Comparison Table ( English - Chinese ) VGOS V2.46STD R1.000 187 / 237 Copyright (C) 2009 Y amaha Motor Co.,Ltd. All Rights Reserved. Code Code Code Code Englis h Englis h Englis h Englis h Chinese Chinese Chinese Chinese…
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 186 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Time to start recording the cleaner action. 清装置作的始
Ea14602 Unit Log - Cleaner - Counter
Number of cleaner actions.
履 2 清装置 作次数
清装置作的次数
Ea14603 Unit Log - Cleaner - Error Counter
Number of errors concerning the cleaner actions.
履 2 清装置 作出次数
清装置作的出次数
Ea14604 Unit Log - Cleaner - Error per cent(%)
The ratio of the cleaner error to the squeegee action count.
履 2 清装置 出率(%)
清装置的 作出次数/作次数 的比率
Ea14610 MIS - MIS by Board - Board Count Max
The production schedule number of boards specified when this board is produced.
履 1 各基板 定生枚数
生基板所指定的定生枚数。
Ea14611 MIS - MIS by Board - Produced Boards
The number of boards that is actually produced until production ended.
(boards that were not completed production are not counted)
履 1 各基板 装枚数
用此基板程序装的基板枚数
Ea14612 MIS - MIS by Board - Produced Blocks
The number of Blocks that is actually produced until production ended.
履 1 各基板 装拼数
用基板程序装的拼数
Ea14613 MIS - MIS by Board - A-Table Mount CT
Average mounting time per Board in this lot.
履 1 各基板 A 工作台 装的 TACT
基板程序生中，平均 1 枚基板所装的(秒)
Ea14614 MIS - MIS by Board - A-Table Mount CT
Average mounting time per Board in this lot.
履 1 各基板 B 工作台 装的 TACT
基板程序生中，平均 1 枚基板所装的(秒)
Ea14615 MIS - MIS by Board - C-Table Mount CT
Average mounting time per Board in this lot.
履 1 各基板 C 工作台 装的 TACT
基板程序生中，平均 1 枚基板所装的(秒)
Ea14616 MIS - MIS by Board - D-Table Mount CT
Average mounting time per Board in this lot.
履 1 各基板 D 工作台 装的 TACT
基板程序生中，平均 1 枚基板所装的(秒)
Ea14617 MIS - MIS by Board - Transfer CT
Average transfer time per Board in this lot.
履 1 各基板 送 TACT
基板程序生中，平均 1 枚基板所装的(秒)
Ea14618 MIS - MIS by Board - Standby CT
Average standby time per Board in this lot.
履 1 各基板 待机
基板程序生中，平均 1 枚基板所装的(秒)
Ea14619 MIS - MIS by Board - Transfer In Board
Number of boards that have been transferred into the machine in this lot.
履 1 各基板 入枚数
基板程序生中，已入机器的基板枚数
Ea14620 MIS - MIS by Board - Transfer Out Board
Number of boards that have been transferred out of the machine in this lot.
履 1 各基板 出枚数
基板程序生中，从机器出的基板枚数
Ea14621 MIS - MIS by Board - Mount Rate
Same as Estimated Pick Up Rate of current Production History.
