EPU Instruction M anual Chapter 5 Database 5-7 5.1.3 Call List W hen you select t he [Database] comm and from the “ Placement data ” screen ( if any component name is not entered in the Placement data) or the “ Component…
EPU Instruction Manual Chapter 5 Database
5-6
When the following error message is displayed, the component data of the database is
associated.
For details, refer to the instruction manual of the production support system.
If you select “Yes” for the menu item “Notify when data into DB” on the “Environ-
ment setting” screen, the following message appears on the screen when the system
finishes registering data into the database.
If you select “No” for the menu item “Notify when data into DB” on the “Environ-
ment setting” screen, the “Information” message shown above does not appear on the
screen.
• The system registers component data in the database sequentially according to
each component name.
• The database in which the system registers data is the database specified with
the “Environment Setting” (See Section 4.3.2 “Environment setting”).
EPU Instruction Manual Chapter 5 Database
5-7
5.1.3 Call List
When you select the [Database] command from the “Placement data” screen (if any
component name is not entered in the Placement data) or the “Component data” screen,
you can select the [Call List] command. If any component name is entered in the
Placement data, you cannot execute this command. In this case, this command is
dimmed on the “Database” menu.
See Section 5.1.1 “How to Use a Database” for how to execute this command.
5.1.3.1 Search
You can search the component database for data.
<Procedure>
①
Click the <Search> button on the database list screen.
EPU Instruction Manual Chapter 5 Database
5-8
② The following dialog box appears on the screen.
Specify the search conditions, and click the <OK> button.
To narrow a search, specify the “Package Class,” “Feeder,” and/or “Centering”
fields.
③ When the system finishes searching, it displays the “Database List” on which the first
matched component data registered in the database is highlighted.
5.1.3.2 Searching the next matched component data
Click the <Find next > button on the screen.
The system displays the next matched data.
Enter your search keyword.
Select one from among these
search options.
