Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 23 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Failed to servo-on because the tray changer door is open.
Please close the open door and press the 'READY' button again.
因托󱎭交󰀷器的柜󳊽敞着，所以无法使伺服 ON。
󲣌将敞着的柜󳊽󳋂，然后按[READY]按󳆃。
Ea00396 TRAY CHANGER ERROR
When parts were mounted, ExtTray detected the error.
There is a possibility of taking parts home to the station.
Please remove when there are parts on the station.
Station No.
托󱎭交󰀷器󳇮󲣄
使用外部托󱎭交󰀷器󲨉装元件󰋋，生了元件回󳇮󲣄。
如果料站上有元件存在󰋋，󲣌取出。
料站号󱓖
Ea00397 CONFIRMATION OF TRAY CHANGER MOVEMENT
The pallet is protruded from the magazine.
Please verify again that it can move the hook axis safely,
and restart Auto-Running.
托󱎭交󰀷器作确󲡹
料架出收󱮈柜后停止了。
了安全，󲣌在确󲡹抓手和料架可以安全移后，
重新始运行。
Ea00398 TRAY CHANGER TIMEOUT ERROR
The head and Tray changer could not shake hand.
Please inform follows No to the maker.
Error Detail
ATS CTRL No
ATS 超󰋋󳇮󲣄
主机准从 ATS 料架中吸附元件，但因与 ATS 无法
取得同󰠺而超󰋋了。
󲣌以下列号󱓖向制造厂商咨󲢷。
󳇮󲣄󲢻󱮛号󱓖
ATS CTRL 号󱓖
Ea00399 TRAY CHANGER ERROR
The reaction of the stage set sensor is abnormal.
Please confirm the state of the sensor and the palette.
托󱎭交󰀷器󳇮󲣄
基板台安装感器的反异常。
󲣌确󲡹感器和料架的状。
Ea00400 DISPENSE CHECK DATA ERROR
Pre Dispense data was defined for dot checking,
but that mark data does not exist in Mark Information.
Pre Dispense data
Mark data
胶点󰖕󰒺 数据󳇮󲣄
󲲰行胶点󰖕󰒺，󲍒已指定了󳕙点胶数据，
但󲢺数据的󰓜󲢅数据并不存在。
󳕙点胶数据 号
󰓜󲢅数据 号
Ea00401 DISPENSE CHECK DATA ERROR
"On dot station" was selected for dispense check,
but there is no dot station for this machine.
胶点󰖕󰒺 数据󳇮󲣄
󲲰行胶点󰖕󰒺，󲍒指定了打点站，
但此机器中没有装打点站。
Ea00402 DISPENSE CHECK DATA ERROR
Defined mark data for dispense check is illegal.
The mark type must be "Fiducial" or "DispenseDot".
Pre Dispense data
Mark data
胶点󰖕󰒺 数据󳇮󲣄
指定用于胶点󰖕󰒺的󰓜󲢅数据异常。
胶点󰖕󰒺所使用的󰓜󲢅数据中的󰓜󲢅󱥐型必󳕐
是"基准󰓜󲢅"或"胶点"。
󳕙点胶数据 号
󰓜󲢅数据 号
Ea00403 DISPENSE CHECK DATA ERROR
Defined head number for dispense check is illegal.
The head is not dispense head.
Pre Dispense data
Head number
胶点󰖕󰒺 数据󳇮󲣄
指定胶点󰖕󰒺用的点胶号󱓖异常。
指定的点胶号󱓖并非点胶。
󳕙点胶数据 号
点胶号󱓖 号
Ea00404 DISPENSE CHECK DATA ERROR
Dispense check position is out of moving area.
Pre Dispense data
Axis
胶点󰖕󰒺 数据󳇮󲣄
指定胶点󰖕󰒺用的位置在󲱄极限外。
󳕙点胶数据 号
󲱉名称
Ea00405 NO DEFINED DOT WAS FOUND.
Dispense fluid might have run out or the nozzle
is clogged up.
Head number
Press the EMG stop and ensure safety,
then remove the cause of this error.
胶液用完󰖕󰨠󳇮󲣄
以下点胶的胶液用完󰖕󰨠的󱮨果:
没有󱂅指定大小的胶点。
点胶号󱓖 号
可能胶液已用完、或吸嘴被堵塞。
󲣌按󱧼急停机按󳆃，确󲡹安全后，
排除故障原因。
Ea00406 DOT STATION DATA ERROR
In Board information, DOT STATION was defined to use.
