EPU Instruction Manual Chapter 4 Creating a Production Program
4-146
(1) List of the menu items
The menu items of the number of components on each component supply unit are
shown here.
1) Items displayed when the [Parts no. setup] command is called
No. Item Description
1 Feeder Shows where to supply with components.
When a stick feeder is selected as a component supply unit, the lane number is
shown in parentheses.
2 Package Shows the packaging style of a component (such as tape, stick and bulk)
3 Component name Shows the component name.
4 Warning
Shows the component supply error.
*: Indicates that the number of remaining components becomes less than
the number specified at “W.Level.”
E: Indicates that a component pick-up retry over error occurs, and the
system stops picking up a component.
To recover the system from an error: Enter the number of the remaining
components or replenish the feeder with components fully.
2) Items to be set
No. Item Description
1 Initial
Enter the number of components supplied in the package specified with “Package”
before the system starts using it. When you enter or change the initial value, the
changed value is copied to the field of the item “Remain.”
When you enter the initial value, the corresponding value is set in the “Remain”
field.
- When you set “0”as this “Initial” value for a feeder, the system does not control
the number of the remaining components by subtracting the number of used
components from this value and continues producing PWBs until a retry over
error occurs at the feeder. Otherwise, the value you set here is entered to the
field of the item “Remain” when you click the <Replenish Comp.> button.
2 Remain
- Shows the number of remaining components when the system checks the
number of components. This value decrements every time the system picks up
a component during production.
- When “0” is set to “Initial,” the value shown here does not decrement.
- If you change the value of “Initial,” the value shown here is changed in the same
manner. You can also change this value only according to components to be
supplied.
- When a tape feeder, stick feeder or bulk feeder is used as a component supply
unit, the system stops subtracting the number of used components from the
“Initial” value if this value reaches “0,” but continues producing PWBs.
When “0” is set in this “Remain” field, the system does not stop producing PWBs
either. In these cases, the feeder continues placing components on boards
until a retry over error occurs.
- The number of the remaining components becomes a smaller number than the
value set in the “Level” field, the signal light warns an operator.
3 W.Level
Sets the warning level.
When the number of remaining components becomes less than the value
displayed here, the signal tower warns you by flashing its yellow lamp.
If “0” is set to “Initial,” this function does not operate.
When you enter a value to “Initial,” this value is initialized.
EPU Instruction Manual Chapter 4 Creating a Production Program
4-147
(2) Device
No. Menu item Description
1
Front
Shows only components set on the front bank.
2
Rear
Shows only components set on the rear bank. (When the rear
feeder option is available.)
3
Holder
Not used in JX-350.
4
MTC
Not used in JX-350.
5
MTS
Shows only components set on the MTS.
(3) Supply
When you press one of the < Supply> buttons, the system replenishes the specified
component supply unit with components fully.
When the system replenishes the unit with components, it resets the number of the
remaining components specified in the “Remain” field to the value specified in the
“Initial” field, and cancels the warning.
No. Menu item Description
1 Replenish all comp Replenishes all types of components set on the machine fully.
2 Replenish Comp Replenishes components whose type(s) is (are) displayed with
the <Device> button fully.
3 Feeder Replenishes components that are selected on the “Parts no.
setup” screen.
(4) <OK>/<CANCEL> buttons
No. Button Description
1 OK Updates your change and quits the “Parts no. setup” screen to return to
the previous screen.
2 CANCEL Discards your change and quits the “Parts no. setup” screen to return
to the previous screen.
EPU Instruction Manual Chapter 4 Creating a Production Program
4-148
4.5 Print
Select the [Print] command from the “File” menu.
The “Print” main screen appears.
Select the items to be printed, and press the <Print> button. When you press the <Save
to file> button, you can save the data in a file in a text format (whose extension is “txt”).
Refer to Section 1.9.8 "Printing” of the “JX-350 Instruction Manual” for details.
