Ea14099 Unit Log - Head - ANC Error Counter
Number of errors concerning the ANC action.
履 2 装 ANC 交出次数
装 ANC 交吸嘴所生的次数
Ea14100 Unit Log - Head - Error per cent(%)
The ratio of the head ANC error to the head ANC count.
履 2 装 出率(%)
装的 ANC 交次数/ANC 交次数 的比率
Ea14110 Unit Log - Nozzle - Head
Head numbering.
履 2 吸嘴 装
示持有的装个数
Ea14111 Unit Log - Nozzle - Date
Time to start recording the nozzle suction.
履 2 吸嘴 始
吸嘴吸料的始
Ea14112 Unit Log - Nozzle - Pick Up Counter
Number of nozzle suctions.
履 2 吸嘴 吸料次数
吸嘴吸料的次数
Ea14113 Unit Log - Nozzle - Pick Error Counter
Number of errors concerning the nozzle suction.
履 2 吸嘴 吸料出次数
生吸嘴吸料的次数
Ea14114 Unit Log - Nozzle - Error per cent(%)
The ratio of the nozzle pick error to the nozzle pick count.
履 2 吸嘴 出率(%)
吸嘴的 吸料次数/吸料次数 的比率
Ea14120 Unit Log - Feeder - Set No
Set position numbering.
履 2 送料器安装号
示具的送料器安装个数
Ea14121 Unit Log - Feeder - Data
Time to start recording the feeder action.
履 2 送料器始
送料器的始
Ea14122 Unit Log - Feeder - Feeder Counter
Number of feeder actions.
履 2 送料器送料次数
送料器的次数
Ea14123 Unit Log - Feeder - Pick Error Counter
Number of errors concerning the feeder actions.
履 2 送料器 吸料出次数
生送料器吸料的次数
Ea14124 Unit Log - Feeder - Error per cent(%)
The ratio of the feeder pick error to the feeder pick count.
履 2 送料器出率(%)
送料器的 吸料次数/吸料次数 的比率
Ea14130 Unit Log - Conveyor - Item
Item names concerning the conveyor.
履 2 送装置 目
示送装置的目名
Ea14131 Unit Log - Conveyor - Data
Time to start recording the conveyor action.
履 2 送装置 始
送运行的始
Ea14132 Unit Log - Conveyor - Counter
Number of conveyor actions.
履 2 送装置 作次数
送运行的次数
Ea14133 Unit Log - Conveyor - Error Counter
Number of errors concerning the conveyor actions.
履 2 送装置 作出次数
生送运行的次数
Ea14134 Unit Log - Conveyor - Error per cent(%)
The ratio of the conveyor error to the conveyor action count.
履 2 送装置 出率(%)
送的 运作次数/运作次数 的比率
Ea14140 Unit Log - Parts(Current Data) - P.No
Parts number is displayed.
履 2 元件(当前的数据) 元件号
示元件号
Ea14141 Unit Log - Parts(Current Data) - Part Name
Parts name is displayed.
履 2 元件(当前的数据) 元件名
示元件名
Ea14142 Unit Log - Parts(Current Data) - Pick Error Counter
Pick error count including retry.
In the following case, it counts.
1. When it is detected that a part is not
present before recognition or mounting.
This check is performed only when
vacuum check is set to special check.
2. When it is detected that a part is not picked
at the center of the nozzle at the
time of recognition.
3. When a part can not be detected
at the time of recognition.
4. When "Ea97" error occurred.
履 2 元件(当前的数据) 吸料出次数
元件生的吸料次数。
(包括重新行)
下列情况将数。
1. 前或装前，已判断出没有吸附到元件。
，只有吸附·放真空感器置特殊才行。
2．果没能将元件吸附到吸嘴中心。
3．，没有找到象物。
4．生 "Ea97" 。
Ea14143 Unit Log - Parts(Current Data) - Error per cent(%)
The ratio of the number of
pickup errors / amount of consumption of this part.
履 2 元件(当前的数据) 出率(%)
元件的 吸料次数/消耗量 的比率
Ea14144 Unit Log - Parts(Current Data) - Vision Error Counter
Vision error count including retry.
履 2 元件(当前的数据) 出次数。(包括重新行)
元件的的生次数
Ea14145 Unit Log - Parts(Current Data) - Error per cent(%)
The ratio of the number of
vision errors / amount of consumption of this part.
履 2 元件(当前的数据) 出率(%)
元件的 次数/消耗量 的比率
Ea14146 Unit Log - Parts(Current Data) - No Parts Error Counter
It counts, when a pickup error, a recognition
error, etc. occur continuously with the same
parts and exceeds the retry count setting.
If retry count is set at "2", the No Parts Error counter
will increment with "3" because the error
occurred 3 times consecutively.
