Comparison Table ( English - Chinese ) VGOS V2.46STD R1.000 132 / 237 Copyright (C) 2009 Y amaha Motor Co.,Ltd. All Rights Reserved. Code Code Code Code Englis h Englis h Englis h Englis h Chinese Chinese Chinese Chinese…
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 131 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
correction.
Ea08601 "Demo." button is pressed down.
So print pressure feedback is not executed.
"示范印刷"按已按下。
不会行印控制理。
Ea08602 "No Vision" and "Demo." button is pressed down:
- fiducial recognition will not be executed.
- print pressure feedback will not be executed.
"不"、"示范印刷"按已按下。
不会行基准。
不会行印控制理。
Ea08603 Conveyor width changes.
Please be careful.
改送度。
注意。
Ea08604 Remove Board on the conveyor. 取出送上的基板。
Ea08605 Printing action starts.
Please be careful.
始印刷。
注意。
Ea08606 Squeegee head moves.
Please be careful.
将要移刮刀。
注意。
Ea08607 Board table moves.
Please be careful.
将要移基板工作台。
注意。
Ea08608 Please clean the mask manually.
After cleaning please release "EMERGENCY STOP"
and press below button.
清网板。
如已完成清，机盖，
解除急停机状。
Ea08609 Cleaner moves back.
Please be careful.
将要收回清装置。
注意。
Ea08610 Please clean the mask manually. 清网板。
Ea08611 Do you wish to change squeegee direction? 可以改印刷方向?
Ea08612 Cleaning action starts.
Please be careful.
始自清。
注意。
Ea08613 Do you wish to reset auto running?
This operation is not available under this status.
要位自运行?
因不是位状，所以不能行理。
Ea08614 Executing cleaning action... 正在行自清．．．
Ea08615 Rolling cleaner gauze... 正在卷取清卷．．．
Ea08616 Executing print action... 正在印刷．．．
Ea08617 Reset operation... 正在行位理．．．
Ea08618 Board table is moving... 正在移基板工作台．．．
Ea08619 Cleaner is not fixed.
Do you put it back?
清装置没有收回。
是否收回清装置?
Ea08620 Cleaner is moving back. 正在收回清装置．．．
Ea08621 Board is not fixed.
Do you want to fix the Board?
基板没有固定
是否入基板?
Ea08622 Enclosed squeegee head moves up.
Please be careful.
将要上升封型刮刀。
注意。
Ea08623 Enclosed head is moving up... 正在上升封型刮刀．．．
Ea08624 Fiducial recognition starts.
Please be careful.
将要行基准。
注意。
Ea08625 Recognizing Board fiducial... 正在基板基准．．．
Ea08626 Recognizing Mask fiducial... 正在网板基准．．．
Ea08627 Please release "EMERGENCY STOP". 解除急停机状。
Ea08628 Mask is not clamped.
Do you want to clamp the mask?
网板没有固定，是否固定网板?
Ea08629 Mismatch of detected mask size.
Possible causes:
(1) Detected mask has mismatch size specified in Board
data.
(2) Mask positioner pin is not set correctly.
出网板尺寸不一致
可能因下列原因所致。
(1) 指定尺寸的网板没有安装。
(2) 决定网板位置的定位没有插在正确的位置。
Ea08630 Supply Board on entrance of the conveyer. 将基板插入送入口。
Ea08631 Carrying Board in and fixing it... 正在入并固定基板．．．
Ea08632 Releasing Board and carrying it out... 正在松并出基板．．．
Ea08633 Changing conveyor width... 正在改送度．．．
Ea08634 Squeegee is moving... 正在移刮刀．．．
Ea08635 Do you carry Board in and fix it for confirmation? 是否用入并固定基板方法来行确?
Ea08636 Do you supply solder? 是否供膏?
Ea08637 CLEANING INTERVAL TIME
Specified interval time have passed.
清超
已超指定的，始施清。
Ea08638 END OF JOB
Please press "RUN" button to restart auto running.
作完成
按"RUN"按，重新始自运行。
Ea08639 Board table and squeegee head move.
Please be careful.
移基板工作台和刮刀。
注意。
Ea08640 Cleaner is not fixed. 清装置没有收回。
Ea08641 Cleaner is connected with Board table.
Connection is being released.
清装置着。
解除。
Ea08645 Do you wish to carry out the fixed Board? 是否出基板?
Ea08646 Remove Board on the upper buffer conveyor. 取出上冲送上的基板。
Ea08647 Remove Board on the lower buffer conveyor. 取出下冲送上的基板。
Ea08648 Fixing Board... 正在固定基板．．．
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 132 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Ea08649 Releasing Board... 正在松基板．．．
Ea08650 Insufficient diskspace left.