Pick Up Error: PE
Vision Error: VE
Nozzle Error: NE
No Part Error: NoCmp
Total parts consumption :Consumption
Mount Rate(%) = (1 - (PE+VE+NE-NoCmp) /
(Consumption-NoCmp)) * 100
履 1 各基板 装率
吸料出次数 ：PE
出次数 ：VE
吸嘴出次数 ：NE
无元件出次数：NoCmp
元件消耗量 ：Consumption
装率(%) = (1-(PE+VE+NE-NoCmp)/(Consumption-NoCmp))*100
Ea14622 MIS - MIS by Board - PickUp Error
The number of pick up error in this Board production. (include retry)
履 1 各基板 吸料出次数
基板程序生中所生吸料的次数(包含重新行)
Ea14623 MIS - MIS by Board - PickUp Error Rate
Pick Up Error: PE
No Part Error which counted by Pick Up Error: NoCmpPick
Total parts consumption: Consumption
(PE - NoCmpPick)/Consumption * 100%
履 1 各基板 吸料率
吸料出次数: PE
无元件出次数中吸料出次数: NoCmpPick
元件消量: Consumption
(PE - NoCmpPick)/Consumption * 100%
Ea14624 MIS - MIS by Board - Vision Error
The number of vision error in this board production. (include retry)
履 1 各基板 出次数
基板程序生中，所生的次数(包含重新行)
Ea14625 MIS - MIS by Board - Vision Error Rate
Vision Error: VE
No Part Error which counted by Vision Error: NoCmpVis
Total parts consumption: Consumption
(VE - NoCmpVis)/Consumption * 100%
履 1 各基板 出率
出次数: VE
无元件出次数中吸料出次数: NoCmpVis
元件消量: Consumption
(VE - NoCmpVis)/Consumption * 100%
Ea14626 MIS - MIS by Board - Nozzle Error
The number of nozzle error in this board production. (include retry)
履 1 各基板 吸嘴出次数
基板程序生中，所生吸嘴的次数(包含重新行)
Ea14627 MIS - MIS by Board - Nozzle Error Rate
Nozzle Error: NE
No Part Error which counted by Nozzle Error: NoCmpNzl
Total parts consumption: Consumption
(NE - NoCmpNzl)/Consumption * 100%
履 1 各基板 吸嘴出率
吸嘴出次数: NE
无元件出次数中吸嘴出次数: NoCmpNzl
元件消量: Consumption
(NE - NoCmpNzl)/Consumption * 100%
Ea14628 MIS - MIS by Board - No Parts Error
The number of no component error in this board production. (include retry)
履 1 各基板 无元件出次数
基板程序生中无元件的数次数(包含重新行)
Ea14629 MIS - MIS by Board - Consumption
The total amount of components in this Board data.
It is counted spent component in Auto Running.
It does not include test pick up (ex. Adjust Assist)
履 1 各基板 元件消耗量
基板程序生中所消耗的元件数。
算自运行中所消耗的元件数，
但因使用元件整功能所消耗的元件不被数。
Ea14630 MIS - MIS by Board - Parts Info. - P.No. 履 1 各基板 各元件信息 元件号
Ea14631 MIS - MIS by Board - Parts Info. - Part Name
Component name
履 1 各基板 各元件信息 元件名称
元件名称
Ea14632 MIS - MIS by Board - Parts Info. - Feeder Type 履 1 各基板 各元件信息 送料器型
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 187 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Feeder type 使用送料器型
Ea14633 MIS - MIS by Board - Parts Info. - Feeder Set No.
Feeder set number
履 1 各基板 各元件信息 安装号
送料器安装号
Ea14634 MIS - MIS by Board - Parts Info. - Start Date
The date of starting production for this Board data
履 1 各基板 各元件信息 始
基板程序生始的
Ea14635 MIS - MIS by Board - Parts Info. - Mount Rate
Mount rate of this component. How to calculate is same as in Board Info.
履 1 各基板 各元件信息 装率
元件的装率。算方法与枚数 TACT 信息的装率相同。
Ea14636 MIS - MIS by Board - Parts Info. - Total Pick Up Error
The number of pick up error for this component
履 1 各基板 各元件信息 吸料出次数
元件生吸料的次数
Ea14637 MIS - MIS by Board - Parts Info. - Total Vision Error
The number of vision error for this component
履 1 各基板 各元件信息 出次数
元件生的次数
Ea14638 MIS - MIS by Board - Parts Info. - Total Nozzle Error
The number of nozzle error for this component
履 1 各基板 各元件信息 吸嘴出次数
元件生吸嘴的次数
Ea14639 MIS - MIS by Board - Parts Info. - Total No Parts Error
The number of no component error for this component
履 1 各基板 各元件信息 无元件出次数
元件生无元件的次数
Ea14640 MIS - MIS by Board - Parts Info. - Total Parts Consumption
The total amount of components.
