Comparison Table ( English - Chinese ) VGOS V2.46STD R1.000 231 / 237 Copyright (C) 2009 Y amaha Motor Co.,Ltd. All Rights Reserved. Code Code Code Code Englis h Englis h Englis h Englis h Chinese Chinese Chinese Chinese…
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 230 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
and return the pallet to the magazine by hand.
Stage No.
Magazine No.
料架台号 号
收柜号 号
Ea29132 Auto tray changer Rack protrude error
The magazine is protruded to the door direction.
Please check the Rack Origin sensor.
And please check whether the magazine is set correctly.
自托交器 料箱出
收柜正向柜方向出。
确料箱出感器的状。
另外，确收柜是否已正确置。
Ea29133 Auto tray changer Restarting error
Can not restart production because tray changer is dangerous or unexpected status.
If some pallets are out of the magazine, Please restore with the following procedure.
1. Press the "EMERGENCY STOP"
2. Remove the pallet by the hand
3. Press the ready button
4. Open the door and insert the pallet in original position
5. Close the door
自托交器 再次启
因托交器在危的状或没有料的状，所以不能再次启。
当料架从收柜中出，用如下序恢。
1. 按急停机按
2. 用手将料架取出
3. 按 Ready 按
4. 打柜，将料架放回到原来的位置
5. 柜
Ea29134 Auto tray changer : Failed to return the pallet
The pallet is protruded from the magazine.
Please press the "EMERGENCY STOP"
and return the pallet to the magazine by hand.
Stage No.
Magazine No.
Pallet Origin sensor:Detect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 料架退回失
料架从收柜中出。
按急停机按，并用手将料架放回到收柜。
料架台号 号
收柜号 号
料架出感器:出 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Ea29135 Auto tray changer : Failed to pull out the pallet
The pallet is protruded from the magazine.
Please press the "EMERGENCY STOP"
and return the pallet to the magazine by hand.
Stage No.
Magazine No.
Pallet Origin sensor:Detect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 料架抽出失
料架从收柜中出。
按急停机按，并用手将料架放回到收柜。
料架台号 号
收柜号 号
料架出感器:出 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Ea29136 Auto tray changer Restarting error
Can not restart production because tray changer is dangerous or unexpected status.
If some pallets are out of the magazine, Please restore with the following procedure.
1. Press the "EMERGENCY STOP"
2. Remove the pallet by the hand
3. Press the ready button
4. Open the door and insert the pallet in original position
5. Close the door
Stage No.
自托交器 料架退回
因托交器在危的状或没有料的状，所以不能再次启。
当料架从收柜中出，用如下序恢。
1. 按急停机按
2. 用手将料架取出
3. 按 Ready 按
4. 打柜，将料架放回到原来的位置
5. 柜
料架台号 号
Ea29137 Auto tray changer Restarting error
Can not restart production because tray changer is dangerous or unexpected status.
If some pallets are out of the magazine, Please restore with the following procedure.
1. Press the "EMERGENCY STOP"
2. Remove the pallet by the hand
3. Press the ready button
4. Open the door and insert the pallet in original position
5. Close the door
Stage No.
自托交器 料架抽出
因托交器在危的状或没有料的状，所以不能再次启。
当料架从收柜中出，用如下序恢。
1. 按急停机按
2. 用手将料架取出
3. 按 Ready 按
4. 打柜，将料架放回到原来的位置
5. 柜
料架台号 号
Ea29140 Auto tray changer Pallet set error
The pallet is on the stage.
Please put it into the magazine and execute it again.
自托交器 料架抽出
料架已抽出至料架台。
将料架放回到收柜，并再次行。
Ea29141 Ext. tray changer Pallet set error
The pallet is on the stage.
Please put it into the magazine and execute it again.
外部托交器 料架抽出
料架已抽出至料架台。
将料架退回到收柜，并再次行。
Ea29142 Auto tray changer : There is unknown pallet
Unknown pallet is detected by the sensor during pallet action.
Please return the pallet to the magazine.
Stage No.
Stage Set position sensor:Detect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 存在不明料架
退回/抽出料架的作中，出了不明料架。
将已抽出至料架台的料架退回收柜。
料架台号 号
料架台安装位置感器 (ATS )
料架台中位置感器:某一个出 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Ea29143 Ext. tray changer Pallet set error
Unknown pallet is detected by the sensor during pallet action.
Please return the pallet to the magazine.
Stage set sensor: Detect
外部托交器 料架抽出
退回/抽出料架的作中，出了不明的料架。
将已抽出至料架台上的料架退回收柜。
料架台安装位置感器 出料架
Ea29144 Auto tray changer : Pallet was lost
A pallet is lost by the sensor during pallet action.
Please check the pallet doesn't exist on the stage.
Stage No.
Stage Set position sensor:Undetect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 料架迷失
退回/抽出料架的作中，未能出料架台上的料架。
如料架已出收柜，将料架退回收柜。
料架台号 号
料架台安装位置感器:未出 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 231 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
Ea29145 Ext. tray changer Pallet set error
A pallet is lost by the sensor during pallet action.