But this machine does not equipped dot station.
Please correct the setting.
打点站 数据󳇮󲣄
没有装配打点站的机器，
却在基板信息内󲢓置了使用打点站。
󲣌将󲢓置更改不使用打点站。
Ea00410 DOT RECOGNITION ERROR
Cannot calculate correction parameters for dot size
correction. The reason may be as follows.
- The number of measured dots is less than
the specified number.
- Timer for correction is 0.
- Total measured area is less than 0.01mm^2.
Please adjust the mark data for dot size
recognition.
Head number
胶点󲢛󳇮󲣄
无法󲲰行胶点尺寸校正。
可能由以下的原因造成。
- 未能󲢛最低󰔌品数以上的胶点。
- 校正󲡶󰋋 0。
- 已󰨠定面󱛄的合󲡶在 0.01mm^2 以下。
󲣌󲣘整胶点󲢛用的󰓜󲢅数据。
点胶号󱓖 号
Ea00412 DISPENSE CORRECTION LIMIT ERROR
The correction value of dispense is outside the range.
Please adjust the value of Min and Max correction of machine
setting to see you change Application conditions.
Head number
Cor. type
Std. area
Cor. area
点胶校正极限󳇮󲣄
点胶校正在范外。
󲣌更改涂胶条件，或󲣘整[机器󲢓置]-[点胶校正]画面的
最小校正、最大校正。
Head 号󱓖 号
校正󱥐型
基准面󱛄
󰨠定面󱛄
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 24 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Cor. amount
Min. Cor.
Max. Cor.
校正量
最小校正
最大校正
Ea00413 DISPENSE CORRECTION ERROR
The amount of Min and Max correction of dispense
correction is inaccurate.
When correction is "1.0000", the value which becomes
an error is contained in Min and Max correction of
dispense correction.
Please adjust the value of Min and Max correction of
machine setting-dispense correction to straddle "1.0000".
Head number
Cor. type
点胶校正󳇮󲣄
点胶校正的最小校正、最大校正不正确。
点胶校正的最小校正、最大校正的校正 1.0000 󰋋，
含有引起󳇮󲣄的。
󲣘整[机器󲢓置]-[点胶校正]画面的最小校正、最大校正，
使其跨越 1.0000。
Head 号󱓖 号
校正󱥐型
Ea00414 DISPENSE CORRECTION ERROR
The amount of Min and Max correction of dispense
correction is inaccurate.
The value with the larger Min correction is contained
from Max correction.
Please adjust Min and Max correction of machine setting.
Head number
Cor. type
点胶校正󳇮󲣄
点胶校正的最小校正、最大校正不正确。
最小校正比最大校正大。
󲣌󲣘整[机器󲢓置]-[点胶校正]画面的最小校正、最大校正。
Head 号󱓖 号
校正󱥐型
Ea00434 Board DATA Dot Dispensing Pos. Warning!
Dot dispensing position is outside Pcb.
If you start production in this condition,
a head unit may be broken. Please check Pcb data again.
Dot Dispense data
基板程序 正式点胶位置 警告
正式点胶位置偏离了基板。
如󱮼󱯂󲲰行，点胶与送装置生干，
可能会造成破󰀴。
󲣌重新确󲡹数据。
正式点胶数据 号
Ea00435 BOARD DATA Pre Dispensing Height Warning!
Pre dispensing Height is too low.
If you execute auto-running in this condition,
a head unit may be broken. Please check data again.
1)Lower end position is below the normal height + 0.5mm.
2)Z height for next job is below the normal height - 0.5mm.
3)Lower end position is above Z height for next job.
4)Z height for next job is above upend position.
Pre Dispense data
基板程序 󳕙点胶高度 警告
󳕙点胶󰋋的高度太低。
如󱮼󱯂󲲰行，点胶可能会破󰀴。
󲣌重新确󲡹󲢓置。
·下降目󰓜位置，低于基准高度+0.5mm 。
·下次作容󲢍高度，低于基准高度-0.5mm。
·下降目󰓜位置，高于下次作容󲢍的高度。
·下次作容󲢍高度，高于上升目󰓜位置。
󳕙点胶数据 号
Ea00436 BOARD DATA Dot Dispensing Height Warning!