There is no more HDD-space for saving inspection result.
Data can't be saved any more until more diskspace is
made available:
1.(Archive and) delete old inspection results.
2.Select another drive to save data to.
磁空不足。
保存果的磁的空容量不足。
如依旧，无法保存数据。
按以下方法确保磁空。
1.除去的果文件。
2.更保存器。
Ea08651 Drive not ready.
The drive to which an inspection result must be saved
is not ready. Possible causes are:
1.A floppy disk is not inserted.
2.A network is not connected.
3.No access right for writing data.
没有准器
保存果的器没有准。
可能因下列原因所致，确。
1．磁没有插入器。
2．网没有接。
3．置禁止写入。
Ea08659 Print Inspection starts.
Please be careful.
将要始印刷。
注意。
Ea08660 Executing print inspection action... 正在行印刷．．．
Ea08661 <<< WARNING >>>
If the enclosed squeegee head attaches on the mask and
is filled by solder, please press "CANCEL" button.
In this case please use "SHAKE OFF" button to move
the squeegee head up.
If you want to enforce it, press "OK" button.
封型刮刀上升警告
封型刮刀接触网板，充填膏，
按"取消"按。
此，用"振停止"按使刮刀上升。
只有在制行，才按"OK"。
Ea08663 <<< WARNING >>>
Current angle of Board table is not good for teaching.
Position teaching has failed.
Do you want to adjust the angle?
示教警告
基板工作台的角度，不适合示教作。
示教无效。
是否更改基板工作台的角度?
Ea08664 Do you wish to carry Board in and fix it? 是否入并固定基板?
Ea08666 Executing rolling action... 正在行膏拌．．．
Ea08667 Do you execute filling solder of Enclosed Head?
Please execute this operation, when solder is completely empty
in Enclosed Head.
It is not necessary to execute this operation for supplying
solder because of solder amount error.
行膏充填?
此操作只有在封型刮刀内完全没有膏才可行。
封型刮刀已有膏、因膏余量而充膏，
没有必要行此操作。
Ea08668 Executing filling solder... 正在充填膏．．．
Ea08669 Please supply solder.
Enclosed Head is running out of solder.
增加膏。
封型刮刀的膏不足。
Ea08671 Executing mask inspection action... 正在行网板．．．
Ea08672 Executing mask measurement action... 正在定网板．．．
Ea08673 Overwrite the result on inspection data?
The result of mask measurement is overwritten on inspection data.
But Board data is not saved.
If you want to save the result, Please save Board data.
是否将网板定果覆盖保存在数据上?
网板定果将覆盖保存在数据的外形
面比率上，但基板程序并不会保存。
如需保存此次的网板定果，保存基板
程序。
Ea08674 "Mask Offset" parameter will change
If you change "Board Distortion" parameter, "Mask Offset"
parameter will change to keep print position.
更新目偏移量。
更新基板歪斜校正参数，必同
更新目偏移量。与基板歪斜校正
参数的化量相当的目偏移量也
随之更新。
Ea08685 SIZURI DEMAND
%s
You have to carry out sizuri,
before going into automatic operation.
Is sizuri performed?
要求印刷
%s
自运行前、需要行印刷。
行印刷?
Ea08686 SIZURI DEMAND
%s
Before going into automatic operation,
you have to carry out sizuri.
When the board is on a conveyor, please remove it.
Is sizuri performed?
要求印刷
%s
自运行前、需要行印刷。
如果送上存在基板、清除基板。
行印刷?
Ea08688 SIZURI INTERVAL OVER
Specified interval time have passed, since the last PCB
was printed.
Is sizuri performed?
印刷要求已
前次的基板印刷后、指定的已。
行印刷?
Ea08689 SOLDER ABANDONMENT WARNING
Specified interval time have passed, since the last PCB
was printed.
Please discard solder.
膏弃警告
从上次基板的印刷始，指定的已。
弃膏。
Ea08690 Do you wish to execute Feedback Printing function?
Please press "RUN" button to restart auto running after
selection.
是否行多重印刷反?
某后，按"RUN"按，再次启自运行。
Ea08691 Do you wish to execute Feedback Cleaning function?
Please press "RUN" button to restart auto running after
是否行清反?
某后，按"RUN"按，再次启自运行。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 133 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
selection.
Ea08692 Do you wish to execute Feedback Printing function again?
Please press "RUN" button to restart auto running after
selection.
是否再次行多重印刷反?
