Comparison Table ( English - Chinese ) VGOS V2.46STD R1.000 226 / 237 Copyright (C) 2009 Y amaha Motor Co.,Ltd. All Rights Reserved. Code Code Code Code Englis h Englis h Englis h Englis h Chinese Chinese Chinese Chinese…
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 225 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Start Pallet No.
End Pallet No.
料架始号 号
料架束号 号
Ea29042 Auto tray changer Component empty warning
Refill the following tray component and push the indicator button.
The component is empty, because the indicator button is not pushed.
Component Name Comment
Start Pallet No.
End Pallet No.
自托元件未充警告
充以下的托元件、并按指示器按。
因未按指示器按，所以,元件呈空的状。
元件名称 注
料架始号 号
料架束号 号
Ea29043 Auto tray changer Component empty warning
Refill the following tray component and push the indicator button.
The component is empty, because the indicator button is not pushed.
Component Name Comment
Start Pallet No.
End Pallet No.
自托元件未充警告
充以下的托元件、并按指示器按。
因未按指示器按，所以,元件呈空的状。
元件名称 注
料架始号 号
料架束号 号
Ea29049 Auto tray changer Component Empty
Cannot start production, because following component is empty.
After supplement component and
perform component supplement operation with Setup-TrayCnt,
restart production, please.
Component Name Comment
Start Pallet No.
End Pallet No.
自托交器 元件用完
由于下列元件呈空的状，运行无法始。
充元件，并在安装-托数中行元件充操作后，
重新始运行。
元件名称 注
料架始号
料架束号
Ea29050 Auto tray changer Pallet return error
Failed to store the pallet.
To start production again, please return the pallet
to its assigned magazine.
Mount data
Component data Name
Pallet
自托交器 料架退回
未能将料架退回到收柜。
重新始生，将料架放回到收柜。
装数据 号
元件数据 号 名称
料架号 号
Ea29051 Ext. tray changer Pallet return error
Failed to return the pallet to the magazine,
because the state of following sensors are mis-match.
Please return the pallet on the stage into the magazine.
Stage No.
Pallet No.
Hook pallet exist sensor: Undetect pallet
Stage set sensor: Detect pallet
外部托交器 料架退回
因以下感器生了，
所以没能将料架退回收柜。
将抽出到料架台的料架放回到收柜。
料架台号 号
料架号 号
有无抓手料架感器 未出料架
料架台抽出感器 出料架
Ea29052 Auto tray changer Pallet set error
Failed to pull out the pallet.
To start production again, please return the pallet
to its assigned magazine.
Mount data
Component data Name
Pallet
自托交器 料架抽出
未能从收柜抽出料架。
再次启生，将料架放回到收柜。
装数据 号
元件数据 号 名称
料架号 号
Ea29053 Ext. tray changer Pallet set error
Failed to pull out the pallet.
Please check the pallet doesn't exist on the stage and restart production.
Stage No.
Pallet No.
Stage set sensor: Undetect pallet
外部托交器 料架抽出
未能从收柜抽出料架。
在确料架台上没有料架后再次行。
料架台号 号
料架号 号
料架台抽出感器 未出料架
Ea29054 Auto tray Changer Pallet return error
Failed to store the pallet.
To start production again, please return the pallet
to its assigned magazine.
自托交器 料架退回
未能将料架退回到收柜。
将料架放回到收柜。
Ea29055 Ext. tray changer Pallet return error
Failed to return the pallet to the magazine,
because the state of following sensors are mis-match.
Please return the pallet on the stage into the magazine.
Stage No.
Pallet No.
Hook pallet exist sensor: Undetect pallet
Stage set sensor: Detect pallet
外部托交器 料架退回
因以下感器生了，
所以没能将料架退回收柜。
将抽出到料架台的料架放回到收柜。
料架台号 号
料架号 号
有无抓手料架感器 未出料架
料架台抽出感器 出料架
Ea29056 Auto tray changer Pallet set error
Failed to pull out the pallet.
To start production again, please return the pallet
to its assigned magazine.
自托交器 料架抽出
未能从收柜抽出料架。
将料架放回到收柜。
Ea29057 Ext. tray changer Pallet set error
Failed to pull out the pallet.
Please check the pallet doesn't exist on the stage and restart production.
Stage set sensor: Undetect pallet
外部托交器 料架抽出
未能从收柜中抽出料架。
在确料架台上没有料架后再次行。
料架台号 号
料架号 号
料架台抽出感器 未出料架
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 226 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Ea29058 Auto tray changer Pallet set error
The head of the machine is picking a component.
If "SET PALLET" is executed, component will drop from head.
Remove component from head and execute "SET PALLET" again.