Pre dispensing Height is too low.
If you execute auto-running in this condition,
a head unit may be broken. Please check Pcb data again.
1)Lower end position is below the pcb height + 0.5mm.
2)Z height for next job is below the pcb height - 0.5mm.
3)Lower end position is above Z height for next job.
4)Z height for next job is above upend position.
Dot Dispense data
基板程序 正式点胶高度 警告
正式点胶󰋋的高度太低。
如󱮼󱯂󲲰行，点胶可能会破󰀴。
󲣌重新确󲡹󲢓置。
·下降目󰓜位置， 低于基板面高度+0.5mm 。
·下次作容󲢍高度，低于基板面高度-0.5mm。
·下降目󰓜位置，高于下次作容󲢍的高度。
·下次作容󲢍高度，高于上升目󰓜位置。
正式点胶/作流程数据 号
Ea00437 BOARD DATA ERROR
Illegal setting of "Retry Seq." in Board Info.
If you want to use "Part Group No." in Part Info.,
change "Retry Seq." to "Group" or "Block".
基板程序󳇮󲣄
重新行方式"自"。
使用元件󱮙号󱓖󰋋，󲣌把基板信息的
重新行方式󲢓置"󱮙"或是"拼"。
Ea00438 BOARD DATA ERROR
Board Size Z is an illegal value.
Please check it and input the correct value.
基板程序󳇮󲣄
基板外形 Z(基板厚度)的󲢓置异常。
󲣌按照基板，󲢓置正确的基板厚度。
Ea00439 BOARD DATA ERROR
Trans Height is outside moving area.
Axes
基板程序󳇮󲣄
基板送高度在作范外。
󲱉名称
Ea00441 BOARD DATA ERROR
Only 'STOP 'Error Sequence of mark data are
available for Board Fiducial.
Please check and correct the mark data.
基板程序󳇮󲣄
基板基准󰓜󲢅不能指定停止以外的󳇮󲣄理。
󲣌修改󰓜󲢅数据。
Ea00442 BOARD DATA ERROR
Only 'STOP 'Error Sequence of mark data are
available for Point Fiducial.
Please check and correct the mark data.
Mount data
Fiducial data
Mark data
基板程序󳇮󲣄
点基准󰓜󲢅不能指定停止以外的󳇮󲣄理。
󲣌修改󰓜󲢅数据。
󲨉装数据 号
基准󰓜󲢅数据 号
󰓜󲢅数据 号
Ea00443 PLEASE CHECK FOR ANY ILLEGAL RUNNING CONDITION
There is possibility that hits components.
注意: 运行条件异常
运行条件󲢓置不适合生。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 25 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Because the mount height offset is large.
If all are OK, please continue.
确󲡹后，如果没󳋃󳕭，󲣌󱮼󱯂。
因󲨉装高度偏差量󲲜大，元件可能干。
Ea00444 DATA CHECK ERROR
Unknown error.
程序󰖕󰒺󳇮󲣄
󲲮是原因不明的󳇮󲣄。
Ea00445 BOARD DATA ERROR
Too many mount data.
基板程序󳇮󲣄
󲨉装数据数多于󲚙定数。
Ea00446 BOARD DATA ERROR
Too many dot-dispense data.
基板程序󳇮󲣄
正式点胶数据数多于󲚙定数。
Ea00447 BOARD DATA ERROR
Too many pre-dispense data.
基板程序󳇮󲣄
󳕙点胶数据数多于󲚙定数。
Ea00449 BOARD DATA ERROR
The nozzle selected in component info. is not
available for stamping action.
Select appropriate one.
Component data Name
基板程序󳇮󲣄
在元件信息中指定使用的吸嘴，
不能󲲰行󳅝浸胶作。
󲣌󲳞适用󳅝浸胶的吸嘴。
元件数据 号 名称
Ea00452 DATA CHECK ERROR
Current Board data has some data error.
Please read same Board data, and correct wrong data.
程序󰖕󰒺󳇮󲣄
当前󲣐入的基板程序，没有󲲰行程序󰖕󰒺。
󲣌重新󲣐入基板程序，修改程序󳇮󲣄之。
Ea00453 SPECIAL DUMP BACK WARNING
The function "Sp. Dump Back" cannot be used for
Ext. Tray Changer like YTF80W.