It is counted spent component in Auto Running.
It is not include test pick up (ex. Adjust Assist)
履 1 各基板 各元件信息 元件消耗量
元件的元件消耗
Ea14641 MIS - MIS by Board - Parts Info. - Pick Up Error
The number of pick up error of head in this component
履 1 各基板 各元件信息 吸料出次数
元件吸料中， Head 所生的次数
Ea14642 MIS - MIS by Board - Parts Info. - Vision Error
The number of vision error of head in this component
履 1 各基板 各元件信息 出次数
元件中， Head 所生的次数
Ea14643 MIS - MIS by Board - Parts Info. - Nozzle Error
The number of nozzle error of head in this component
履 1 各基板 各元件信息 吸嘴次数
元件吸嘴中的在此 Head 中的次数
Ea14644 MIS - MIS by Board - Parts Info. - No Parts Error
The number of no parts error of head in this component
履 1 各基板 各元件信息 无元件次数
元件无元件中的在此 Head 中的次数
Ea14645 MIS - MIS by Board - Parts Info. - Parts Consumption
The amount of components picked by head
履 1 各基板 各元件信息 元件消耗量
元件元件消耗量中，使用 Head 的次数
Ea14650 MIS - MIS by Board - Head Info - Head No.
履 1 各基板 各 Head 信息 Head 号
Ea14651 MIS - MIS by Board - Head Info - Head Type
Nozzle change type of each head.
AutoNzlChg, ManualNzlChg etc.
履 1 各基板 各 Head 信息 Head 型
Head 的吸嘴交型
自吸嘴交、手吸嘴交等
Ea14652 MIS - MIS by Board - Head Info - Start Time
The date of starting production for this Board data
履 1 各基板 各 Head 信息 始
始生基板程序的
Ea14653 MIS - MIS by Board - Head Info - Mount Rate
Mount rate of this head.
How to calculate is same as in Board Info.
履 1 各基板 各 Head 信息 装率
Head 的装率。算方法与枚数 TACT 信息的装率相同。
Ea14654 MIS - MIS by Board - Head Info - Total PickUp Error
The number of pick up error for this head
履 1 各基板 各 Head 信息 吸料出次数
Head 生吸料的次数
Ea14655 MIS - MIS by Board - Head Info - Total Vision Error
The number of vision error for this head
履 1 各基板 各 Head 信息 出次数
Head 生的次数
Ea14656 MIS - MIS by Board - Head Info - Total Nozzle Error
The number of nozzle error for this head
履 1 各基板 各 Head 信息 吸嘴出次数
Head 生吸嘴的次数
Ea14657 MIS - MIS by Board - Head Info - Total No Parts Error
The number of no parts error for this head
履 1 各基板 各 Head 信息 无元件出次数
Head 生无元件的次数
Ea14658 MIS - MIS by Board - Head Info - Total Parts Consumption
The amount of component which picked by this head
履 1 各基板 各 Head 信息 元件消耗量
Head 所消耗的元件数
Ea14659 MIS - MIS by Board - Head Info - PickUp Error
The number of this head's pick up error which were picked with this nozzle
履 1 各基板 各 Head 信息 吸料出次数
Head 吸料中，吸嘴所生的次数
Ea14660 MIS - MIS by Board - Head Info - Vision Error
The number of this head's vision error which were picked with this nozzle
履 1 各基板 各 Head 信息 出次数
Head 中，吸嘴所生的次数
Ea14661 MIS - MIS by Board - Head Info - Nozzle Error
The number of this head's nozzle error which were picked with this nozzle
履 1 各基板 各 Head 信息 吸嘴出次数
Head 吸嘴中，吸嘴所生的次数
Ea14662 MIS - MIS by Board - Head Info - No Parts Error
The number of this head's no parts error which were picked with this nozzle
履 1 各基板 各 Head 信息 无元件出次数
Head 无元件中，吸嘴所生的次数
Ea14663 MIS - MIS by Board - Head Info - Parts Consumption
The amount of components of this head which were picked by this nozzle
履 1 各基板 各 Head 信息 元件消耗量
Head 消耗量中，吸嘴所消耗的数量
Ea14680 Unit log -Feeder ID -Feeder ID
Barcode sticked to the feeder or "ID of CLi Feeder" is displayed.