自托交器 料架抽出
机器或自托交器吸附着元件的状。
此行料架抽出，元件可能掉落。
取出吸附状的元件，并再次行。
Ea29059 Ext. tray changer Pallet set error
The head of the machine or ext. tray changer is picking a component.
If "SET PALLET" is executed, the part will drop from head.
Remove component from the head and retry "SET PALLET" again.
again.
外部托交器 料架抽出
机器或自托交器吸附着元件的状。
此行料架抽出，元件可能掉落。
取出吸附状的元件，并再次行。
Ea29060 Auto tray changer Pallet return error
The destination magazine column is already occupied by another pallet.
Please check whether the pallet isn't set at wrong column.
And please check whether the Pallet Close sensor points to correct position.
Mount data
Component data Name
Pallet No.
Pallet close sensor: Detect pallet
自托交器 料架退回
料架退回位置上已有其他料架存在。
确料架是否安装在了的位置上，
料架退回感器是否指向正确的位置。
装数据 号
元件数据 号 名称
料架号 号
料架退回感器 出料架
Ea29061 Ext. tray changer Pallet return error
The destination magazine column is already occupied by another pallet.
Please check whether the pallet isn't set at wrong column.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Pallet No.
Pallet close sensor: Detect pallet
外部托交器 料架退回
料架退回位置上已有其他料架存在。
确料架是否安装在了的位置上，
料架退回感器是否指向正确的位置。
料架台号 号
料架号 号
料架退回感器 出料架
Ea29062 Auto tray changer Pallet return error
The destination magazine column is already occupied by another pallet.
Please check whether the pallet isn't set at wrong column.
And please check whether the Pallet Close sensor points to correct position.
Pallet close sensor: Detect pallet
自托交器 料架退回
料架退回位置上已有其他料架存在。
确料架是否安装在了的位置上，
料架退回感器是否指向正确的位置。
料架退回感器 出料架
Ea29063 Ext. tray changer Pallet return error
The destination magazine column is already occupied by another pallet.
Please check whether the pallet isn't set at wrong column.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Pallet No.
Pallet close sensor: Detect pallet
外部托交器 料架退回
料架退回位置上已有其他料架存在。
确料架是否安装在了的位置上。
料架退回感器是否指向正确的位置。
料架台号 号
料架号 号
料架退回感器 出料架
Ea29064 Auto tray changer Pallet set error
There is no designated pallet.
Please check whether the pallet and the magazine are set correctly.
Mount data
Component data Name
Pallet
自托交器 料架抽出
指定的料架不存在。
确料架及收柜是否已正确安装。
装数据 号
元件数据 号 名称
料架号 号
Ea29065 Ext. tray changer Pallet set error
There is no designated pallet in the magazine.
Please check whether the pallet is set at correct column.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Pallet No.
Pallet close sensor: Undetect pallet
外部托交器 料架抽出
指定的料架不在收柜中。
确料架是否已正确安装在指定位置上，
料架退回感器是否指向正确的位置。
料架台号 号
料架号 号
料架退回感器 未出料架
Ea29066 Auto tray changer Pallet set error
There is no designated pallet.
Please check whether the pallet and the magazine are set correctly.
自托交器 料架抽出
指定的料架不存在。
确料架及收柜是否已正确安装。
Ea29067 Ext. tray changer Pallet set error
There is no designated pallet in the magazine.
Please check whether the pallet is set at correct column.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Pallet No.
Pallet close sensor: Undetect pallet
外部托交器 料架抽出
指定的料架不在收柜中。
确指定的位置上是否正确安装了料架，
料架退回感器是否指向正确的位置。
料架台号 号
料架号 号
料架退回感器 未出料架
Ea29068 Auto tray changer Pallet set error
There is no designated pallet.
Please check whether the pallet and the magazine are set correctly.
Pallet
自托交器 料架抽出
指定的料架不存在。
确料架及收柜是否已正确安装。
料架号
Ea29069 Auto tray changer Pallet set error
The operation of manual pallet set was interrupted by emergency stop.
There is a possibility that the position of the pallet is not correct.
After releasing the "EMERGENCY STOP",
Please make the door switch into 'close' and return the pallet.
自托交器 料架抽出
由急停机等手工料架抽出作中断了。
料架可能没有在正确的位置上。
解除急停机后，打柜，安装好料架。
Ea29070 Auto tray changer Pallet set error
Can not start production because the operation of manual pallet set is not
completed.
Please put the pallet back in the magazine by opening the door again,
自托交器 料架抽出
因手工料架抽出作未完成，所以不能始自运行。
打柜并安装好料架，再重新始自运行。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 227 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
and restart the production.