Please check "Dump Way" in Component Information.
特殊返󲲭理󳇮󲣄
YTF80W 等外部托󱎭交󰀷器不能使用[特殊返󲲭理]的弃方法。
󲣌更改元件信息中弃方法的󲢓置。
Ea00454 BOARD DATA ERROR
CO-PLANARITY CHECK is available only when the datum
angle is 0 degree.
Mount data
Component data Name
基板程序󳇮󲣄
形状基准角度在 0 度以外的状下，
不能施引脚󱲭起󰖕出。
󲨉装数据 号
元件数据 号 名称
Ea00455 Board DATA ERROR
Fiducial skip function can not be used
with tray changer unless it is accompanied
with the all fiducial check function.
基板程序󳇮󲣄
只要基准󰓜󲢅跳󲲜功能不与全基准󰓜󲢅功能并用，
就不能同󰋋使用托󱎭交󰀷器。
Ea00456 BOARD DATA ERROR
At the following head,
the vision type of the dispense nozzle is not defined.
Please set the type.
Head Number No.
基板程序󳇮󲣄
没有󲢓置下列点胶号󱓖的点胶嘴的校正󱥐型。
󲣌󲢓置校正󱥐型。
点胶号󱓖 号
Ea00457 BOARD DATA ERROR
At the following head,
the vision type of the dispense nozzle is illegal.
The dispense vision data for the type does not exist.
Please change to the correct type.
Head Number No.
基板程序󳇮󲣄
下列点胶号󱓖的点胶嘴的校正󱥐型不正确。
所󲢓置的校正󱥐型用的点胶校正数据不存在。
󲣌更改正确的校正󱥐型。
点胶号󱓖 号
Ea00458 TRAY PRECEDE ERROR
In case of component supply from ATS,
if the Dump way set to [Sp.Dump Back],
the Tray Precede function cannot be used.
Please set Tray Precede to [Not Use].
托󱎭先󳇮󲣄
ATS 元件的弃方法󲢓置特殊返󲲭理󰋋，
不能使用托󱎭先功能。
󲣌把托󱎭先󲢓置[不行]。
Ea00459 CONFIRMATION OF BLOW MODE
Blow Mode is not set to "Normal".
This could have a negative influence on production.
Please confirm the Blow mode setting.
󲨉装󰋋的排气方式确󲡹
[机器󲢓置]1 画面中󲨉装󰋋的排气方式不是"普通"。
可能无法在最佳条件下󲲰行生。
Ea00460 Multi-Macs Data Error
Multi-Macs data in Machine Data is not correct.
This condition is not good for mounting accuracy.
Please adjust Multi-Macs data in Adjust Utility.
Multi-MACS 数据󳇮󲣄
[机器󲢓置]画面所󲢓置的 Multi-MACS 的校正基准异常。
如󱮼󱯂运行，不能正常生。
󲣌在[机器󲢓置]画面重新󲣘整 Multi-MACS 校正基准。
Ea00461 PLEASE CHECK FOR BOARD SIZE HEIGHT
Board Size Height is "0".
If OK, please continue.
注意: 基板厚度数据异常
在基板程序中所󲢓置的基板厚度的数"0"。
确󲡹后，如没有󳋃󳕭，󲣌󱮼󱯂运行。
Ea00462 BOARD DATA Pre-Dispensing Pos. Warning!
Pre-Dispensing position is outside the Pcb or Dot-Station.
If you start production in this condition,
a head unit may be broken. Please check Board data again.
Pre-Dispense data
基板程序 󳕙点胶位置 警告
󳕙点胶坐󰓜在基板或打点站上的范外。
如󱮼󱯂󲲰行，点胶可能与送装置等生干，造成破󰀴。
󲣌重新确󲡹数据。
󳕙点胶数据 号
Ea00463 BOARD DATA Pre-Dispensing Pos. Warning!
Pre-Dispensing position added Y+20mm for checking is
outside the Dot-Station.
If you start production in this condition,
a head unit may be broken. Please check Board data again.
基板程序 󳕙点胶位置 警告
校正量确󲡹作用的󳕙点胶坐󰓜在打点站上的范外。
如󱮼󱯂󲲰行，点胶与送装置等可能生干，造成破󰀴。
󲣌重新确󲡹数据。
󳕙点胶数据 号