履 2 元件(当前的数据) 无元件出次数
元件因没有元件而生的次数。
同一元件生吸料、，超置
的重新行的次数，已出的次数数。
例如，重新行次数置"2"，
3 次生后，出次数以"3"数。
Ea14147 Unit Log - Parts(Current Data) - Error per cent(%)
The ratio of the number of
no parts errors / amount of consumption of this part.
履 2 元件(当前的数据) 出率(%)
元件因 没有元件而生的次数/消耗量 的比率
Ea14148 Unit Log - Parts(Current Data) - Nozzle Error Counter
Nozzle error count including retry.
The number of times a part was picked up
履 2 元件(当前的数据) 吸嘴出次数
元件生吸嘴堵塞的次数。
(包括重新行)
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 180 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
and recognized, but the offset of the part
was out of tolerance.
元件的果元件中心坐异常，数。
Ea14149 Unit Log - Parts(Current Data) - Error per cent(%)
The ratio of the number of
nozzle errors / amount of consumption of this part.
履 2 元件(当前的数据) 出率(%)
元件的 吸嘴次数/消耗量 的比率
Ea14150 Unit Log - Parts(Current Data) - Consumption
Parts consumption counter
The part count for the e.g. test picking
is excluded.
When a part is picked normally, it is counted.
履 2 元件(当前的数据) 消耗数
元件的消耗数。
算自运行中所消耗的元件数，因吸附等消耗的元件不被数。
正常吸附元件，才数。
Ea14151 Unit Log - Parts(Current Data) - Change Counter
Change Counter
(This data is not used.)
履 2 元件(当前的数据) 料更次数
元件的料更次数
(数据没有使用)
Ea14152 Unit Log - Parts(Current Data) - Feeder Type
The "Feeder Type" of part data is displayed.
When it is changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 送料器型
元件的送料器型。
示元件数据的"送料器型"中的置。
如果中途更改，自运行始会自更新。
Ea14153 Unit Log - Parts(Current Data) - Feeder Set No.
The "Feeder Set No." of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 送料器安装号
元件的送料器安装号。
示元件数据的 "送料器安装位置"中的置。
如果中途更改，自运行始会自更新。
Ea14154 Unit Log - Parts(Current Data) - Nozzle Type
The "Required Nozzle" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 吸嘴型
元件的吸嘴型。
示元件数据的"使用吸嘴"中的置。
如果中途更改，自运行始会自更新。
Ea14155 Unit log - Parts(Current Data) - Pick Speed
"Pick Speed (%)" of part data is expressed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 吸料速度
元件的吸附速度。
示元件数据的"吸附速度(%)"中置。
如果中途更改，自运行始会自更新。
Ea14156 Unit Log - Parts(Current Data) - Pick Timer
"Pick Timer sec" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 吸附
元件的吸附。
示元件数据的"吸附(秒)"中的置。
如果中途更改，自运行始会自更新。
Ea14157 Unit Log - Parts(Current Data) - Pick Height
"Pick Height (mm)" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 吸料高度
元件的吸料高度。
示元件数据的"吸料高度(mm)"中的置。
如果中途更改，自运行始会自更新。
Ea14158 Unit Log - Parts(Current Data) - Mount Speed
"Mount Speed (%)" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 装速度
元件的装速度。
示元件数据的"装速度(%)"中的置。
如果中途更改，自运行始会自更新。
Ea14159 Unit Log - Parts(Current Data) - Mount Timer
"Mount Timer sec" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 装
元件的装。
示元件数据的"装(秒)"中的置。
如果中途更改，自运行始会自更新。
Ea14160 Unit Log - Parts(Current Data) - Mount Height
"Mount height (mm)" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 装高度
元件的装高度。
示元件数据的"装高度(mm)"中的置。
如果中途更改，自运行始会自更新。
Ea14161 Unit Log - Parts(Current Data) - Alignment Type
The "Alignment Type" of part data is displayed.
When changed during production, it is updated at
the time of the auto running start.
履 2 元件(当前的数据) 型
元件的型。
示元件数据的"校正型"中的置。
如果中途更改，自运行始会自更新。
Ea14162 Unit Log - Parts(Current Data) - Threshold
The "Part Threshold" of part data is displayed.
When changed during production, it is updated at the
time of the auto running start.
履 2 元件(当前的数据) 界限
元件的界限。
示元件数据的"元件界限"中的置。
如果中途更改，自运行始会自更新。
Ea14163 Unit Log - Parts(Current Data) - Coplanarity Error Counter
Coplanarity Error Counter
履 2 元件(当前的数据) 引脚起出次数
元件生引脚起的次数
Ea14164 Unit Log - Parts(Current Data) - Error per cent(%)
Error per cent(%)
履 2 元件(当前的数据) 出率(%)
元件的 引脚起的次数/消耗量 的比率
Ea14170 Unit Log - Parts(Reenact Data) - Part Name
Parts name is displayed.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 元件名
示元件名。
切基板程序自合保存。
Ea14171 Unit Log - Parts(Reenact Data) - Date
Time which started measurement
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 始
元件的始。
切基板程序自合保存。
Ea14172 Unit Log - Parts(Reenact Data) - Pick Error Counter
Pickup error count including retry.