Ea29071 Ext. tray changer Pallet set error
The head of the machine is picking a component.
If "SET PALLET" is executed, component will drop from head.
Remove component from head and execute "SET PALLET" again.
外部托交器 料架抽出
机器的 Head 正在吸附元件。
行料架抽出，可能致元件掉落。
取出吸附状的元件，并再次行。
Ea29072 Ext. tray changer Pallet set error
The head of the Ext. tray changer is picking a component.
If "SET PALLET" is executed, component will drop from head.
Remove component from head and execute "SET PALLET" again.
外部托交器 料架抽出
外部托交器的 Head 正在吸附着元件。
行料架抽出，可能致元件掉落。
取出吸附状的元件，并再次行。
Ea29073 Ext. tray changer Pallet set error
Cannot set the designated pallet, because the magazine is not set.
Please check whether the magazine of designated pallet is set correctly.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Magazine No.
Pallet No.
Magazine set sensor: Undetect magazine
外部托交器 料架抽出
因没有安装收柜，所以不能抽出指定的料架。
确指定料架的收柜是否已正确置，
收柜安装感器是否正常感。
料架台号 号
收柜号 号
料架号 号
收柜安装感器 未出收柜
Ea29074 Ext. tray changer Pallet set error
Cannot set the designated pallet, because the magazine is not set.
Please check whether the magazine of designated pallet is set correctly.
And please check whether the Pallet Close sensor points to correct position.
Stage No.
Magazine No.
Pallet No.
Magazine set sensor: Undetect magazine
外部托交器 料架抽出
因没有安装收柜，所以不能抽出指定的料架。
确指定料架的收柜是否已正确置，
收柜安装感器是否正常感。
料架台号 号
收柜号 号
料架号 号
收柜安装感器 未出收柜
Ea29075 Auto tray changer Dump only pallet set error
There is no designated pallet.
Please check whether the pallet and the magazine are set correctly.
Pallet
自托交器 弃用料架安装
不存在所指定的弃用料架。
确料架以及收柜是否安装正确。
安装料架后，重新始自运行。
料架号 号
Ea29076 Auto Tray Failed to return pallet
Returning pallet was failed for pallet close sensor non-detection.
There is danger of pallet crash in this state.
Please be sure to do the following operation.
1. Confirm whether there is no pallet on the pallet stage.
2. Remove by the hand when a pallet exists on the pallet stage.
Stage No.
Pallet No.
自托料架退回失
料架退回失。料架退回用感器不感。
如持此状，料架有碰撞的危，
所以必按照以下位。
1. 确料架是否从收柜出。
2. 如有料架出，用手推回收柜。
料架台号 号
料架号 号
Ea29080 Auto tray changer Component empty
Component counter reached specified number.
Refill the components and run again.
Component data Name
Start Pallet No.
End Pallet No. [CNTcmp_inf5]
自托交器 元件用完
使用元件数已达到定数目。
充下列元件后，重新始运行。
元件数据 号 名称
料架始号 号
料架束号 [CNTcmp_inf5]号
Ea29081 Ext. tray changer Component empty
Component counter reached specified number.
Refill the components and run again.
Component data Name
Start Pallet No.
End Pallet No. [CNTcmp_inf5]
外部托交器 元件用完
使用元件数已达到定数目。
充下列元件后，重新始运行。
元件数据 号 名称
料架始号 号
料架束号 [CNTcmp_inf5]号
Ea29082 Auto tray changer Component empty
All components in alternative loop are not available.
This can be caused by the followings:
- Pick up or recognition error happened.
- Component counter reached specified number.
Refill the components or check trays and run again.
Component data
Start Pallet No.
End Pallet No.
自托交器 元件用完
替代元件循的全部元件不可使用的状。
原因如下：
- 生了吸附或。
- 使用元件数已达到定数目。
充下列元件后，重新始运行。
元件数据 号
料架始号 号
料架束号 号
Ea29083 Ext. tray changer Component empty
All components in alternative loop are not available.
This can be caused by the followings:
- Pick up or recognition error happened.
- Component counter reached specified number.
Refill the components or check trays and run again.
Component data
Start Pallet No.
End Pallet No.
外部托交器 元件用完
替代元件循的全部元件不可使用的状。
原因如下：
- 生了吸附或。
- 使用元件数已达到定数目。
充下列元件后，重新始运行。
元件数据 号
料架始号 号
料架束号 号
Ea29084 Auto tray changer Components empty
All components in alternative loop are not available.
This can be caused by the followings:
- Door of auto tray changer was opened.
自托交器 元件用完
因柜敞或元件用完等原因，
不能使用下列元件。
柜或充元件后，重新始运行。