某后，按"RUN"按，再次启自运行。
Ea08693 WARNING OF FEEDBACK PRINTING
Feedback Printing function will be executed.
Please press "YES" button to restart. If you want to judge again,
press "NO" button.
行多重印刷反
保持原并再启自运行，[是]。
在再次确画像的基上重新，[否]。
Ea08694 WARNING OF FEEDBACK CLEANING
Feedback Cleaning function will be executed.
Please press "YES" button to restart. If you want to judge again,
press "NO" button.
行清反
保持原并再次启自运行，[是]。
在再次确画像的基上重新，[否]。
Ea08695 Executing mask scan... 正在行网板描...
Ea08696 Release "EMERGENCY STOP" and press READY button.
When the "EMERGENCY STOP" is not released and the cancel
button is pressed,the "EMERGENCY STOP" is canceled and
any subsequent movement of the X Y R axis
can cause damage to the mask
when the board table is not lowered first.
解除急停机按扭。
在未解除急停机并按取消按情况下，之后解除
急停机，在不下降基板工作台的情况下移 XYR ，
可能会致网板坏。
Ea08697 Filling solder of Enclosed Head start
Please set solder cassette in Enclosed Head.
行膏充填
将膏盒安装到封型刮刀上后，按"OK"按。
Ea08698 Calculating the correction data of fiducial... 正在算基准校正量...
Ea08700 INSPECTION DATA ERROR
Object data couldn't be transferred to the vision system.
Object Data
印刷数据
未能向系送象数据。
象数据 号
Ea08701 PRINT INSPECTION DATA ERROR
View data couldn't be transferred to the vision system.
Print Inspection View Data
印刷数据
未能向系送野数据。
印刷野数据 号
Ea08702 PRINT INSPECTION DATA ERROR
The data number of the object data is unusual.
Print Inspection Object Data
印刷数据
象数据的数据号异常。
印刷象数据 号
Ea08703 PRINT INSPECTION DATA ERROR
The data number of the view data is unusual.
Print Inspection View Data
印刷数据
野数据的数据号异常。
印刷野数据 号
Ea08704 PRINT INSPECTION DATA ERROR
Object data don't exist.
Print Inspection Object Data
印刷数据
象数据不存在。
印刷象数据 号
Ea08705 PRINT INSPECTION DATA ERROR
View data don't exist.
Print Inspection View Data
印刷数据
野数据不存在。
印刷野数据 号
Ea08706 PRINT INSPECTION DATA ERROR
Object data is Skip data.
Print Inspection Object Data
印刷数据
象数据呈跳状。
印刷象数据 号
Ea08707 PRINT INSPECTION DATA ERROR
View data is Skip data.
Print Inspection View Data
印刷数据
野数据呈跳状。
印刷野数据 号
Ea08708 PRINT INSPECTION VISION ERROR
Vision recognition didn't work normally.
印刷行
没有正常作。
Ea08709 PRINT INSPECTION VISION ERROR
Inspection result couldn't be acquired from the vision system.
印刷行
未能从系得到果。
Ea08710 INSPECTION DATA ERROR
Total number of the object data couldn't be transferred to the vision system.
数据
未能向系送象数据的数。
Ea08711 PRINT INSPECTION DATA ERROR
Total number of the view data couldn't be transferred to the vision system.
印刷数据
未能向系送野数据的数。
Ea08712 NG RESULT IN PRINT INSPECTION
NG result occurs during Board inspection.
Print Inspection View Data
印刷果 NG
印刷的行果 NG。
印刷野数据 号
Ea08713 NG RESULT IN PRINT INSPECTION
NG result occurs in inspection for carried Board.
Pick up the Board.
If you want it to carry out to the next machine,
put it back as before.
印刷果 NG
已出基板的印刷的行果 NG。
取出基板。
原直接送至后工程机，将基板放在
取出基板的位置。
Ea08714 NG RESULT IN PRINT INSPECTION
NG result occurs in inspection for carried Board.
印刷果 NG
已出基板的印刷的行果 NG。
Ea08715 PRINT INSPECTION DATA ERROR
Inspection Execution Level couldn't be transferred to
the vision system.
果
未能向系送行。
Ea08716 NG RESULT IN PRINT INSPECTION
NG result occurs in printed Board inspection.
Please judge "OK" or "NG" for each view on the window
which will appear after closing of this error window.
If you will judge all view as "OK", the Board will be
印刷果 NG
印刷的行果 NG。
在框之后示的用画面，确个
野印刷的果，判定其是"OK"或"NG"。
如全野了"OK"，基板会送至后工序机。