履 2 送料器 ID 送料器 ID
示粘在送料器主体上的条形或 CLi 送料器的 ID。
Ea14681 Unit log -Feeder ID -Feeder Type
"Feeder Type" is displayed.Methods of distinguishing feeder type are as follows:
1. By analyzed "ID of CLi Feeder".
2. By extracted from Parts data installed to the feeder.
履 2 送料器 ID 送料器型
示送料器型名。
既可以从 CLi 送料器的 ID 辨送料器型，
也可以从安装在送料器上的元件的数据辨送料器型。
Ea14682 Unit log -Feeder ID -Parts
"Parts Name" is displayed.
履 2 送料器 ID 元件名称
示元件名称。
Ea14683 Machine num 机器号
Ea14684 Unit log -Feeder ID -Feeder SetNo
"Feeder Set No" is displayed.
履 2 送料器 ID 送料器安装号
示送料器的安装位置号。
Ea14685 Cart num 料号
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 188 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Ea14686 Cart Set num 料内的安装号
Ea14687 locate 所在位置
Ea14688 Use 使用状
Ea14689 Unit log -Feeder ID -Feeder Counter
The count the feeder driven is displayed.
履 2 送料器 ID 送料次数
示送料器的次数。
Ea14690 Unit log -Feeder ID -Pick ErrorCounter
The count of "Pick Error" for the parts which is installed to the feeder is displayed.
履 2 送料器 ID 吸料出次数
示送料器上的元件所生的吸料次数。
Ea14691 Unit log -Feeder ID -Pick Error Par
The ratio of "Pick Error" for the parts which is installed to the feeder is displayed.
This value is calculated by "Pick Error Counter" / "Feeder Counter".
履 2 送料器 ID 吸料出率
示送料器上的元件所生的吸料次数与送料次数的比率。
Ea14692 Unit log -Feeder ID -Vision ErrorCounter
The count of "Vision Error" for the parts which is installed to the feeder is displayed.
履 2 送料器 ID 元件出次数
示送料器上的元件所生的次数。
Ea14693 Unit log -Feeder ID -Vision ErrorPar
The ratio of "Vision Error" for the parts which is installed to the feeder is displayed.
This value is calculated by "Vision Error Counter" / "Feeder Counter".
履 2 送料器 ID 元件出率
示送料器上的元件出次数与送料次数的比率。
Ea14694 Unit log -Feeder ID -No PartsError Counter
The count of "No Parts Error" for the parts
which is installed to the feeder is displayed.
履 2 送料器 ID 无元件出次数
示送料器上的元件所生的无元件次数。
Ea14695 Unit log -Feeder ID -No PartsError Par
The ratio of "No Parts Error" for the parts which is installed to the feeder is
displayed.
This value is calculated by "No Parts Error Counter" / "Feeder Counter".
履 2 送料器 ID 吸嘴出次数
示送料器上的元件所生的无元件次数与送料次数的比率。
Ea14696 Unit log -Feeder ID -Nozzle ErrorCounter
The count of "Nozzle Error" for the parts which is installed to the feeder is
displayed.
履 2 送料器 ID 吸嘴出次数
示送料器上的元件所生的吸嘴次数。
Ea14697 Unit log -Feeder ID -Nozzle ErrorPar
The ratio of "Nozzle Error" for the parts which is installed to the feeder is displayed.
This value is calculated by "Nozzle Error Counter" / "Feeder Counter".
履 2 送料器 ID 吸嘴出率
示送料器上的元件所生的吸嘴次数与送料次数的比率。
Ea14698 Unit log -Feeder ID -Date
The date when each feeder began driving is displayed.
履 2 送料器 ID 始
示送料器的始。
Ea14699 Unit log -Feeder ID -Warning
The state of "Maintenance Warning" for the feeder is displayed.