In the following case, it counts.
履 2 元件(史数据) 吸料出次数
元件生吸附的次数(包括重新行)。
下列情况将数。
Comparison Table ( English - Chinese )
VGOS V2.46STD R1.000 181 / 237 Copyright (C) 2009 Yamaha Motor Co.,Ltd. All Rights Reserved.
Code
CodeCode
Code
English
EnglishEnglish
English
Chinese
ChineseChinese
Chinese
1. When it is detected that a part is not
present before recognition or mounting.
This check is performed only when
vacuum check is set to special check.
2. When it is detected that a part is not picked
at the center of the nozzle at the
time of recognition.
3. When a part can not be detected
at the time of recognition.
4. When "Ea97" error occurred
Data is saved at the time
of a Board data change.
1．前或者装前，判断没有吸附到元件。
，限吸附·放真空置特殊的候才行。
2．果没能将元件吸附到吸嘴的中心。
3．，没有找到象物。
4．生 "Ea97" 。
切基板程序自合保存。
Ea14173 Unit Log - Parts(Reenact Data) - Error per cent(%)
The ratio of the number of
pickup errors / amount of consumption of this part.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 出率(%)
元件的 吸料次数/消耗量 的比率。
切基板程序自合保存。
Ea14174 Unit Log - Parts(Reenact Data) - Vision Error Counter
Vision error count including retry.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 出次数(包括重新行)
元件生的次数。
切基板程序自合保存。
Ea14175 Unit Log - Parts(Reenact Data) - Error per cent(%)
The ratio of the number of
vision errors / amount of consumption of this part.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 出率(%)
元件的 次数/消耗量 的比率
切基板程序自合保存。
Ea14176 Unit Log - Parts(Reenact Data) - No Parts Error Counter
It counts, when a pickup error, a recognition
error, etc. occur continuously with the same
parts and exceeds the retry count setting.
If retry count is set at "2", the No Parts Error counter
will increment with "3" because the error
occurred 3 times consecutively.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 无元件出次数
元件生无元件的次数。
同一元件生的吸料、，超了置
的重新行数，以出的次数数。
例如，重新行数置"2"， 3 次生，出次数以"3"数。
切基板程序自合保存。
Ea14177 Unit Log - Parts(Reenact Data) - Error per cent(%)
The ratio of the number of
no parts errors / amount of consumption of this part.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 出率(%)
元件 无元件次数/消耗量 的比率
切基板程序自合保存。
Ea14178 Unit Log - Parts(Reenact Data) - Nozzle Error Counter
Nozzle error count including retry.
The number of times a part was picked up
and recognized, but the offset of the part
was out of tolerance.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 吸嘴出次数
元件生吸嘴堵塞的次数。
(包括重新行)
元件的果元件的中心坐异常，数。
切基板程序自合保存。
Ea14179 Unit Log - Parts(Reenact Data) - Error per cent(%)
The ratio of the number of
nozzle errors / amount of consumption of this part.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 出率(%)
元件的 吸嘴次数/消耗量 的比率。
切基板程序自合保存。
Ea14180 Unit Log - Parts(Reenact Data) - Consumption
Parts Consumption Counter
The part count for e.g. test picking
is excluded. When a part is picked normally,
it is counted.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 消耗数
元件的消耗数。
算自运行中所消耗的元件数，因吸料等消耗的元件不被数。
元件正常吸附数。
切基板程序自合保存。
Ea14181 Unit Log - Parts(Reenact Data) - Change Counter
Change Counter
(This data is not used.)
履 2 元件(史数据) 料更次数
元件的料更次数
(数据没有使用)
Ea14182 Unit Log - Parts(Reenact Data) - Feeder Type
The "Feeder Type" of part data is displayed.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 送料器型
元件的送料器型。
示在元件数据的"送料器型"中的置。
切基板程序自合保存。
Ea14183 Unit Log - Parts(Reenact Data) - Feeder Set No.
The "Feeder Set No." of part data is displayed.
Data is saved at the time
of a Board data change.
履 2 元件(史数据) 送料器安装号
元件的送料器安装号。
示元件数据的"送料器安装位置"中的置。
切基板程序自合保存。
Ea14184 Unit Log - Parts(Reenact Data) - Nozzle Type
The "Required Nozzle" of part data is displayed.
履 2 元件(史数据) 吸嘴型
元件的吸嘴型号。
