰖕󰨠的󱮨果:

没有󱂅指定大小的胶点。

点胶号󱓖 号

可能胶液已用完、或吸嘴被堵塞。

󲣌按󱧼急停机按󳆃，确󲡹安全后，

排除故障原因。

Ea00406 DOT STATION DATA ERROR

In Board information, DOT STATION was defined to use.

But this machine does not equipped dot station.

Please correct the setting.

打点站数据󳇮󲣄

没有装配打点站的机器，

却在基板信息内󲢓置了使用打点站。

󲣌将󲢓置更改不使用打点站。

Ea00410 DOT RECOGNITION ERROR

Cannot calculate correction parameters for dot size

correction. The reason may be as follows.

- The number of measured dots is less than

the specified number.

- Timer for correction is 0.

- Total measured area is less than 0.01mm^2.

Please adjust the mark data for dot size

recognition.

Head number

胶点󲢛󳇮󲣄

无法󲲰行胶点尺寸校正。

可能由以下的原因造成。

- 未能󲢛最低󰔌品数以上的胶点。

- 校正󲡶󰋋 0。

- 已󰨠定面󱛄的合󲡶在 0.01mm^2 以下。

󲣌󲣘整胶点󲢛用的󰓜󲢅数据。

点胶号󱓖 号

Ea00412 DISPENSE CORRECTION LIMIT ERROR

The correction value of dispense is outside the range.

Please adjust the value of Min and Max correction of machine

setting to see you change Application conditions.

Head number

Cor. type

Std. area

Cor. area

点胶校正极限󳇮󲣄

点胶校正在范外。

󲣌更改涂胶条件，或󲣘整[机器󲢓置]-[点胶校正]画面的

最小校正、最大校正。

Head 号󱓖 号

校正󱥐型

基准面󱛄

󰨠定面󱛄
