DIAGNOSTICS SCREEN CHANGE Chapter Issue 4, Aug 14 Technical Reference Manual 39.25 SCREEN CHANGE Selecting this diagnostics modul e opens the following window: The following icons are displayed: Next/Previous have no fun…
DIAGNOSTICS
SCREEN ALIGNMENT
39.24 Technical Reference Manual Chapter Issue 4, Aug 14
Drive Y Motor
Using Jog Buttons
Selecting this diagnostic function drives the Y actuator using the jog buttons.
The right jog button drives the Y actuator forward at slow speed and the left jog
button drives it to the rear, stopping immediately the button is released.
Toggle Chase
Clamp
Selecting this diagnostic function alternately energizes and de-energizes the
chase clamp solenoid, displaying On when the clamps are energized and Off
when the clamps are de-energized.
Cycle Alignment
System
Selecting this diagnostic function starts a continuous cycle of driving the stencil
actuators to each of the positions in the table below in sequence, dwelling for 2
seconds at each point and continuing the cycle.
The positions are given as XF, XR and Y in mm from the home position and are
as follows:
If data logging is enabled, every time the stencil returns to 0,0,0, locate a stencil
fiducial and its coordinates are appended to:
D:\Program Files\DEK\MachineControl\Printer\Screen.Dat file.
This continuous cycling is terminated by selecting the stop key or when the set
cycle count has been reached.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count. The cycle count may be preset 5 -
9995 cycles (default 50) by selecting Adjust.
10, 0, 0.
2 +20, +10, +10.
30, 0, 0.
4 -20, -10, -10.
50, 0, 0.
6 +10, +20, -10.
70, 0, 0.
8 -10, -20, +10.
DIAGNOSTICS
SCREEN CHANGE
Chapter Issue 4, Aug 14 Technical Reference Manual 39.25
SCREEN CHANGE Selecting this diagnostics module opens the following window:
The following icons are displayed:
Next/Previous have no function in this application.
Run Diagnost activates the toggle stencil clamps diagnostic function.
Exit returns operation to the module diagnostics page.
Toggle Screen
Clamps
Selecting this diagnostic function alternately energizes and de-energizes the
stencil clamps, displaying On when energized and Off when de-energized.
Screen Sensor This diagnostic function continuously displays the status of the stencil sensor.
Screen Change Diagnostics
Toggle Screen Clamps
Toggle Screen Stop
Load Screen
Centre Screen Sensor
OFF
ON
OFF
Run
Diagnost
Next
Previous
Exit
DIAGNOSTICS
SCREEN CLEANER
39.26 Technical Reference Manual Chapter Issue 4, Aug 14
SCREEN CLEANER
Selecting this diagnostics module opens the following window:
The following icons are displayed:
Next/Previous moves the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The following icons are displayed:
Incr./Decr. changes the value of the cycle count.
Exit returns operation to the screen cleaner diagnostics page.
Toggle Dry Wipe
Blade
Selecting this diagnostic function raises and lowers the cleaner body assembly,
displaying On when the cleaner body assembly is raised and Off when the
cleaner body assembly is lowered.
Toggle Solvent
Pump
Selecting this diagnostic function alternately switches the solvent pump on and
off, displaying its current status.
Toggle Paper Feed Selecting this diagnostic function alternately switches the paper feed motor on
and off, displaying its current status.
OFF
Screen Cleaner Diagnostics
ON
OFF
Toggle Dry Wipe Blade
Toggle Solvent Pump
Toggle Paper Feed
Toggle Vacuum
Toggle Screen Cleaner Home Clamp
Cycle Clean Blade
Toggle Cleaner Camera
Clamp
Toggle Oscillate
OFF
OFF
OFF
ON
ON
OFF
Cleaner Paper Low/Advance
Cleaner Solvent Low
Cleaner Attached
Cycle Count
Done :-
0,To go :-
50
ON
ON
. . . more
Run
Diagnost
NextAdjust
Previous
Exit
Cleaner Cycle Parameters
CYCLE COUNT
50.0
Cycles
Incr. Decr.
Exit