履 2 送料器 ID 点警告状
示送料器的点警告状。
Ea14700 Unit log -Nozzle ID -Nozzle ID
ID(Code Name for Identification) set for the nozzle is displayed.
履 2 吸嘴 ID 吸嘴 ID
示吸嘴的 ID。
Ea14701 Unit log -Nozzle ID -Nozzle Type
"Nozzle Type Name" is displayed,
which is used for specify a use of the nozzle.
履 2 吸嘴 ID 吸嘴型
示吸嘴型名。
用于辨吸嘴的。
Ea14702 Unit log -Nozzle ID -Table No.
"Mount Table Number" is displayed, which equipped the nozzle.
履 2 吸嘴 ID 工作台号
示安装吸嘴的工作台号。
Ea14704 Unit log -Nozzle ID -Nozzle Station No.
"Nozzle Station Number" is displayed,
which is the location number on the nozzle station for the nozzle.
履 2 吸嘴 ID 吸嘴交站号
示吸嘴交站中存放吸嘴的位置号。
Ea14705 Unit log -Nozzle ID -Head No.
"Head Number" is displayed, which can equip the nozzle.
履 2 吸嘴 ID Head 号
示安装吸嘴的 Head 号
Ea14706 Unit log -Nozzle ID -Head Type
"Head Type" is displayed, which means the type of method for exchanging nozzle.
Fixed : Cannot exchange nozzles
Manual : Can exchange nozzles with manual operation.
ANC : Can exchange nozzles from the nozzle station by the automatic operation.
FNC : Can exchange nozzles from the flying nozzle by the automatic operation.
履 2 吸嘴 ID Head
示安装吸嘴的 Head 。
固定 : 不能行吸嘴交。
手 : 可以手交吸嘴。
ANC : 可以自在吸嘴交站交吸嘴。
FNC : 可以自行行式交吸嘴。
Ea14707 Locate 所在位置
Ea14708 Use 使用状
Ea14709 Blow Level 真空
Ea14710 Unit log -Nozzle ID -Pick UpCounter
The count the nozzle picked is displayed.
履 2 吸嘴 ID 吸料次数
示吸嘴行吸料作的次数。
Ea14711 Unit log -Nozzle ID -Pick ErrorCounter
The count of "Pick Error" for the parts which is installed to the nozzle is displayed.
履 2 吸嘴 ID 吸料出次数
示吸嘴吸附元件所生的吸附次数。
Ea14712 Unit log -Nozzle ID -Pick Error Par
The ratio of "Pick Error" for the parts which is installed to the nozzle is displayed.
This value is calculated by "Pick Error Counter" / "Pick Up Counter".
履 2 吸嘴 ID 吸料出率
示吸嘴吸附元件所生的吸附次数与送料次数的比率。
Ea14713 Unit log -Nozzle ID -Vision ErrorCounter
The count of "Vision Error" for the parts which is installed to the nozzle is displayed.
履 2 吸嘴 ID 元件出次数
示吸嘴吸附元件所生的次数。
Ea14714 Unit log -Nozzle ID -Vision ErrorPar
The ratio of "Vision Error" for the parts which is installed to the nozzle is displayed.
This value is calculated by "Vision Error Counter" / "Pick Up Counter".
履 2 吸嘴 ID 元件出率
示吸嘴吸附元件所生的次数与送料次数的比率。
Ea14715 Unit log -Nozzle ID -No PartsError Counter
The count of "No Parts Error" for the parts
which is installed to the nozzle is displayed.
履 2 吸嘴 ID 无元件出次数
示吸嘴吸附元件所生的无元件次数。
Ea14716 Unit log -Nozzle ID -No PartsError Par
The ratio of "No Parts Error" for the parts which is installed to the nozzle is
displayed.
This value is calculated by "No Parts Error Counter" / "Pick Up Counter".
履 2 吸嘴 ID 无元件出率
示吸嘴吸附元件所生的无元件次数与送料次数的比率。