Please check the pallet doesn't exist on the stage.
Stage set sensor: Undetect
外部托交器 料架抽出
退回/抽出料架的作中，没有出本存在的料架。
确料架是否已抽出至料架台。
料架台安装感器 未出料架
Ea29146 Ext. tray changer Axis moving error
Stage(DZ axis) can't move, because Hook axis(DY axis) is near the magazine.
On the [Unit]-[Ext. TC]-[Axis] screen, please keep away the hook axis (DY axis)
from the magazine.
Stage No.
Ext. tray changer Axis moving error___
Stage(DZ axis) can't move, because Hook axis(DY axis) is near the magazine.
On the [Unit]-[Ext. TC]-[Axis] screen, please keep away the hook axis (DY axis)
from the magazine.
Stage No.
Ea29147 Auto tray changer : Failed to return the pallet
When returning pallet,
unknown pallet was detected on stage.
Please return the pallet on stage to magazine.
Stage No.
Stage Set position sensor (ATS )
Stage Middle position sensor:Either Detect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 料架退回失
退回料架的途中，在料架台上出了不明料架。
将料架台上的料架退回收柜。
料架台号 号
料架台安装位置感器 (ATS )
料架台中位置感器: 出任意一个 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Ea29148 Auto tray changer : Failed to pull out the pallet
When pull out pallet,
pallet was not detected on stage.
If pallet is protruding from magazine, please return it to magazine.
Stage No.
Stage Set position sensor:Undetect (ATS )
*To check current sensor status, see [Unit]-[Auto TC] or [I/O] view.
自托交器 料架抽出失
抽出料架的途中，未能在料架台上出料架。
如料架已出收柜，将料架退回收柜。
料架台号 号
料架台安装位置感器:未出 (ATS )
*当前的感器状,可在[装置]-[自托]或[I/O]画面确。
Ea29149 Ext. tray changer Axis moving error
Stage(DZ axis) can't move, because the pulled pallet is near the magazine.
On the [Unit]-[Ext. TC]-[Axis] screen, please keep away the hook axis (DY axis)
from the magazine.
Stage No.
Ext. tray changer Axis moving error___
Stage(DZ axis) can't move, because the pulled pallet is near the magazine.
On the [Unit]-[Ext. TC]-[Axis] screen, please keep away the hook axis (DY axis)
from the magazine.
Stage No.
Ea29150 Auto Tray changer Door opening error
The door is open.
Please close the door.
自托交器 柜打
柜敞着。
将敞的柜。
Ea29151 Ext. Tray changer Door opening error
The door is open.
Please close the door.
外部托交器 柜打
柜敞着。
将敞的柜。
Ea29152 Auto Tray changer Door opening error
The door is open or the door is not correctly closed.
Please close the door.
(When the door light is off in spite of the door switch 'close',
please turn the door switch into 'open' once and turn it 'close'.)
自托交器 柜打
柜敞着或没有好。
将敞的柜。
(当柜[]，但柜指示灯却灯，
先将柜置[]，然后再置[]。)
Ea29153 Ext. Tray changer Door opening error
The door is open or the door is not correctly closed.
Please close the door.
(When the door light is off in spite of the door switch 'close',
please turn the door switch into 'open' once and turn it 'close'.)
Stage No.
外部托交器 柜打
柜敞着或没有好。
将敞的柜。
(当柜[]，但柜指示灯却灯，
先将柜置[]，然后再置[]。)
料架台号 号
Ea29154 Auto tray changer Door opening error
Failed to servo-on because Auto tray changer door is open.
Please close the opening door and press the 'READY' button again.
自托交器 柜打
因自托交器的柜敞着，所以不能将伺服 ON。
将敞的柜后，再按一次'READY'按。
Ea29155 Ext. tray changer Door opening error
Failed to servo-on because Ext. tray changer door is open.
Please close the opening door and press the 'READY' button again.
外部托交器 柜打
因自托交器的柜敞着，所以不能将伺服 ON。
将敞的柜后，再按一次'READY'按。
Ea29156 Auto tray changer Door opening error
The operation of opening the door was interrupted by "EMERGENCY STOP".
There is a possibility that the position of the pallet is not correct.
After releasing the "EMERGENCY STOP", Please open the door again and return the
pallet.
(If the door switch is already 'open',
please turn the door switch into 'close' once and turn it 'open')
自托交器 柜打
因急停机理柜打作中断了。
料架可能不在正确的位置上。
按急停机按，然后重新打柜并装入料架。
(柜已''，先将柜置[]，
然后再置[]。)
Ea29157 Auto tray changer Door opening error
Can not start production because the operation of opening the door is not
completed.
Though door switch is 'Open', the pallet has not been returned yet.
This error is caused by interruptions of opening the door by emergency stop, etc.
Please put the pallet back in the magazine by opening the door again,
and restart the production.
自托交器 柜打
因柜打作没有完成，所以不能始自运行。
柜[]，但本退回的料架却抽出状。
状生于因急停机而引起的柜打中断等。
重新打柜并退回料架，再重新始自运行。
Ea29158 Auto tray changer Door opening warning
It may not move to the pallet drawer position,
because the door switch was operated quickly.
Please turn the door switch into 'close' once (the door light lights),
and turn it 'open' again.
自托交器 柜打
由于快操作柜，所以可能未移到
可行抽出的位置。
先将柜置[]，等柜指示灯点亮
后，再置[]。
Ea29159 Auto tray changer Magazine set warning 自托交器 收柜安装警告
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 232 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
The magazine is not set correctly.
Please check the following points.
1. The magazine clamp must be locked correctly.
2. The pallet suppression of the magazine must be tightened correctly.
3. The pallet not protruding from the magazine.
收柜料箱的安装不正确。
确如下几点。
1. 收柜固定必定
2. 收柜的料架具必定
3. 料架没有从收柜中出
Ea29160 Auto tray changer Door closing warning
The door was closed with the door switch 'close'.
In this state, the tray changer can not work.
Please turn the door switch into 'open', and turn it 'close' again.
自托交器 柜警告
在柜位置[]的状下了柜。
状下，托交器可能无法作。
先将柜置[]，再置[]。
Ea29161 Auto tray changer Door opening error
Can not open the door because of the INTERLOCK error.
Please turn the door switch 'open' and remove the cause of the INTERLOCK error.
Then please turn the door switch 'close' once again.
自托交器 柜打
因正在中，所以不能打柜。
先将柜置[]，等排除原因后，
再置[]。
Ea29162 Ext. tray changer Door opening warning
It may not move to the pallet drawer position,
because the door switch was operated quickly.
Please turn the door switch into 'close' once (the door light lights),
and turn it 'open' again.
外部托交器 柜打
由于快操作柜，所以可能未移到
可行抽出的位置。
先将柜置[]，等柜指示灯点亮
后，再置[]。
Ea29163 Ext. tray changer Magazine set warning
The magazine is set, but the magazine clamp is not locked correctly.
Please open the door and lock the magazine clamp.
外部托交器 收柜安装警告
然安装了收柜，但没有定收柜固定。
定收柜固定。
Ea29164 Ext. tray changer Door closing warning
The door was closed with the door switch 'close'.
In this state, the tray changer can not work.
Please turn the door switch into 'open', and turn it 'close' again.
外部托交器 柜警告
在柜位置[]的状下了柜。
状下，托交器可能无法作。
先将柜置[]，再置[]。
Ea29165 Ext. tray changer Door opening error
The door switch is 'open'.
Please turn the door switch 'close'.
(When the door is open,
turn the door switch 'close' after closing the door first, please)
Stage No.
外部托交器 柜打
柜位置[]。
将柜置[]。
(柜敞，先将柜，然后置[]。)
料架台号 号
Ea29180 Auto tray changer Picking error
Cannot pick a component from the tray.
If components are empty, please supply components.
When there are components,
please check whether a component can be picked from a tray correctly.
If there is a head vacuuming a component, remove it and restart production.
Mount data
Component data Name
Start Pallet No.
End Pallet No.
自托交器 吸附
未能从托吸附元件。
元件用完，充元件。
存在元件，确是否能从托正确吸附元件。
如正吸附着元件，在取出后再次运行。
装数据 号
元件数据 号 名称
料架始号 号
料架束号 号
Ea29181 Ext. tray changer Picking error
Cannot pick a component from the tray.
If tray components are empty, please supply components.
When there are tray components,
please check whether a component can be picked from a tray correctly.
If there is a head vacuuming a component, remove it and restart production.
Mount data
Component data Name
Start Pallet No.
End Pallet No.
Tray Head No.
外部托交器 吸附
未能从托吸附元件。
元件用完，充元件。
存在元件，确是否能从托正确吸附元件。
如正吸附着元件，在取出后再次运行。
装数据 号
元件数据 号 名称
料架始号 号
料架束号 号
Head 号 号
Ea29182 Ext. tray changer Component supply error
Failed to put the component on the station.
There is a possibility that the component was dropped around the station.
Please remove the component and restart production.
Mount data
Component data Name
Station
Next tray position is for the next pick sequence.
(X= , Y= )
外部托交器 元件供
未能将元件正确放在料站上。
元件可能掉落在料站或其周。
取出元件后重新运行。
装数据 号
元件数据 号 名称
料站 号
接下来要使用的元件在托上的位置：
(X= 号, Y= 号)
Ea29183 Ext. tray changer Component supply error
The component is not placed correctly on the station.
If the component is on the station, please remove it.
Mount data
Component data Name
Station
Next tray position is for the next pick sequence.
(X= , Y= )
外部托交器 元件供
供元件没有正确放置在料站上。
的料站上存在元件，取出。
装数据 号
元件数据 号 名称
料站 号
接下来要使用的元件在托上的位置：
(X= 号, Y= 号)
Ea29184 Ext. tray changer Component supply error
Unknown component is on the station.
Please remove the component and restart production.
外部托交器 元件供
料站上放着元件。
在取出元件后再次运行。
